Used Precision Measuring Table for sale (25,874)

Condition: used, Year of construction: 2011, machine/vehicle number: IntNr231473, KEYENCE Model Series IM-6020, Year 2011 For sale: Optical measuring system KEYENCE IM-6020, in good and fully functional condition. The IM Series is recognized for its rapid, high-precision and operator-independent measuring capabilities, making it the ideal solution for quality assurance, goods-in inspection, and in-process control applications. Technical specifications (excerpt): Model: IM-6020 Year of manufacture: 06/2011 Measuring principle: Optical / non-contact Measuring range (X/Y): approx. 200 × 200 mm Measuring range (Z): Height measurement via autofocus Measurement accuracy: up to approx. ±2 µm (depending on measurement conditions) Nksdpfx Ajycu U Tedwot Repeatability: Very high, operator-independent Camera: High-resolution CCD camera Illumination: Incident / transmitted / contour lighting Measurement functions: - Length, angle, radius, and diameter measurement - Contour and form measurement - Pass/fail comparison (OK/NOK) - Automatic dimension recognition Software: KEYENCE IM software for rapid program creation Measurement cycle time: several seconds per part (also for multiple features) Condition: - Used - Well maintained - Fully functional - Immediately ready for operation Machine dimensions: approx. 900 x 500 x 1500 [mm] Machine weight: approx. 32 [kg] Viewing under power is possible by prior appointment. Subject to prior sale and technical modifications or errors.

Condition: used, table diameter 5600 mm table load 150 t x-travel / mm total power requirement 88 kW weight of the machine ca. 55 t Round table dm 5600 mm / 150 to load Round table dia. 5600mm / 150 to load Equipment: Table with drive motor Status: closed since 1980 Machine Type:C.T.F Diameter core face plate: 3000 mm Diameter ring faceplate: 5600 mm Core and ring faceplate can be coupled: yes Faceplate divisible into segments: no Max. workpiece weight: 150000 kg Table weight approx.: 55000 kg Dimensions: Dm 5600 x H 1500 mm filming operation Speed: 0.1 - 20 rpm Rotation levels:4 Drive power: 88 KW milling operation Speed: 0.0002 - 0.2 rpm Nodpfshmzkbox Adwjkt Peripheral speed (5000 mm): 3140 mm/min Drive power: 11 KW

Condition: used, Year of construction: 2007, table diameter 4520 mm table load 35000 kg swivelling range 110 Grad total power requirement 44 kW weight of the machine ca. / t required space / m Type: ROMAT 350 / LVEB-120000N-4m / VVEs-D-18000N-5m-S / QVEB-2m travelling beam / CR-200000N / Nksdpfxjrmulvj Adwjt Hydraulic scissor lift table In the scope of delivery: Item Designation 1 Welding power source GLC 603 Quinto SD 2 Wire drum 3 Service door 2.1 4 Robot control cabinet 5 Service door 1.2 6 Scissor lift table (shown in parking position) 7 Cross-travelling unit QVEB 8 ROMAT 350 robot 9 Service door 1.1 10 Safety fence 11 Platform 12 Positioner 13 Sliding door 1 14 Linear traversing unit LVEB 15 Vertical traversing unit VVEs 16 Sliding door 2 The disc ring on the table is a device that is not included in the scope of delivery ----- Technical data - Mechanical dimensions (without control unit and superstructures): approx.6440(57 7 0)x4520(2700)x5460(3320) LxWxH - Turntable diameter: 4520mm - Weight: approx. 25,000kg (without superstructure) - Speed range: 0.004 - 1.07 rpm - Welding current coupling: 600 A - Maximum table load capacity: 35 tons (according to load chart) Ambient temperature Storage / transport 0 to 60'C Operation +4 to 35 "C Interfaces Central transfer point for control, power supply, earth connection ----- 2.3 Linear traversing unit, LVEB Type LVEB-120000N 4m Dimensions W x D x H 7,700 x 2,440 x 776 mm Weight 4,355 kg Travelling distance 4,000 mm Load of the carriage 120,000 N Drive unit Gear motor Precision bevel gear motor Manufacturer Stöber Type K402VF0250EK703V Power 4.21 kW Voltage UKE 140 V / 1000 rpm Current Rated current IN: 8.32 A Type of current Standstill current I0: 9.04 A Motor speed 3,000 rpm Gear ratio i = 25.28 ----- 2.4 Vertical traversing unit, VVEs Type VVEs-5m Dimensions W x D x H 2,000 x 1,960 x 7,150 mm Weight 9,500 kg Travelling distance 5,000 mm Max. moving mass 18,000 N Drive unit Gear motor Bevel gear motor with brake Manufacturer Stöber Type K713VF0790MQ30ED704B Power 4.8 kW Motor speed 2,000 rpm Gear ratio i = 78.83 (20181/256) ----- 2.5 Cross-travelling unit, QVEB Type QVEB-2m Dimensions W x D x H 1,270 x 4,100 x 756 mm Weight 1,950 kg Travelling distance 2,000 mm Load on the travelling beam 10,000 N Max. moving mass 18,000 N Drive unit Gear motor Precision flat geared motor Manufacturer Stöber Type FS202VQ0145ED402U Power 1.43 kW Voltage UKE 140 V / 1000 rpm Rated current IN 2.86 A Type of current Standstill current I0: 3.1 A Motor speed 3,000 rpm Gear ratio i = 14.65 (3180/217) ----- 2.6 Rotary indexing table Type CR-200kN Manufacturer Cloos Dimensions W x D x H 1,820 x 2,120 x 541 mm Weight 2,850 kg Drive unit Gear motor Bevel gear motor Manufacturer Stöber Type K814VG1540EK803U Power 6.7 kW Motor speed 3,000 rpm Gear ratio i = 154.322 ----- 2.7 Robot ROMAT 350 Type ROMAT 350 Dimensions (W x D x H) in reference position 1,900 x 600 x 1,500 mm Weight 205 kg Footprint 500 x 515 mm N...

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 220708845GC, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 300 mm, Used demonstration machine, year of manufacture 2022 (TOP condition + fully functional) • OPTIV M 4.4.3 multisensor coordinate measuring machine (CMM) with Dual Z technology • Base frame • 10x CNC motorized zoom with digital color camera and 12-segment LED ring light • HP-S-X1C scanning sensor • 3x HP-S-X1C/H stylus holders (1x M3) Nkedoycqa Sopfx Adwjt • M3 stylus (R-5-SS-3-L50) • HR-X probe rack for HP-S-X1C/H (3 ports, l=400) • Sensor calibration unit without calibration artifacts • Glass standard • Setting ring 20 mm • Reference sphere Ø 25 mm • Measurement and evaluation software PC-DMIS CAD++ (version 2024.2) • Machine control unit (PC) • 2 monitors + mouse + keyboard + desk Delivery, commissioning, calibration on request

Condition: used, Year of construction: 2017, Absolutely as good as new Consists of 1 measuring case 12-20mm Consists of 1 measuring case 20-50mm Consists of 1 measuring case 50-100mm Nksdpfxovvxvde Adwst

Condition: used, optical angel measuring unit. Nksdpfogw Tw Rsx Adwot

Condition: used, length 400 mm width 270 mm Nkodpfjd Iha Rjx Adwot weight of the machine ca. 0,02 t dimensions of the machine ca. 0,4x0,27x0,03 m

Condition: used, table length 600 mm table width 600 mm Nedpfx Asd Ihbbedwokt table load 0 t different clamping tables, former used on a HÖFLER measuring machine! As complete package or single table available.

Condition: used, Year of construction: 1992, table length 1 mm table width 1 mm table load 1 t Nedpfxju Sbc Nj Adwskt round table plate Ø 600 mm with 3 t-slots (18/30), Slot-distance: 160 mm, with misc. clamping plates and clamping pot!

Condition: used, Year of construction: 2014, length 1200 mm width 800 mm Nodjv Ig Acepfx Adwjkt Thickness 160 mm

Condition: used, Year of construction: 2018, 5.5 kW main motor, frequency converter (2000-6000 rpm), motorized 2-axis scoring unit with its own drive. Motorized height adjustment in 0.1 mm increments. Motorized angle adjustment in 0.1° increments with digital display. 1090 x 630 mm miter gauge. Narrow and wide extraction hoods with quick-change function. Clamping shoe, sliding block, and manual quick-release clamp. Sliding carriage length 2150 mm (cutting length 2170 mm) - Quick-Scoring equipment packages - Scoring unit adjustable without tools from 2.8 to 3.6 mm - Miter gauge +45° - 45° - On/off switch on the sliding carriage. Storage location: Nattheim Nkedpfx Adjvvkm Uswet

Condition: used, Year of construction: 1991, Eye-level control panel, Aigner integral stop including feed with sliding carriage (without stop ruler), milling stop with digital display and swivel mechanism Storage location: Nattheim Nkjdpov Ai N Ujfx Adwjt

Condition: used, Year of construction: 2004, Saw unit: pivots 45°. Carriage length: 3200 mm. Maximum saw blade diameter: 450 mm. Saw blade bore: 30 mm. Motor power: 7.5 kW. Max. Cutting width: mm Control panel: at eye level Height adjustment: input via keyboard Tilt adjustment: input via keyboard Tilt angle display: digital Cutting width display: digital Table extension length: yes Cross-cutting at the cross stop: 3200 mm Cross stop display: scale Scoring device adjustment: electric Scoring blade: PSV Protective cover: yes End position lock: yes Automatic motor brake: yes Speeds: 2500/3500/5000 rpm Description: Cutting height at 450 sheets, 150 mm Weight approx.: 1180 kg Dimensions: 3200 x 1800 x 1800 mm Extraction diameter: 1 x 80, 1 x 120 mm Nsdpfxex Ngzas Adwskt Storage location: Nattheim

Condition: repair required (used), Year of construction: 1987, functionality: limited functionality, Table milling machine with 2 milling spindles Table size: 1,500 x 800 mm Extendable rail on the table, length 2,500 mm Rail extendable up to approx. 640 mm from table front edge 2 extension pieces for the rail, each L = 850 mm Spindle diameter: 30 mm Usable spindle length approx. 140 mm Spindle 1 height-adjustable with mechanical digital display Spindle 2 height- and side-adjustable, with mechanical digital displays Nkjdpeycq Aysfx Adwet Max. tool diameter approx. 180 mm Distance between spindles approx. 550 mm Milling spindle locking mechanical via lever 2 motors, each 4.5 / 5.5 kW Motors with pole-changing function Forward/reverse operation 6 spindle speeds: 3000/4000/5000/6000/8000/10000 rpm Pneumatic milling spindle braking 2 extraction ports, diameter 120 mm Connection data: 400 V, 50 Hz, 3 Ph, N Additional notes: + Spindles heat up during operation. Therefore, likely necessary to replace bearings (not included in price) + Table insert rings for milling spindles are missing.

Condition: used, Year of construction: 2019, operating hours: 100 h, functionality: fully functional, type of input current: AC, input voltage: 220 V, input frequency: 50 Hz, 1. TESSA TT20 Nodpfxowq Dp Do Adwekt 2. SENSOR

Condition: excellent (used), CATALOG NUMBER 7644 Technical Data: - Max main blade diameter with scoring unit: 350 mm - Max main blade diameter without scoring unit: 450 mm - Cutting height with mounted blade: 100 mm - Main blade adjustable hydraulically: up/down + angle Nodpfjwgdh Sex Adwskt - Electric angle display - Electric height and lateral adjustment of scoring unit - Spindle diameter: 30 mm - Spindle locking - With sliding table - Cutting length on sliding table: 2800 mm - Cutting width at fence: 1440 mm - With side carriage - With scoring unit - Max diameter of scoring blade: 120 mm - Scoring unit spindle diameter: 22 mm - Scoring unit motor: 0.75 kW - Main motor: 5.5 kW - 4 spindle rotation speeds - Electronic speed display - Extraction port diameters: 120 mm, 80 mm - Table dimensions: 1220 x 730 mm - Table dimensions with extension: 1230 mm - Table dimensions with extension: 2070 mm - Saw blade guard - Dimensions (L/W/H): 2940 x 3400 x 1420 mm - Weight: 1100 kg ADVANTAGES – German-made – With scoring unit – Not repainted – Used saw, in very good condition Net price: 29,900 PLN Net price: 7,120 EUR Net price calculated at an exchange rate of 4.2 PLN/EUR (In case of significant exchange rate changes, the price may change)

Condition: excellent (used), Year of construction: 2014, I sell the format sliding table saw without scoring KUSING FPn MINI 1000 Year 2014. Sliding table length 1000mm / cutting length 1200mm. Max. cutting width on cross fence 1950 / 2850mm. Max. cutting width on parallel fence 1270mm. Motor 4,0 kW (5,5 HP). Max. saw blade diameter fi.300x30mm Main blade 4000 rpm. Saw aggregate tilting 0-45° EU-Product. Made in Slovakia. Fully working, including CE and full Documentation. Condition very good. Avialable immediately. Nsdpfeyc N Dcsx Adwokt

Condition: excellent (used), For sale: a complete set of professional measuring stations from the renowned German brand ULTRA Germany, models: • ART. 27484-032 – POS. 12 • ART. 27484-033 – POS. 10 • ART. 27484-030 – POS. 8. The devices are designed for precise positioning, inspection, and calibration of mechanical and measuring components in production and quality control processes. An ideal solution for measurement laboratories, quality departments, research centers, or tool shops requiring high repeatability and accuracy. • Construction made of high-quality steel and aluminum – robust, stable, and durable • Precision linear guides ensure smooth movement and high measurement accuracy • Height adjustment and holder locking for quick adaptation to the tested component • Capability to mount dial indicators, holders, and other measuring accessories • A reliable solution for series measurements and part positioning in production processes. Condition: used, in very good technical and visual condition – devices are fully functional, sourced from a quality control department. Price refers to Nsdsxltn Ajpfx Adwekt

Condition: excellent (used), For sale: CNC rotary table from the renowned brand Fadal Engineering (USA), model VH65. Professional 4th axis designed for machining centers, especially Fadal VMC, but integration with other CNC machines is also possible using the appropriate controller. Technical specifications: • Model: VH65 • Table diameter: 165 mm (6.5”) • Gear ratio: 90:1 • Pneumatic brake (M60 ON / M61 OFF) • Industrial multipin connector • Serial no.: 4630298 Condition: used, mechanically functional, normal signs of operation. Solid and heavy construction – ideal for precise 4-axis machining. Nkedpfx Asw R St Nedwet

Condition: excellent (used), – Mitutoyo dial test indicator, model 513 454 – accuracy 0.01 mm – lever type (test indicator) – antimagnetic version – Made in Japan – Mitutoyo magnetic base – model 7011SN Nsdpfx Adew Rdi Aewskt – ON/OFF lock – robust, stable, with precise clamping mechanism – Made in Brazil – The set is fully functional. Stable guidance and precise readings. – Ideal for tool setup, run-out checking, and inspection measurements.

Condition: good (used), I am selling a WTW PH96 meter in good condition. Nedpfjvdxu Njx Adwjkt

Condition: excellent (used), For sale: a robust measuring device from the renowned German manufacturer AbaWerk Aschaffenburg. Made with a cast iron base and equipped with two hardened centering points for securing shafts and cylindrical workpieces. Perfect for use with toolmaker’s microscopes, measuring projectors, and in quality control applications. Technical specifications: • Manufacturer: AbaWerk Aschaffenburg (Made in Germany) • Center distance: approx. 115 mm • Stable, heavy cast iron base – secure clamping • Allows rotation of the workpiece between centers • Condition: used, fully functional Nksdpfx Ajw Sav Iodwst Manufactured to industrial standards – precision and durability make these units highly sought after in metrology and toolmaking environments.

Condition: excellent (used), For sale: robust mounting plate/machine table with T-slots. Constructed from thick-walled steel, painted blue. Excellent base for installing large components, fixtures, or for measuring and machining applications. Nkodpjw Rdtuofx Adwet • Dimensions: 2570 x 770 x 200 mm • Surface with T-slots • Precisely machined top section • Weight: 900 kg • Can be transported or loaded by forklift

Condition: excellent (used), For sale: Professional digital height gauge Mitutoyo (model 192-613) – Japanese precision and reliability in a single device. Ideal for workshops, quality control, and precise measurements. Specification: • Measuring range: 0–300 mm • LCD display – clear readings even in low light • Functions: ZERO/ABS, PRESET, HOLD Nksdpfx Asw N Hn Sodwst • Power supply: CR2032 battery • Stable base ensuring secure support and accurate measurement • Original – Made in Japan Condition: Device is fully functional and well maintained,

Condition: good (used), For sale: PWB Swiss measuring device, model TOOL MASTER 310 Very good condition, complete, ready for operation Package includes: • TMA 21 control panel • LED displays • Dial gauge Nkodow Humlepfx Adwjt • Measuring socket for holders Features: • X and Z axis measurement • Tool setting and calibration for CNC tools • Easy operation • Length and diameter measurement Original user manual included Brand: PWB Swiss Model: Tool Master 310
