Used Start Hole for sale (11,149)

Year of construction: 2013, condition: used, controller manufacturer: Siemens, controller model: 840Dsl, _____ Description: Year of manuf. : 2013 In general: Drilling-ø (max.):3,5 mm Drilling depth (max.):200 mm Knjdpfx Aajx E Ingsnef Deep drilling module: Technology:Drillingspindle Speed (max.):10.000 rpm Power:3,5 kW Taper:HSK-A40 Equipment/Accessory: Chipmanagement:Chip tray Coolingmanagement:Internal cooling unit with Filter and High-pressure, 140 bar Workpiececlamping:Collet chuck, SMW Autoblok KSZ-MB-040-Z140 Oilmistseparation:Electrostatic extraction, LTA AC 500 Further Accessory:Misc. Single lip driller

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 620x560x1720 mm Weight 110 kg Total power requirement 0 kw Kjdpev A Hm Rjfx Aanjnf

Condition: used, Year of construction: 2000, Number of spindles in row: 11 Number of horizontal spindles: 3 Knedpfx Aoxc Hi Ueanjf Cup hinge boring head: yes, Blum Drill pitch: 32mm Power consumption: 2.2kW Drilling unit: swiveling

Condition: used, Scheer Type DB 5 dowel hole drilling machine for precise and fast drilling of dowel holes (horizontal and vertical) in solid wood and panel materials. The machine is ideal for series production in furniture construction as well as for precise joints in interior design. Includes a comprehensive range of dowel drill bits. drilling spindles: 21 division: 32 mm Kodpswp E Uxofx Aanenf passage width: max. 1.000 mm Pivot: pneumatic

Condition: used, Year of construction: 1984, Row and Fitting Boring Machine Used machine Kedoxdpkdopfx Aansnf Year of manufacture: 1984 Condition: Function-tested Technical data: Fully automatic pneumatic control with foot pedal Boring unit 1.1 kW Speed 2800 rpm Boring stroke 0–55 mm Stop ruler cross adjustable from 0–140 mm Working height 850 mm Space requirement without extension rail 1000 x 750 mm Compressed air connection 6 bar Weight approx. 70 kg Includes various stops, boring heads, and drills Location: Flörsheim Availability: Immediate

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 2,000 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm Workpiece Length : 50 – 2.000 mm Centre Hole Diameter : ø 1 – 100 mm Workpiece Weight : max. 170 kg Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Knjdpfjxrnchex Aanef Dust Extraction And Filtration : Available (as a option) Grinding Process : Manual Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex M-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex M-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Contact us for more details.

Condition: good (used), Year of construction: 2009, Deep Hole Drilling Machine Mollart MicroDrill VDM Workpiece diameter (center drilling): up to 10 mm with manual loading Eccentric drilling diameter: 2 to 300 mm with manual loading Materials: Steel and other metals except magnesium or its alloys Tool data – drilling diameter: 0.70 to 6.00 mm with 4 spindles, or 6.00 to 8.00 mm with 2 spindles Maximum drilling depth: 180 mm Number of main spindles: 4 Main spindle speed: 2,500 to 25,000 rpm or 600 to 7,500 rpm Main spindle power: 0.85 kW at 100% duty cycle Operating pressure of drilling oil pump: 0 to 40 bar Oil tank capacity: approx. 650 l Oil mist extraction capacity: approx. 430 m³/h Year of manufacture: 2009 Total machine power supply: 25 A The microdrill Mollart VDM is a high-precision deep hole drilling machine for ultra-fine drilling in steel and other metallic materials. Thanks to its four powerful main spindles, the machine enables drilling diameters starting from 0.70 mm and depths up to 300 mm, making it ideal for demanding micro-drilling applications. Spindle speeds of up to 25,000 rpm ensure excellent machining quality, while the integrated high-pressure drilling oil pump with up to 40 bar provides optimal lubrication and chip removal. The large 650-liter oil tank and high-performance oil mist extraction system ensure stable and clean operation. The machine is equipped with a Siemens SIMATIC control interface, which allows for precise and user-friendly operation. With its robust construction, high reliability, and extremely fine machining accuracy, the microdrill Mollart VDM is ideal for companies manufacturing precision components in the micro range. Knedpfsx Eml Rox Aanef No guarantee is given for the correctness, completeness, or topicality of the information provided.

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 570x490x1720 mm Weight 90 kg Kjdsv A Hm Djpfx Aanjnf Total power requirement 1 kw

Condition: used, Year of construction: 1992, Number of spindles per row of holes: 16 Number of horizontal spindles: 5 Cup hinge drilling head: yes Drill pitch: 32 mm Hold-down device: yes / pneumatic Kedpfx Aswv Nb Nsanonf Power consumption: 2.2 kW Drilling unit: swivelling

Condition: used, Year of construction: 1983, functionality: fully functional, machine/vehicle number: M02-4-320, Deep hole drilling machine Kjdpfxjx Ezllj Aanonf For technical data, please refer to the attached images

Condition: used, Year of construction: 1974, operating hours: 10,000 h, functionality: fully functional, machine/vehicle number: 8002/6410, drilling depth: 1,000 mm, drill diameter: 30 mm, type of input current: three-phase, spindle motor power: 21 W, table length: 1,000 mm, input voltage: 550 V, mount diameter: 160 mm, number of spindles: 1, drilling capacity: 1,000 mm, quill diameter: 30 mm, Equipment: rotational speed infinitely variable, Deep hole drilling machine for up to 1000 mm and 30 mm diameter, used for drilling aluminium, regularly serviced, includes a significant quantity of drills. Machine is fully operational and in continuous use. Siemens control, Simatic PANEL, documentation available. Kjdpfx Aasx Ehg Tjnenf

Condition: good (used), Year of construction: 1992, Hydr.hole punching machine make häwa year 1992 Kedegbk R Uspfx Aanenf working pressure.400bar with electric height adjustable supporting table Machine ready for use .

Condition: used, Year of construction: 2016, Used Makor START ONE spray coating machine suitable for low-volume woodworking production. Designed for applying water-based or solvent-based paints and glues to veneered components and PVC panels. Ideal for companies moving from manual finishing to automatic spray coating. Knedjx Iggyopfx Aanef Equipped with PLC control system with intuitive interface and automatic panel detection to optimise paint usage. Features a self-cleaning paper transport system, reducing maintenance and downtime. Spraying unit includes an electronically controlled oscillating arm with capacity for up to 4 spray guns, 2 high-pressure feed circuits, and quick-change coupling system. Efficient air-flow and filtration system ensures clean operation and environmental compliance. Technical Data: • Feed speed: 1–4.5 m/min • Air capacity: 10,000 m³/h • Installed power: 7 kW • Working height: approx. 900 mm

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2800x1100x2200 mm Weight 1100 kg Total power requirement 8,8 kw Ksdpfovz Hwasx Aanjnf Horizontal and vertical drilling machine MULTI MZ3x8 - Max. Center Distance Between Holes 2440(L)mm x 300(W) mm- Min. Center Distance Between Holes 220(L)mm x 32(W) mm - cess length 2440 mm - cess length 220 mm - Plate thickness 12~40 mm - Total number of drilling bit 32pcs - Horizontal backside drilling rows 4 rows - Max. drilling dia. 35 mm(Single bit) and 13 mm (Multi)- Max. drilling depth 50 mm - Dia. of drilling bit shaft 10 mm - Length of drilling bit 57 mm/70 mm - Drilling bit speed 2840 rpm - Qty of horizontal L&R drilling rows 2 rows - Qty of vertical up drilling rows 2 rows - Air pressure 0.5~0.6 Mpa - Total power 8.8 kw - Net weight 1100 kg - Overall dimension 2800 x 1100 x 2200 mm

Condition: good (used), Year of construction: 1990, machine/vehicle number: X0006, Offer 25364 Technical Data: - Punching force: 200 kN - Max. sheet thickness: 6 mm - Max. punching diameter: 90 mm - Stroke: 42 mm - Throat depth: 400 mm - Maximum strokes per minute: 200 spm - Installation height: mm - Drive: 400 V / 3 kW Knodex I Nc Repfx Aansf - Required space approx.: W 1000 x H 1650 x D 1200 mm - Weight approx.: 1400 kg - Including: positioning table, quick-change punch device, foot switch, emergency stop switch, various punches and dies The machine can be inspected by appointment at the 63322 Rödermark site. Company Erich Mieth: Tel. 06074-90877 Monday - Friday: 9:00 am - 12:00 pm and 2:00 pm - 5:00 pm The price includes 19% VAT. You will receive an invoice with VAT shown separately. Sale to commercial customers only. Payment by bank transfer before collection of the machine.

Condition: good (used), Year of construction: 2008, IXION TL 1001 CNC Deep Hole Drilling Machine with Equipment Year of manufacture: 2008 Control system: MITSUBISHI M530 Machine number: 950521 Drilling depth (Z), CNC controlled: 1,000 mm Drilling unit (Y), vertically traversable: 800 mm Table size: 1,200 mm x 700 mm Table load: 3,000 kg Table longitudinal travel (X): 1,000 mm Table displacement (W): 1,000 mm Table rotatable by 360° Spindle: SK 40 Spindle speed: 100 – 4,000 rpm Max. drilling capacity in steel: 25 mm Max. thread cutting in steel: M20 Milling in steel possible Weight: approx. 3,500 kg Equipment: Compact belt filter KBF Electronic handwheel Coolant system Chip conveyor KBF 270 P50 Included in delivery: Deep hole drilling tools Workplace with: Holders / mounting brackets / supports / sealing discs Operating manual/documentation Machine parameters on storage medium For equipment, technical data, installation & transport – see PDF. Image, content, and details are provided without guarantee and therefore not binding. All additional accessories visible in the photos and video are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery includes only the accessories explicitly listed here, in the order confirmation and invoice. FCA (Free Carrier, loaded on truck) D-04643 Geithain packaging only Ksdpfxox Hv D Eo Aanonf Lead time: immediately Subject to prior sale / Payment due immediately upon purchase

Condition: good (used), Raimann branch patching machine with glue application Kodpsvrfl Rsfx Aanjnf Type A10 Year of manufacture 1994 Working method: Milling out the branch hole with a branch drill Milling out the repair piece from the strip with a plug cutter Pressing in the repair patch with glue application Number of units 1 piece Maximum tool diameter of strip magazine 35 mm Min. tool diameter of strip magazine 18 mm Maximum tool diameter of plug magazine 30 mm Min. tool diameter of plug magazine 15 mm Maximum workpiece height 200 mm Maximum drilling, milling and punching depth 22 mm Minimum drilling, milling and punching depth 2.5 mm Performance (number of work cycles) 18 pieces/min. Working height 815 – 955 mm Projection from stand to tool 710 mm Drive motor 2.2 kW Glue tank size 5 liters Compressed air 6 bar Weight approx. 1100 kg

Condition: used, Year of construction: 2016, machine/vehicle number: M99955/3533513, Pipe Cutting Machine FZH VARIO 2 with 2.9m Magazine (Year 2016) Automatic pipe cutting line VARIO 2 by FZH Maschinenbau GmbH, manufactured in 2016. This line is designed for the cutting to length of round pipes and has been used in serial production of furniture fittings. The system comprises a magazine with singling system, feed unit, pipe cutting head, as well as extraction and deburring unit. Application areas: – Automatic cutting of round pipes in series production – Pipe diameter approx. Ø 6.0–78.0 mm – Wall thickness approx. 0.1–1.5 mm (plastics up to approx. 2.0 mm) Knjdpfsx Hqd Tjx Aanjf – Cut lengths from approx. 70 mm, with typical lengths from 200–1,200 mm – Suitable for steel pipes (e.g., E195) and various other pipe materials Machine basic data (extract from manufacturer documentation): – Pipe diameter (outside): Ø 6.0 mm to 78.0 mm – Wall thickness: 0.1–1.5 mm (plastics up to 2.0 mm) – Cut lengths: 70–700 mm in one feed cycle, longer lengths by repositioning – Minimum cut length: 70 mm – Shortest scrap length: 150 mm – Pipe input: by the meter or from coil – Cycle time for cutting only: approx. 4 s (material dependent) – Feed time for 200 mm pipe length: approx. 2 s – Feed time for 500 mm pipe length: approx. 5 s – Feed time for 1,200 mm pipe length: approx. 16 s Condition / maintenance: – Well-maintained used condition from family business – System was regularly serviced – Technical documents (offer, layout drawing, specifications) available – Photos of the complete line including magazine and deburring unit available Inspection possible by appointment. Dismantling and loading can be organized in coordination with the buyer.

Condition: as good as new (ex-display), machine/vehicle number: G-V7-LBM2200-2S-RL-400-Schweiz, Exhibition machine Hans Schreiner long hole drilling machine with one-hand operation. Optimum work thanks to fixed table and movable drill head. Standard with left/right rotation, dowel drilling device and 2-speed motor including tool compartment, eccentric clamp, miter stop Technical data: Motor output 3.8 kW Voltage 400 V Table size 570 x 300 mm Max. drilling depth 150 mm Side travel 290 mm Height adjustment 140 mm Kedpfsvw Edqox Aanjnf Dowel drilling device 16, 20, 22, 25 mm hole spacing Max. drill holder 20 mm Speeds 1400/2800 rpm Weight 140 kg Suction connection 100 mm Packaging dimensions 855 x 600 x 1160 mm Prices subject to change, errors, printing and typesetting errors reserved

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1050x1050x110 mm Kodpfx Aaovz Er Ajnjnf Weight 350 kg Total power requirement 1,5 kw

Year of construction: 2020, condition: as good as new (ex-display), electrode diameter 0,5 to 3mm travels 300x400x350mm ) CE-cretification verifies the best possible safty all Machines in over-floor construction Kjdpfx Aasf Hmn Aensnf Elektrode Ø 0,5-3mm Travel X-Axis 300mm Travel Y-Axis 400mm Travel Z-Axis 350mm Travel W-Axis 300mm Speed W Axis 30-60mm/min Rapid feed Z-Axis 120mm/min removal rate (max.) 300:1 Table dimension 320x440mm max.generator capacity 30A

Condition: good (used), Year of construction: 2004, NAGEL/TBT BW-30-3000 Deep Hole Drilling Machine Year of manufacture: 2004 Control: SIEMENS SINUMERIK 840D Drilling depth up to 3,000 mm Drilling diameter max. 27 mm / min. 16 mm Axes: 3 Max. feed: 140 mm/min Table X-axis: 950 mm Working area in X-axis: 900 mm Working area in Z-axis: 1,750 mm Coolant capacity: 2,400 l Table load capacity: 4,000 kg Cooling system type: KA-1 Table size: 3,300 mm x 950 mm Feed rate up to 7,000 mm/min Power: N = 7.5 kW Speed: 650 – 6,500 rpm Automatic central lubrication Hydraulic drive for drill guide bush Magnetic chip conveyors Knedjx Hwhljpfx Aanjf All other accessories visible in the photos and video are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery includes only those accessories which are expressly listed here, in the order confirmation, and in the invoice. FCA (Free Carrier – Loaded on Truck) D-95447 Bayreuth Packaging only Delivery time: immediate Subject to prior sale / Payment due immediately upon conclusion of sale

Condition: used, Year of construction: 2017, Number of drilling spindles: 21 pcsPitch: 32 mmDrill chuck: Clamping surface of drill shank: 10 mmOperation: foot pedalTools included: yesDrilling direction: from below & end faceTilting: manualTilting angle: only 0° or 90°Max. pass-through height: 80 mmMax. pass-through width: 750 mmNumber of material clamps: 3 pcsType of material clamping: pneumaticDesign: stationaryStop system: only for structural seriesWeight approx.: 400 kgMotor power: 1.5 kWDust extraction diameter: 120 mmStorage location: with customer Knedpfx Asihghrsanof

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1300x1100x1350 mm Weight 500 kg Knedpsvz Eizsfx Aanjf Total power requirement 3,5 kw

Condition: used, Year of construction: 2022, New demonstration machine! List price: €13,610.- 400V, 3Ph, 50Hz / 1.5 kW complete in standard configuration with: Fully automatic electronic control with impulse operation via foot pedal for clamping-drilling-unclamping, automatic electrical return of the drilling unit once the set drilling depth has been reached, automatic adjustment for increased drill depth when end-faced drilling saves need to reset the depth for surface to edge drilling operations (+10 mm; e.g., for dowel length 35 mm, surface depth 14 mm and edge depth 24 mm). 1 drilling beam with 21 spindles, 32 mm center distance, 1.5 kW motor (drill feed 0-70 mm). Incl. 21 quick-change chucks (Ganner system) for easy bit exchange; multi-position swivel drilling unit from 0° to 90°, supported by gas spring. 1 clamp carrier, movable along the Y-axis with 3 pneumatic clamps, for workpiece height up to max. 80 mm. Comprehensive stop system includes: 1 1800 mm stop rail for shelf drilling (aluminum profile 40x40 mm) with 3 locator stops, quick-change system, easily switchable from right to left side for mirrored shelf drilling in cabinet construction; also usable for line boring in System 32. Limit stops and position settings as well as drilling height position over the support table with mechanical digital stop. Stops can be easily swung away for the quickest changeover from cabinet to frame and arm extensions for clamp carrier executed for line boring positions up to max. 300 mm. Ideal three-stage tool system. 1 set of dowel drills: 5 carbide dowel drills, Ø 8x77 mm, right; 4 carbide dowel drills, Ø 8x77 mm, left. Additional features: Extraction funnel, dust-tested, Ø 120 mm. Set for line boring in System 32 complete with: 2 guides with scale and adapter for position max. 300 mm, 2 pairs of locator cams for line boring for Y-position 37 mm and e.g. 300 mm, 1 base rail 1000 mm (aluminum profile 40x40 mm), 1 setting gauge for line boring. 1 set of drills: 11 carbide line boring drills, Ø 5x57 mm, right; 10 carbide line boring drills, Ø 5x57 mm, left. Hydraulic brake cylinder. Clamping cylinder with holder, additional. Location: Ksdpfx Aajqw Ek Ienjnf
