Used Ayen Skb 50 for sale (27)

Condition: good (used), Year of construction: 1984, Dowel Drilling Machine AYEN SKB 50 Manufacturer AYEN Model SKB 50 Year of manufacture 1984 S/N 8411346 Total 50 spindles in (2) swivel heads with (25) spindles each drills vertically from above and horizontally from behind drills in any angle between 0° - 90° with a positive stop at 45° working width 768mm / passage 1000mm 50-spindle swivel head assembly quickly converts to (2) 25-spindle heads for double row drilling, 5-1/8" minimum distance between heads for row drilling. 3 HP - 3,450 RPM gear motor, 39" plate width with a 30-1/4" drilling width. Complete with: (2) 39" stops with flip stops, (3) pneumatic "Quick Set" hold-downs, Foot pedal control for drill cycle/head positioning. Motors, 3 phases, 380 V / 50 Hz Compressed air consumption 9l / cycle Itedpfskcfcajx Aaben Weight 490 Kg

Condition: excellent (used), Year 1995 Engine 2.5 kW 8 adjustable units dowels glue 21 drills Iedoxnw Skopfx Aabjtn

Condition: excellent (used), functionality: fully functional, overall weight: 71 kg, AYEN Magnum Dowel Inserter 25.09.8212 Net price: 5,900 PLN Ijdpfexlr Smjx Aabotn Dowel diameter range: 8–20 / 11–26 mm Simultaneous dowel insertion with integrated glue dispensing Cycle time: 1.2 s Stepless dowel diameter adjustment Adjustable glue dispensing volume Operating pressure: 6 bar Maximum glue working pressure: 6 bar Continuous air consumption: 200 l/min Glue tank capacity: 1.4 l (sufficient for approx. 10,000 dowels) Dowel hopper capacity: 4 l Installation dimensions: - Width: 480 mm - Depth: 480 mm - Height: 900 mm Total machine weight: 71 kg Single gun weight: 2.2 kg Mobile and portable device, easy to use Compact design Requires only compressed air for operation Accurate centering thanks to the protruding glue nozzle Glue always applied directly into the hole via the protruding nozzle Glue volume and injection time precisely adjustable via the valve control block Quick gun switching: "Glue + dowel" or "Glue only" Integrated water flushing option Standard high-pressure gluing system suitable for D4 glue Operates in any position, even upside down

Condition: good (used), 3 drilling heads; adjustable drilling head width; power: 3 x 2.2 kW; Isdexg Ur Ejpfx Aabotn

Condition: used, Year of construction: 1980, Number of drill spindles: 23 Pitch: 32 mm Drill bit holder: Screw-in thread Operation: Foot pedal Drilling direction: From above and from the front Swivel: Pneumatic Maximum throughput width: 720 mm Number of material clamps: 2 Type of material clamping: Pneumatic Design: Mobile Stop system: For hole line and construction line Dimensions: 1300 x 1200 x 1700 mm Approx. weight: 365 kg Motor power: 2.2 kW Storage location: Nattheim Ijdpowkir Djfx Aabjtn

Condition: used, Year of construction: 1985, Used machine Year of manufacture: 1985 Equipment and technical data: - 23-spindle drilling head (32 mm pitch, suitable for carcass and furniture construction) - Pneumatic clamping cylinders for workpieces - Infinitely adjustable depth stops - Adjustable fence with measuring scale - Solid worktable with lateral supports - Quick-change drill bushes for various drill diameters - Foot pedal control for pneumatic operation - Drilling spindles: 23 units, 32 mm pitch - Max. drilling depth: approx. 65 mm - Drilling diameter: 2–35 mm - Motor power: 2.2 kW - Speed: approx. 2800 rpm - Compressed air connection: G 1/4 - Air consumption: approx. 7 l/cycle - Electrical connection: 380 V, 50 Hz - Worktable: approx. 1000 × 350 mm - Dimensions (L×W×H): approx. 1200 × 800 × 1200 mm Iedsxdpmljpfx Aabetn - Weight: 490 kg Location: Baden-Württemberg Availability: short notice

Condition: excellent (used), Dowel boring machine DB 2000 Ijdpfxsth U Ezj Aabotn Year of construction 1981

Condition: like new (used), functionality: fully functional, Dübellock drilling machine Ayen 23, complete equipment, partly new drill bits Isdpexg N Dpefx Aabjtn

Condition: ready for operation (used), Year of construction: 1980, functionality: fully functional, machine/vehicle number: 751 950, drilling depth: 45 mm, total width: 1,170 mm, total length: 750 mm, total height: 1,620 mm, type of input current: three-phase, overall weight: 350 kg, rotational speed (max.): 2,800 rpm, compressed air connection: 10 bar, input voltage: 380 V, workpiece height (max.): 110 mm, working width: 720 mm, number of spindles: 23, table width: 820 mm, table height: 772 mm, operating pressure: 6 bar, height adjustment type: mechanical, working height: 842 mm, table length: 430 mm, power: 2.2 kW (2.99 HP), workpiece width (max.): 820 mm, Boring machine for dowelling and drilling. Also suitable for line boring, cup hinges, frame edges, and other fittings. - Mobile (height adjustment +70 mm). - Work table with integrated measuring scale. - Pneumatically swiveling drilling beam, horizontal and vertical, also at 45° angles. Iodpfexg Drbox Aabotn - Pneumatic foot control, 3 pneumatic clamping cylinders. - Version with 23 spindles at a 32 mm pitch. - All drilling spindles equipped with quick-change chucks. - 2 stop guides, each 1040 mm, with one stop slider each. - 2 inserts for frame dowelling. - 3000 mm line boring guide rail with 2 stop sliders and 2 indexing sliders. - Adjustment gauge for stop rails. - Operating manual with machine card, clamping and pneumatic diagram, spare parts list, and all technical drawings. - Approx. 50 drill bits (some of them new). - Operating hours counter.

Condition: ready for operation (used), model: Alomat AL200, 2 aggregates, ready to work Ijdpfxoxd Sxwe Aabotn

Condition: excellent (used), 19 Drill You can call or write to us. We can speak and write German and Russian. You can also send messages in English Iodpfxjucqacs Aabotn 5.1.5

Condition: excellent (used), Drilling units with Festo control, currently mounted on a frame press. 4 drilling units 1.5 kW. 2 drilling units 1.5 kW with 240 mm stroke. 2 units with angle gears configured as sawing units. 2 drilling units with 3-spindle drilling head, 32 mm pitch. Individual sale possible. Isdpfew I R Iaex Aabstn

Year of construction: 1985, condition: ready for operation (used), Various old woodworking machines are available. 1) Joos triple veneer press. 2) Frommia FS 60 post router, year of manufacture: 1985. 3) Schwabedissen planer. 4) Column drilling machine Ayen. On-site inspection is possible. Iodpowty Emsfx Aabjtn

Condition: like new (used), Year of construction: 1978, operating hours: 160 h, functionality: fully functional, machine/vehicle number: 705514, workpiece weight (max.): 50 kg, drill spindle length: 700 mm, feed length X-axis: 3,000 mm, feed length Y-axis: 730 mm, AYEN Vertical Drilling Machine - 21 drill bits - 32 mm spacing - Drilling head length: 70 cm - 3 quick drilling distance adjustments - Drilling depth range up to 70 cm (adjustable front/rear) - 2.2 kW motor - Pneumatic connection: 6 bar - Head activation via foot pedal - Automatic material clamping - Very precise and fast operation - Stable construction, weight: 480 kg - Perfect condition Iedpfxow Hm S Ho Aabetn Net price, VAT invoice issued.

Year of construction: 1992, condition: excellent (used), 23 spindles working width 720 mm vertical drilling depth 45 mm horizontal drilling depth 120 mm Ijdpfx Aok Up Iteabjtn

Condition: used, Ayen type D4-105 knothole drilling machine for drilling out knotholes in wood as a wall model. Isdpfx Aewlbuasabetn

Condition: good (used), The machine consists of two units. And has the following functions: 1. branches - drilling holes 2. pin milling 3. glue injection 4. driving in the pin Process time only approx. 3 sec/cycle You can call or write to us. We can speak and write German and Russian. You can also send messages in English. 5.3.4 Itodpfx Aastpqafobsn

Condition: excellent (used), Year of construction: 1995, Chamfering unit, suitable for BIHLER GRM 50 or GRM 80 wire diameter range: 2,5 - 5,5 mm Itjdpfx Aoi Tza Ueaben

Year of construction: 1981, condition: excellent (used), 2 piece boring bar 21 drills, grid system 32 mm32 mm Max travel of the drill bar of min. 22 mm up to 624 mm Rows spacing min. 125 mm, 603 mm (drill line) 1 pneumatic cylinders between the drill bar Motor4. 4 kW Stroke 98 mm Oil brake cylinder with stroke 70 mm Itjdpfed Attpox Aaben Operating pressure approx. 6.0 bar Air consumption approx. 3 l / stroke Travel distance of at least 20 mm to 650 mm Masch.Nr.: 705521 Weight approx. 540 kg Dimensions: 2500 x 1100 x 1700 mm The machine is still processed and checked for function Condition very good

Condition: ready for operation (used), Brand: Ayen Model: DB 1000 B23 Pneumatically controlled drilling machine Isdpfxsri R H Ee Aabstn Tech. info: Max opening: 820 mm Working width: 720 mm Drilling depth: Horizontal 120 mm, vertical 80 mm Motor: 2,2 kW, 50 Hz, 380 V, 2800 RPM, 3-phase Machine size: 120x80x205 cm (lxwxh) Weight: 275 kg Stock no: 2001012

Condition: used, Year of construction: 1979, from school operationused, good conditionmake Ayentype DB 1000 K 23year of construction 1979machine no. 7SA740GS-testednumber of spindles 23 piecesnumber of drilling beams 1spindle distance / grid 32 mmdrilling from aboveswiveling pneumatichole line drilling devicestorage location 97447 Gerolzhofen, free loaded, unpackeddelivery in as-is condition as viewed,without warranty and guarantee Iodpovxr Raefx Aabetn

Condition: used, Working width: 720 mm working width: 820 mm Max. passage: 45 mm Itjdslfcn Ejpfx Aabsn Max throughput: 120 mm Drilling depth vertical: 45 mm, horizontal: 120 mm

Year of construction: 1980, condition: excellent (used), 1 piece drilling beam 21 drills, grid system 32 mm32 mm max. travel of the drilling beam min. 22 mm to max. 624 mm Row spacing min. 125 mm , max. 603 mm ( drilling line ) Itodefhn Irjpfx Aabon Engine4.4 kW Drill stroke 98 mm Oil brake cylinder with stroke 70 mm Operating pressure approx. 6.0 bar Air consumption approx. 3 l/cycle Traverse path from min. 20 mm to max. 650 mm Weight approx. 540 kg Dimensions : 2500 x 1100 x 1700 mm The machine is still being reconditioned and checked for function condition very good

Condition: used, used, good conditionmake Ayentype D-41HAmachine no. 52396motor 0.75 kWnumber of spindles 4 pieceswall-mounted machinespace requirement approx. 1000 mm x 300 mm x 800 mmweight approx. 70 kgtotal connected load 0.75 kWstorage location 97447 Gerolzhofen, free loaded, unpackedhandover in as-is condition as inspected,without guarantee and warranty Itjdpsvwfrbofx Aabjn

Condition: used, used, top condition, hardly run manufactured by Ayen Isdevwgd Sopfx Aabstn type ED 08-3 motor 0.6 kW number of spindles 3 piece wall machine folding hand operation stand range ca. 500 mm drill chuck Konus MK 1 required space ca. l x w x h mm 1100 x 300 x 1000 located in 97447 Gerolzhofen sale in current condition - free on truck -
