Used wire EDMs with x-travel of 500-699mm for sale (77)

Condition: used, Year of construction: 1998, Sodick AM 35 CNC EDM Machine Model: AM 35 Year: 1998 Control: Neuro Fuzzy II 40: ‘X’ axis Travel: 350mm ‘Y’ axis Travel: 250mm ‘Z’ axis Travel: 250mm Tank Dimensions: W 790 x D 590 x H 320mm Lhedpfxjwqgh Ae Adwsb Max. electrode weight: 50 kg Max. Table Load: 550 kg With: Magnetic chuck 350 x 250mm

Condition: used, Year of construction: 2015, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, Travel: X 600 / Y 400 / Z 310; Water bath machine; Automatic wire threading; Chiller. Lhedpfsx Hgg Dsx Adwob

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 0044, workpiece weight (max.): 200 kg, travel distance X-axis: 1,800 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,100 mm, total height: 2,455 mm, total length: 3,000 mm, total width: 3,760 mm, workpiece height (max.): 250 mm, workpiece width (max.): 750 mm, workpiece length (max.): 550 mm, type of input current: three-phase, overall weight: 3,700 kg, feed length X-axis: 350 mm, feed length Y-axis: 250 mm, feed length Z-axis: 256 mm, Equipment: cooling unit, documentation/manual, Wire EDM system GF AgieCharmilles CUT 2000 with loading robot Power on time: 91,716 h Operating hours: 17,889 h The system consists of a CNC wire EDM machine GF AgieCharmilles CUT 2000 with integrated automation/loading robot (WorkPartner) and is ideally suited for precise series and single-part production. Lhodpfox S Ehkex Adwob The CUT 2000 is designed for highly accurate contour cutting with excellent surface quality and stable process control. It features the Vision-5 control unit (Windows XP), automatic wire threading system, integrated dielectric unit, and coaxial flushing, enabling reliable, low-manned operation. The loading robot (GF WorkPartner) transforms the machine into an automated production cell. Depending on the magazine version, workpieces weighing approximately 400 to 800 kg in total can be handled. Automatic loading and unloading allow for extended run times without operator intervention and significantly increase productivity.

Condition: ready for operation (used), Year of construction: 2021, operating hours: 11,537 h, functionality: fully functional, workpiece weight (max.): 1,000 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 350 mm, workpiece length (max.): 1,030 mm, Wire EDM machine from 2021 with only 11,537 operating hours! TECHNICAL DETAILS Travel Distances X-axis travel: 600 mm Y-axis travel: 400 mm Z-axis travel: 350 mm Workpiece Data Workpiece weight: 1,000 kg Workpiece height: max. 350 mm Workpiece width: max. 800 mm Workpiece length: max. 1,030 mm Table Data Table width: 630 mm Table length: 950 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,400 x 2,160 x 2,320 mm Overall weight: 5,440 kg EDM hours: 11,537 h Power-on hours: 29,381 h Type of mains supply: 3-phase current EQUIPMENT Manual central lubrication for CUT E series Heat exchanger kit Large wire spool accommodation 25 kg, CUT E series Wire chopper for CUT E series Signal lamp Lhsdpfsx I Akuex Adwob Note: Dismantling and loading can be carried out by the seller at an additional cost.

Condition: excellent (used), Year of construction: 2015, operating hours: 5,090 h, functionality: fully functional, machine/vehicle number: T0298, workpiece weight (max.): 850 kg, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 250 mm, workpiece height (max.): 245 mm, workpiece length (max.): 670 mm, type of input current: three-phase, table width: 960 mm, input frequency: 50 Hz, Equipment: cooling unit, The Sodick VZ500L is a wire-cut EDM (Electrical Discharge Machining) machine from Sodick, designed for electro-erosive machining of metals. This is a wire-type machine equipped with linear drives, enabling precise cutting of intricate shapes at an angle based on CAD files (e.g., DXF, STEP, IGES). Main features: Type: Wire-cut EDM Manufacturer: Sodick Model: VZ500L Drives: Linear Working range (X x Y x Z): 500mm 350mm 250mm Maximum workpiece dimensions: 960mm 670mm 245mm Maximum workpiece weight: 850 kg Capabilities: Angular wire cutting (based on 3D models) Ledpfex Ekcyox Adwjhb Additional features: Automatic wire feeding (AWF) Immersion in dielectric fluid

Condition: excellent (used), Year of construction: 2019, operating hours: 4,247 h, functionality: fully functional, machine/vehicle number: T1284, workpiece weight (max.): 1,500 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 370 mm, total height: 2,570 mm, total length: 1,852 mm, total width: 2,825 mm, workpiece height (max.): 400 mm, workpiece width (max.): 750 mm, workpiece length (max.): 550 mm, type of input current: three-phase, table width: 750 mm, overall weight: 5,350 kg, table length: 550 mm, table height: 400 mm, empty load weight: 5,350 kg, table load: 1,500 kg, input voltage: 400 V, input frequency: 50 Hz, The Sodick AG60L die-sinking EDM was manufactured in 2019. It features a ceramic table measuring 750 x 550 mm and can handle a maximum workpiece weight of 1,500 kg. The machine is equipped with a linear motor, glass scales, and a remote control unit, which enhance both precision and operator convenience. We invite you to purchase the Sodick AG60L die-sinking EDM. Please contact us for further details about this machine. Axis travel (X/Y/Z): 600 / 420 / 370 mm Lhsdpjx Ekb Nsfx Adwsb Equipment includes: replaceable paper filter, SEC-10 (C-axis), SGF2 Nano Wear Unit, fire extinguisher, TMM3 Power Generator, dielectric cooling unit, 15" TFT touchscreen, linear motors (X, Y, Z axes), glass scales (X, Y, Z axes), ceramic work area, remote control. Machine dimensions (LxWxH): 1852 x 2825 x 2570 mm / Machine weight: 5,350 kg Max. workpiece weight: 1,500 kg / Ceramic table size (W x D): 750 x 550 mm Distance floor-to-table: 850 mm / Max. electrode weight: 50 kg Dielectric fluid level (min-max): 150 – 400 mm / Dielectric capacity: 465 liters

Condition: new, The Neospark T 500 is an advanced Wire Cut EDM machine from the renowned brand KNUTH, known for its precision and efficiency in electrical discharge machining. This high-performance machine is ideal for companies specializing in mold and tool making, providing exceptional cutting capabilities for electrically conductive materials, especially when separating 3-D printed components from their base plates. The Neospark T features a rigid cast-iron frame with precision-machined surfaces, ensuring permanent mechanical precision through its advanced linear guides and preloaded ballscrews on all axes. Operating costs are notably low thanks to its cost-effective design, while the user-oriented IPC-based 4-axis control system enhances process reliability. Moreover, it includes a specialized aluminum cutting function that extends wire life and minimizes the risk of breakage during machining. With features like a central lubrication system, easy setup via handheld controls, and integrated CAD/CAM software, the Neospark T 500 is a robust choice for professionals seeking efficient and reliable Wire Cut EDM solutions. To explore this product further, request a quote today. Lodpfx Aswt Du Sjdwshb

Condition: not inspected (used), Year of construction: 1996, functionality: unexamined, machine/vehicle number: 6.0138, travel distance X-axis: 630 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 462 mm, table load: 800 kg, controller model: CHARMILLES ROBOFIL 6020 SI, No minimum price – guaranteed sale to the highest bidder! This machine is being auctioned due to the closure of a business. Bidding commits you to timely collection between 26.01.2026 and 29.01.2026! TECHNICAL DETAILS Travel Paths Travel X-axis: 630 mm Travel Y-axis: 400 mm Lhedpfx Asxqalljdwsb Travel Z-axis: 462 mm Travel U-axis: ±50 mm Travel V-axis: ±50 mm Workpiece Max. workpiece dimensions: 1,260 x 685 mm Max. workpiece height (immersed): 200 mm Max. load capacity: 800 kg Max. workpiece height between feedthroughs: 360 mm Measuring resolution: 0.5 µm Maximum manual speed: 15 mm/s Wire unwind speed Tension, taper offset Maximum workpiece height for wire threading: 300 mm Work tank dimensions: 1,355 x 760 x 425 mm MACHINE DETAILS Control: CHARMILLES ROBOFIL 6020 SI Dimensions & Weight Dimensions (L x W x H): 4,500 x 2,700 x 2,900 mm Weight: 4,000 kg Electrical Details Operating voltage: 380/400 V Frequency: 50 Hz Rated current: 18 A EQUIPMENT Includes matching workshop drawer cabinet with accessories and documentation

Year of construction: 2000, condition: ready for operation (used), Cutting Erosion Machine MAKINO EU 64 X=600 mm Y=400 mm Z=260 mm workpiece dimensions WxDxH max 940x650x260 mm Ljdpfxsgwp Eqo Adwjhb Workpiece weight max 1500 kg Service due before commissioning !!! Current service report from Makino can be sent on request

Condition: ready for operation (used), Year of construction: 1988, Control: FANUC Lodpfsxx Uatsx Adwjhb Travel: X= 500, Y= 350, Z= 300 mm Max. table load: 350 kg Dimensions: 3500 x 2400 x 2400 mm Weight: 3,000 kg

Condition: used, Year of construction: 2013, operating hours: 47,754 h, functionality: fully functional, machine/vehicle number: 52DR2077, workpiece weight (max.): 1,500 kg, travel distance X-axis: 620 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 300 mm, Equipment: documentation/manual, For sale is a used Mitsubishi MV2400R wire EDM machine in good, well-maintained condition. The machine is well preserved and has been handled with care. Lhjdpfjx Iukmjx Adwob

Condition: good (used), Year of construction: 2013, functionality: fully functional, machine/vehicle number: 03DR2150, workpiece weight (max.): 1,500 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, total height: 2,150 mm, total length: 2,687 mm, total width: 3,030 mm, overall weight: 3,500 kg, Equipment: cooling unit, Wire-Cut EDM Machine The machine comes from productive operation and is in fully functional, used condition. All relevant assemblies are complete; the generator cabinet, control system, wire feed, and AT system (Automatic Threader) are all present and complete. Running times according to control system: Processing time: approx. 29,062 h NC on-time: approx. 43,836 h Ready-/TFT downtime: approx. 8,966 h Maintenance records (excerpt): Filter change: last performed at 176 h / 200 h Resin change: 21 h / 1000 h Oil refill: 742 h / 1000 h Conductivity sensor: 742 h / 1000 h Current supply rotation: 57 h / 80 h The machine is complete but shows typical signs of use after more than 10 years in operation Accessories are extensive and well organized Servicing always confirmed as per control system Automatic threading system included Accessories / Equipment: Original Mitsubishi nozzle & roller/bearing kit: various guide rollers upper and lower diamond guides nozzle set (upper/lower nozzle) drying stones / assembly tools NSK/Japan replacement bearings spare tension rollers Manufacturer’s wooden box Mitsubishi Electric Spare and consumables: resin container (packed) Ledpfx Aox Hadvedwjhb filter elements quick adhesive components A/B pH test strips process chemicals (for EDM) logbook / maintenance records Documentation / manuals: complete folders: Operator’s Manual MV Part 1 & 2 training materials “Advance Series” operating instructions (German) maintenance and AT maintenance sheets Travels (X / Y / Z): 600 × 400 × 310 mm Working table / workspace: table size: 840 × 640 mm (square table) max. workpiece dimensions: 1050 × 800 × 295 mm max. workpiece weight: 1,500 kg Wire data: wire diameter: 0.1–0.3 mm max. wire feed: 23 m/min tension: 0.5–25 N automatic threading (AT), including fine-threading Taper cutting: opto-linear T/C device, ±75 mm (X/Y), max. taper angle 15° at 260 mm workpiece height Generator / Control system: transistor-controlled pulse generator 15" LCD touch control 6-axis simultaneous control integrated 2D and 3D CAM (Parasolid viewer) NC memory up to 1 GB USB interfaces (2×) Dielectric system tank capacity: 860 l filter flow rate: 50 l/min paper filters (2 pcs) resin container 10 l (ion exchanger)

Condition: excellent (used), Year of construction: 2017, operating hours: 8,500 h, functionality: fully functional, workpiece weight (max.): 1,500 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, total height: 2,150 mm, total length: 2,687 mm, total width: 3,030 mm, workpiece height (max.): 305 mm, workpiece width (max.): 1,050 mm, workpiece length (max.): 820 mm, type of input current: AC, table width: 840 mm, overall weight: 3,500 kg, table length: 640 mm, positioning accuracy: 0.003 mm, ### Price heavily reduced ### This machine is very well maintained and in very good condition. The machine is still in production. You can view and test this machine with power on. Price is ex works, without dismantling. Manufacturer: Mitsubishi Electronic Year of manufacture: 2017 MODEL: MV 2400R MV-R Series – Power for Precision Production hours: approx. 8,000 hours Application type: EDM / wire cutting Machine type: Wire EDM machine Technical specifications - Mitsubishi MV 2400R X-axis movement: 600 mm Y-axis movement: 400 mm Z-axis movement: 310 mm Travel (X / Y / Z) in mm: 600 / 400 / 310 Travel (U / V) in mm: 150 / 150 (+/- 75) Max. workpiece dimensions (W x D x H) in mm: 1050 x 820 x 305 Max. workpiece weight in kg: 1500 Table dimensions (W x D) in mm: 840 x 640 Overall dimensions (W x D x H) in mm: 2687 x 3030 x 2150 Machine weight in kg: 3500 Price greatly reduced. Lhodevq Rh Uepfx Adwjb

Condition: refurbished (used), Year of construction: 2013, functionality: fully functional, workpiece weight (max.): 1,500 kg, travel distance X-axis: 550 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 400 mm, total height: 2,340 mm, total length: 2,600 mm, total width: 2,600 mm, workpiece height (max.): 400 mm, workpiece width (max.): 700 mm, workpiece length (max.): 1,200 mm, overall weight: 3,300 kg, warranty duration: 6 months, GF AgieCharmilles CUT 300 Year of manufacture: 2013 Charmilles Millenium Control Travel paths (X / Y / Z): 550 x 350 x 400 mm Travel paths (U / V): 550 x 350 mm Maximum taper angle: +/- 30° at 400 mm height Integrated Collision Protection (ICP) on all 5 axes Manual tank door (accessible from one side) Maximum workpiece dimensions: 1200 x 700 x 400 mm Maximum workpiece weight: 1,500 kg Cutting speed: 340 mm²/min Best surface finish: Ra 0.10 µm Available wire diameters: 0.15 to 0.33 mm Lhsdpexwktmjfx Adwob Dimensions of the complete unit: 2600 x 2600 x 2340 mm Total weight of the unit: 3,300 kg The machine will be cleaned, fully overhauled, and functionally tested by us after the order is received. You will receive a 6-month warranty on the machine. We are happy to offer you commissioning of the machine.

Condition: excellent (used), Year of construction: 2017, operating hours: 7,700 h, X travel 600 mm Y travel 400 mm Z travel 350 mm U travel 150 mm V travel150 mm Max. workpiece weight 1 000 kgs Size of working area (L × W) 1 050 × 710 mm Wire dia 0,1 ‒ 0,3 mm (optional 0,05 mm is still possible) Range of wire tension ~3 ‒ 23 N Max. wire speed cca. 420 mm / s Dimensions (L × W × H) cca.. 2 575 × 2 945 × 2 345 mm Lhodpfx Asxgqitjdwsb Place required (for installation) ca. ~3 860 × 4 245 mm Weight cca.4600 kgs High from floor to table surface cca. 995 mm Power required 3 Phasys, 50/60 Hz, cca. 13 kVA Tolerance: “Fine Corner Control”, “Digital PIKA-W Plus” options Visual / additional functions / controller: Smart Pulse (SPW) generator, Linearmotor (X/Y/U/V), absolut linearscales, ceramic working area, automatic wire threading (AWT), wire rotation, sparing power circles, optional Extra-taper (±45°) function, etc.

Condition: used, Year of construction: 2012, Travel distance: Ljdpfx Ajuu Dl Rodwohb X 500 mm Y 350 mm Z 300 mm Water bath machine Automatic wire threader

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, workpiece weight (max.): 1,500 kg, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 300 mm, No reserve price – guaranteed sale to the highest bidder! The payment deadline for the machine is 20/11/2025! Placing a bid obligates the buyer to collect the machine within the period from 01/12/2025 to 05/12/2025! TECHNICAL DETAILS Travel X-axis travel: 500 mm Y-axis travel: 350 mm Z-axis travel: 300 mm Work Table Table dimensions: 780 mm x 630 mm Table load capacity: 1,500 kg Taper: 10° / 150 mm Lhjdpfx Aoxnkblsdwjb U/V-axis travel max.: 30 mm Maximum workpiece dimensions: 1,050 mm x 800 mm x 295 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 2,800 mm x 2,460 mm x 2,100 mm Weight: 3,500 kg

Condition: good (used), Year of construction: 1998, Controller FANUC Series 16W Max size of wpc. 800 x 730 x 300 mm Max table load 750 kg X travel 520 mm Y travel 370 mm Z travel 300 mm U travel 120 mm V travel120 mm Dia of wire Ø 0,05 – 0,33 mm No. of axes 5 (X, Y, Z, U, V) Capacity of tanks 650 Liters Accessories - Dielectric cooler Lhjdpjul Uwlefx Adwob - Coolant unit - Interface RS232 - MPG - Automatic wire threading - Manuals

Condition: excellent (used), Stroke X-Y-Z 500 x 350 x 300 mm Workpiece dimensions 1050 x 800 x 295 mm Workpiece weight 1500 kg U+V-Axis +/- 21 mm Misc. accessories MARCELS MASCHINEN AG Lhjdpfx Adoxl A Aioweb

Condition: used, Year of construction: 2008, Travel distances: X axis = 350 mm Y axis = 250 mm Z axis = 220 mm incl. cooler Fully functional Lodpfx Adjw Swd Aowshb

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, GF AgieCharmilles Progress VP3 Year of manufacture: 2009 Travel paths: X= 500 mm, Y= 350 mm, Z= 426 mm U/V axis travel: +/- 70 mm Maximum taper: 30° at 100 mm height Maximum workpiece dimensions: 1050 x 650 x 420 mm Maximum workpiece weight: 400 kg (submerged) / 800 kg (out of tank) Achievable surface quality: Ra: 0.20 µm Maximum cutting speed: 500 mm²/min Available wire diameters: 0.15 – 0.33 mm Submerged wire EDM machine with automatic wire threading and re-threading after wire breakage With manual front door (accessible from one side) Including AGIEJOGGER handbox for convenient setup AGIE IPG-V generator AGIEVISION 5 control unit Dimensions (L x W x H): 1940 x 2300 x 2600 mm Net weight: 3460 kg The machine is cleaned and fully overhauled after receipt of order. You will receive a 6-month warranty on all machine parts. Ljdpoxggdmofx Adwohb We are also happy to offer commissioning and training services.

Condition: used, Year of construction: 2004, Working range 1.050 x 650 x 250 mm max. workpiece weight 400 (800) kg control Agievision AGIE max. conicity 30° / 100mm travel -x axis 500 mm travel -y axis 350 mm travel -z axis 426 mm travel U x V-axis mm rapid traverse X-axis 3 m/min Lhedpfxsw Spa Nj Adweb rapid traverse Y-axis 3 m/min rapid traverse U-axis 0,6 m/min rapid traverse V-axis 0,6 m/min rapid traverse Z-axis 0,6 m/min wire dia. 0,2...0,33 mm total power requirement 12,1 kVA weight of the machine ca. 3,9 t dimensions of the machine ca. 2,8 x 2,4 x 2,3 m Wire Eroding Machine AGIE - Agiecut Progress 3

Condition: used, Year of construction: 2004, Working range 1.050 x 650 x 250 mm max. workpiece weight 400 (800) kg control Agievision AGIE max. conicity 30° / 100mm travel -x axis 500 mm travel -y axis 350 mm travel -z axis 426 mm travel U x V-axis mm rapid traverse X-axis 3 m/min rapid traverse Y-axis 3 m/min rapid traverse U-axis 0,6 m/min rapid traverse V-axis 0,6 m/min Lhjdpfsw Spbtox Adweb rapid traverse Z-axis 0,6 m/min wire dia. 0,2...0,33 mm total power requirement 12,1 kVA weight of the machine ca. 3,9 t dimensions of the machine ca. 2,8 x 2,4 x 2,3 m Wire Eroding Machine AGIE - Agiecut Progress 3

Condition: like new (used), Year of construction: 2008, operating hours: 1,120 h, Controller ARISTECH (similar as FANUC) Number of axes: 4 Table size 640 x 470 mm X Axis Travel 425 mm Y Axis Travel 300 mm Z Axis Travel 250 mm Max workpiece size 800 x 600 x 250 mm U Axis Available:standard Weight cca 3000 kg Lhodovvl Uaopfx Adwob Dimensions LxWxH = 1860 x 2050 x 2100 mm The machine consist of following units 1. EDM machine 2. Controller cabinet 3. Water tank and pump 4. Water cooler 5. Transformer 6. Transformer Nr.2 (power supply) The machine was barelly used. Still unter power. It will be due to company liquidation.

Condition: used, Year of construction: 1981, functionality: unexamined, Due to the dissolution of the department, an AGIE EMS 3 die-sinking EDM machine is available. The machine was still in operation until 12 months ago, but is no longer needed and is now stored disassembled. It is sold complete, including tank, filtration unit, 2 barrels with original fluid, as well as various tools and copper electrodes. Suitable for hobbyists or professionals—also a good source of spare parts, as these parts are becoming increasingly scarce. Loading with forklift is free of charge, whether you want the complete unit or just specific parts. Collection is preferred, but shipping with a freight carrier is also possible. Price upon request. Lodpfx Asxtq Nasdwehb
