Used Edge Milling Machine for sale (65,977)

Condition: used, Year of construction: 1995, Technical details: x-travel: 600 mm y-travel: 400 mm z-travel: 400 mm table surface area: 800 x 400 mm range of revolution per miute: 63 - 3150 / 18 step U/min feed continuous: X/Y/Z: 8 - 800 / 8step mm/min. spindle taper: SK 4 Fpsdeytnd Aepfx Adasd spindle head swivable left - right: 90 ° quill stroke: 105 mm total power requirement: 5,3 kW weight of the machine ca.: 2245 kg machine dimensions LxWxH: 2,1 x 2,8 x 1,9 m Control screen replaced with new LCD. The milling machine is equipped with measuring system with digital display PROTOTRAK MX2. The X and Y axes can run cycles. (interpolation), the Z-axis is moved manually. Spindle with right/left travel Automatic tool clamping via control command Coolant device (without container) Chip collection tray Tool accessories (comparable in the photo) *

Condition: used, Year of construction: 2003, gebraucht 2003 4544 prompt, Zwischenverkauf v Spanien 13800 € 1 50 - 1700 (12) U/min ISO 40 600/210/400 mm 800 x 225 mm 1500 mm 1350 mm 1850 mm 950 kg 1,5 kW with 3-axis digital display or Cooling equipment Machine lamp Swivelling universal milling head (Huron design) Horizontal milling device with counter bearing Table enclosure automatic feeds in X and Y Fjdpfjyrhtzsx Adaepd Machine feets User Manual and EG Confirmation english

Condition: used, Year of construction: 2005, gebraucht 2005 4541 prompt, Zwischenverkauf v China 5700 € 1 40 - 1.300 U/min ISO 30 465 x 230 x 380 mm 1000 x 280 mm 2.2 kW 1400 mm 1300 mm 2200 mm 1120 kg 90 ° 115 - 1.750 (115, 230,290 U/min Milling head rotatable and swivellable +/- 90° with manual quill 120 mm travel range Fjdjyrhr Depfx Adajpd Spindle sleeve feed takes place via a turnstile or with the fine feed by means of a handwheel Spindle head 350 mm manually traversable Max. drilling capacity 30 mm Manual tool clamping vertical/horizontal by means of tightening screw Automatic feed in X Axis,(8) 12 - 370 mm/min Coolant unit Chip tray Lighting 1x Collet chuck set 1 Stk Drill chuck with mounting 4 Milling cutter holders User Manual in ENGLISH Does not comply with the German UVV & Austrian AMVO

Condition: new, neu ca. 4 Monate ab Auftragse Taiwan 48000 € 916.8 € 40 -3200 U/min ISO 40 600 x 500 x 400 mm 1000 x 500 mm 3.75 kW 1814 kg 1000 mm/min 8 14 x 63 mm 300 kg 600 mm 500 mm 400 mm 0 - 600 mm/min. 0 - 600 mm/min. 40 - 3200 40 - 3200 +/- 90° ° 100 mm manuell 3,75 kW 1200 x 250 mm 160 - 660 mm 95 - 495 (2. T-Nut), 180 mm swiveling operating panel 3 axes digital read out Fagor 400ib Innova motor for horizontal- and vertical spindle: 3,75 kW feed motors with inverter for X/Y/Z: 0,75 / 0,75 / 0,75 kW ball screw spindles for X/Y/Z axes manual gear box for spindle speeds 1 pc. long milling arbor 27 mm 3 pcs. recustion sleeves (MK1, MK2, MK3) 1 pc. drawing bar ISO40 for horizontal or vertical spindle spindle protection with switch table safety guard with doors with switches outer arbor support for horizontal spindle LED work lamp Fpjdpeyrhrqjfx Adaed automatic lubrication for X/X/Z guidways safety hand wheels for X/Y/Z axes coolant equipment with chip tray covers for X/Z axes level pads and bolts tool box with tools operating manual in English or German according to CE rules

Condition: used, Year of construction: 2002, gebraucht 2002 4543 prompt, Zwischenverkauf v Spanien 11400 € 1 50 - 1700 (12) U/min ISO 40 600/210/400 mm 800 x 225 mm 1700 mm 1500 mm 1960 mm 950 kg 1,5 kW with 3-Axis Digital display Fabr. Time Technology Europe Swivelling universal milling head (Huron design) Horizontal milling device with counter bearing and 1 pc. long milling arbor Coolant device Fjdsyrhn Espfx Adaepd Machine light automatic feeds in X and Y Machine feet with vibration absorbers no User Manual DOES NOT COMPLY WITH GERMAN UVV & AUSTRIAN AMVO

Condition: used, Year of construction: 1997, Catalogue number 7724 TECHNICAL DATA - number of working spindles: 6 pcs - spindles pressed pneumatically onto the material - milling units adjustable up/down, right/left, and at angles - 6 pneumatic clamps - stepless feed speed adjustment - max milling height: 130mm - max milling length: 2500mm - max milling width: 330mm - shaft diameter: 40mm Motor power: - milling units 1-2: 2 × 5.5kW - milling units 3-4: 2 × 4.5kW - milling units 5-6 universal (sanding or milling): 2 × 4.5kW - extraction nozzle diameter: 10x152mm - air supply requirement: 6-8 bar - dimensions (L/W/H): 8000x3000x2420mm - weight: approx. 6000kg ADVANTAGES – Italian manufacture – For through-feed processing of curved elements according to template Fpsdpfx Adoya Hl Esajd – 6 milling units – Not repainted – Safety guards – Original DTR + CE documentation – Used machine in very good condition Net price: 46,900 PLN Net price: 11,160 EUR (based on 4.2 EUR exchange rate) (Prices may change depending on exchange rate fluctuations)

Condition: used, Year of construction: 2007, x-travel 780 mm Fpodpfxeyb S Ibe Adajd y-travel 560 mm z-travel 560 mm total power requirement --- kW weight of the machine ca. 12,0 t dimensions of the machine ca. --- m

Condition: good (used), 1 used tool milling machine Manufacturer: Emco Fedpfxsyt Htco Adajpd Model: FB 6 Control: Heidenhain TNC 124 Table working area dimensions: 900 x 500 mm X-travel: 700 mm Y-travel: 500 mm Z-travel: 500 mm Spindle taper: ISO 40 Spindle speed: 0 - 3150 rpm Machine dimensions (L x W x H): 2220 x 2115 x 2120 mm Machine weight: 2550 kg

Condition: used, Year of construction: 2006, x-travel 1.100 mm y-travel 600 mm z-travel 560 mm Control Heidenhain iTNC 530 spindle tunring speed 12.000 U/min tool taper SK 40 number of tool places 40 Pos. weight of the machine ca. 7,4 t In our assessment, the machine is in good used condition and can be inspected under power by appointment. Fsdpfx Adeytybyeaepd Technical features & accessories: - Chip conveyor - 4th axis preparation - Internal coolant supply Accessories, tools, and clamping devices shown are only included if specifically stated in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, Year of construction: 2004, x-travel 3.000 mm y-travel 1.000 mm z-travel 1.000 mm surface area 1.035 x 3.500 mm control Heidenhain 530i round table Ø500 mm / 360° mm/° NC swivel head +/-90 ° spindle tunring speed 9.000 U/min tool taper SK 40 number of tool places 48 Pos. auto power on hours ca. 27.834 h spindle hours ca. 12.357 h In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: - NC swivel head Fedpexx A Ncofx Adaepd - Rotary table - Wireless probe - Direct linear encoder - Internal coolant supply 40 bar Accessories, tools, and clamping devices shown are only included in the scope of delivery if specifically stated in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, Year of construction: 2007, x-travel 500 mm y-travel 420 mm z-travel 380 mm Control Heidenhain TNC 530 max. turning speeds 20-18000 min/-1 tool taper SK 30 table surface area 800 x 480 mm max. table load 500 kg number of tool places 32 Pos. max. tool length 280 mm max. tool weight 6 kg rapid traverse 50 m/min Fpjdpfxoytha Do Adaed feed speeds 20 m/min weight of the machine ca. 5700 kg dimensions of the machine ca. 6,6 x 5,4 x 3 m total power requirement 45 kW Number of working hours 24.437 h spindle hours 9.874 h Number of axles 5 St. 5-axis Milling Center Deckel Maho DMG 50 eVo linear, built 2007 Attachment: 10 off SK30 tool holder Note: The control system occasionally switches to EMERGENCY STOP due to a hydraulic fault. This is probably due to the control system and not the hydraulic unit or hoses, as there are no leaks. The supplier expects that a minor repair will suffice.

Condition: ready for operation (used), - USED - BRIDGE-TYPE MILLING MACHINE WITH MOBILE TABLE AND MOBILE CROSS BEAM Fsdpfxsyru Ncj Adaepd LONGITUDINAL TRAVEL: 9000 mm TRANSVERSAL TRAVEL: 2950 mm VERTICAL TRAVEL: 1250+2200 mm RAPID FEEDS L-T-V: 3 - 3 - 2 m/min TABLE SIZE: 2800 x 8000 (5000+3000) mm MAX ADMITTED LOAD: 64000 Kg SPINDLE: 20 - 600 rpm; 100 kW; 13000 Nm; ISO 60 DISTANCE BETWEEN UPRIGHTS: 3200 mm DISTANCE SPINDLE NOSE-TABLE: 2806 mm OVERALL DIMENSIONS: 21000 x 7800 x 6650 mm ACCESSORIES: GEAR BOX NOTE: No 1 90° HEAD; No 1 REDUCED 90° HEAD; No 1 VERTICAL EXTENSION; No1 TILTING HEAD; 3-STEPS GEAR BOX

Year of construction: 2016, condition: ready for operation (used), - USED - TRAVELLING COLUMN MILLING MACHINE Fpodpfx Ajx Ru Azjdaod LONGITUDINAL TRAVEL: 6000 mm TRANSVERSAL TRAVEL: 1500 mm VERTICAL TRAVEL: 2500 mm RAPID FEEDS L-T-V: 35 m/min SPINDLE: 337- 5000 rpm; 42 kW; 1180 Nm WORKTABLE: 300 x 2500 x 7000 mm HEAD: ISO 50 ; MILLESIMAL POSITIONING ; A/B AXIS AUTOMATIC TOOL MAGAZINE: PICK-UP ; 12 POS CONTROL UNIT: HEIDENHAIN TNC 640 HIGH PRESSURE COOLANT: 20 Bar NOTE: AUTOMATIC HEAD CHANGE; COMPRESSED AIR INSIDE THE TOOL; RTCP; AUTOCAL SOFTWARE FOR AUTOMATIC CALIBRATION

Condition: used, functionality: fully functional, table width: 695 mm, table length: 1,200 mm, rotational speed (max.): 2,800 rpm, rotational speed (min.): 700 rpm, overall weight: 3,000 kg, BOHNER & KÖHLE DP 6 A Milling Machine with turntable Technical data: Table clamping surface: approx. 1200 × 695 mm Milling spindle with 1.5 HP, Speed range: 700, 1,400, and 2,800 rpm Weight: approx. 3,000 kg Overall dimensions (L × W × H): Approx. 2,400 × 2,300 × 2,750 mm Fjdox Hwdaopfx Adaepd Fully functional

Condition: used, Year of construction: 2004, gebraucht 2004 4540 ca. 2 Wochen ab Auftragse Österreich 19900 € 1 63 - 3150 (18) U/min 700 x 500 x 500 mm 900 x 500 mm 6.6 kW 2150 mm 2220 mm 2120 mm 2550 kg 500 kg 100 mm CNCHeidenhain TNC 410 18. mech. feeds with rapid travel in X,Y,Z axes ball screw spindles toolmaker accuracyDIN 8615 hyd. tool clamping with holdersSK40 vertical und horizontal vertical spindle+/- 30° swiveling swing out device digital 3D edge finder work area protection coolant equiptment aut. central lubrication fixed angle table with 10 t-slots chip collecting tray machine lamp users manual in GERMAN + CE COMPLIES WITH THE CURRENT INDUSTRIAL SAFETY REGULATIONS (AMVO & UVV) Fpodpfxjwirmne Adajd

Year of construction: 1990, condition: used, spindle taper 2 x SK 40 forward bearing diameter 110 mm milling head speed 100 - 4500 U/min milling drive 5,1 kW workpiece length - max. 830 mm workpiece dia. with double equipment max. 135 mm taper diameter 78 g6 mm centre height 260 mm turning speed range - stepless max. 15 U/min distance of spindles 135 mm spindle nose DIN 55026 Gr. 5 stroke of workpiece slide 810 mm Feed speed max. 6 m/min. surface area 200 x 1750 mm stroke of tool slide 120 mm Feed speed max. 2 m/min. Fodpfx Adoyt Rwrjajpd column movement 200 mm tailstock quill stroke 100 mm morse taper 3 MK centre height 260 mm axial distance of the quills 135 mm passage of steadyrest 40 - 80 mm control SIEMENS SINUMERIK 810 weight of the machine ca. 6,5 t with SIEMENS-control SINUMERIK 810/820 acc.: NC-dividing unit with back stop, various toolholders, steadies, running centres, coolant

Condition: used, Year of construction: 1990, x-travel 2800 mm y-travel 1000 mm z-travel 1200 mm table surface area 2000 x 800 mm rotary table dia. 800 mm spindle taper SK 50 spindle turning speed - stepless 50 - 2000 U/min max. torque on the spindle 3000 Nm spindle drive 30 kW feeds longditudinal/cross/vertical 2 - 2000 mm/min rapid motion -longitudinal/cross/vertical 7 m/min control SIEMENS control SINUMERIK 850 M no. of tools in magazin 56 workpiece diameter at full load 114 mm wotkpiece diameter with 2 vacant positions 200 mm workpiece length 400 mm weight of tools max. 16 kg tool changing time ca. 8 - 9 sec internal coolant system feed ja / yes weight of the machine ca. 25,4 t = 5-axis CNC-bed-type milling machine with integrated NC-rotary table and NC-swivelling milling head - Acc.: tool pre-setting device, various tool fixtures, chip conveyor, Fsdpsyt Rwljfx Adajpd coolant with high pressure pump and filtration device, electron. handwheel, fixators

Condition: good (used), Code: 0324 Brand: OMEC Model: 750 Automatic milling machine for dovetail joints on drawers and various furniture parts Fodpfxjytr Sdo Adajpd Technical data: Useful working width 480 mm Thickness of drawer fore parts 60 mm Number of joints per minute: at 1st speed 25 , at 2nd speeds 35 Electric motor power of toolholder spindle 1,5 Hp Electric motor power trip traverse 1,5 Hp Overall dimensions mm 800 X 1300 X 1200 h Weight kg 350

Year of construction: 2003, condition: ready for operation (used), Control Unit Brand SELCA Model SELCA 3040 Fedpfjx D E T Ijx Adaspd Main Drive Spindle speed range 5000 Spindle motor power 22 kW Tool taper ISO 50 Number of axis 4 Movement X-Axis Movement 2000 mm Y-Axis Movement 1250 mm Z-Axis Movement 1250 mm Media Chip conveyor Yes Additional Equipment Remote handwheel Chip conveyor Through-spindle coolant This 3-axis Parpas THS125/2000TG was manufactured in 2003. It features a SELCA 3040 control unit, a main spindle with 5000 rpm and 22 kW power, and an electrospindle that reaches up to 28,600 rpm. The machine includes a 24-position tool changer and accessories like a chip conveyor and through-spindle coolant. If you are looking to get high-quality milling capabilities consider the Parpas THS125/2000TG machine we have for sale. Contact us for more information. Application Types Milling

Condition: used, Year of construction: 1982, x-travel 300 mm y-travel 160 mm z-travel 340 mm feeds -stepless- 5-500 mm/min rapid traverse 1200 mm/min spindle turning speed range 40 - 2000 U/min tool taper Normkegel 40 table length 600 mm Fpodpfovvnfuox Adaed table width 120 mm voltage 380 V frequency 50 Hz rated current 13 A weight of the machine ca. 0,750 t dimensions of the machine ca. 1,8 x 1,5 x 1,8 m DESCRIPTION Machine incl: active three-axis digital readout HEIDENHAIN documentation various tool holders Machine vice etc.

Condition: used, Year of construction: 2006, x-travel 1050 mm y-travel 510 mm z-travel 510 mm control Fusion 640 M Nexus spindle taper DIN 69871/SK40 Feed speed 8000 mm/min. turning speed range 35 - 12.000 U/min rapid travel x/y/z 36 m/min distance spindle /table max. 660 mm distance spindle /table min. 150 mm no. of tools in the magazine 30 Stück tool taper CAT 40 Tool diameter 80 mm wotkpiece diameter with 2 vacant positions max. 125 mm max. tool weight 8 kg max. tool length 350 mm table length 1300 mm table width 550 mm number of T-slots 3 T-slot - width 18 mm T-slot - distance 100 mm max. table load 1200 kg table height over floor 850 mm coolant tank 250 l coolant pump 4,5 bar internal coolant system feed 15 bar coolant capacity 271 l/min required air pressure 700 l/min spindle drive 18,5 connected load frequency 400 V connected load 36,6 kVA frequency 50 Hz Needed pneumatic pressure 5 (bei 200 l/min) bar weight of the machine ca. 6,9 t dimensions of the machine ca. 2,90 x 2,84 x 2,81 m Including special accessories: -Cooling through the spindle (15 bar) -Chip conveyor, hinged belt on the left side -Torque-dependent drilling cycle (Mazatrol) -Automatic determination of drilling depth increments after torque detection. preferably in combination with HSS tool) -Interface set Contents: - Interface for keyboard - Interface for mouse - Interface for printer Retrofitting not possible Machine color gray / black -CNC Performance Option Package contents: - Shared variables (600 pairs) - MAZAK Tornado thread tapping (EIA/ISO) - Synchronous thread cutting - EIA/ISO input function - EIA/ISO special function Spiral interpolation (G02.1, G03.1), 3D tool correction (G40-G42) Scaling (G50, G51) etc. - EIA/ISO, Constant feed (G93) When using this function, the feed rate remains constant for straight and curved combinations on the contour. - EIA/ISO tool length measurement (G37) - EIA/ISO, programme unit stop function Programme sequence is automatically stopped at a specified programme unit. - MAZACC-2D (Mazatrol & EIA/ISO) Precision control function for precise vector interpolation and optimal acceleration and deceleration at edges and radii. This enables improved two-dimensional Fpsdsxp Rywjpfx Adajd shape accuracy. - Additional workpiece coordinate system (G54.1 P1 - 48) 48 pairs - Spiral machining function (G33) for boring head machining (e.g. with d'Andrea tool) - Used machine without warranty - - All dimensions, weight and performance data are non-binding

Condition: used, Year of construction: 2019, x-travel 2.000 mm y-travel 820 mm z-travel 720 mm Control Mazatrol Smooth G spindle taper SK 40 spindle turning speed range 35 - 12.000 U/min spindle motor 22 kW distance spindle centre table top edge 140 - 860 mm table load 1700 Kg rapid travel x/y/z 50 m/min table width 820 mm table length 2500 mm table height over floor 870 mm T-slots 7 T-slot - width 18 mm T-slot - distance 100 mm tool change unit 48 tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 130 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 260 l/min electrics - voltage/frequency 400 / 50 V/Hz coolant tank 450 l high-performance coolant system 25 bar total power requirement 46,7 kW weight of the machine ca. 14,8 t dimensions of the machine ca. 4,3 x 3,6 x 3,1 m STANDARD ACCESSORIES Transformer for the European market USB port (1 port) Mazak standard colour Spindle speed 12,000 min-1 (steep taper 40) Work area lighting SAFETY DEVICES Operator door with locking switch Work area panelling The splash guard encloses the working area from the side. Fully enclosed work area Protection against chips, coolant and access to the work area during automatic machining. Safety precautions in accordance with global standards COOLANT SUPPLY Coolant supply through spindle (pressure at the pump = 5 bar) Complete coolant system includes pumps, valves, pipework and nozzles for the efficient production of quality components. FACTORY AUTOMATION Automatic switch on/off and warm-up function Automatic switch-on of a warm-up cycle via digital timer MEASUREMENT SYSTEM Tool length measurement and tool breakage detection CHIP DISPOSAL Fpsdpfx Adetuggcoasd Factory preparation for chip conveyor (left) NUMERICAL CONTROL Fixed control/operating unit Relocation Detector Mazatrol SmoothG control unit 19" LCD colour screen (touch screen) Mazak tapping/drilling cycle Tornado (Mazatrol) By drilling and tapping in helical machining mode, a wide range of diameters a wide range of diameters can be machined at high speed with a wide range of diameters can be machined at high speed with just one tool. This function minimises programming and machining times. EIA/ISO input function Tool path check in the background The tool path of a programme can be checked even if another programme number is programme number is called up and processed in automatic mode. 3D coordinate conversion Shape compensation for rotating axes Mazacc 2D software (contour correction) Accuracy is maintained at high feed rates. Mazacc-3D software package for high-speed machining High-speed and high-accuracy machining for contours defined in the finest programme contours defined in the finest programme increments. MAZACC-3D high-speed software package (NO456) is additionally required. Control with high smoothing Interface for LAN SD Memory Card I/F Smooth standard software for M/C - NO443 B) MAZACC-2D software (workpiece shape compensation) - NO444 D) MAZACC-3D high-speed software package - NO445 B) Shape compensation for rotating axes - NO497 D) High accuracy control for finishing operations - Seamless corner point control - Variable acceleration control - Ultra high speed machining mode - NO498 Rapid traverse paths Rounding function Absolute positioning system Machine incl. the f...

Condition: used, Year of construction: 2010, functionality: fully functional, Initial commissioning: March 2010 Control: Fidia with HPX21 handwheel X-axis: approx. 11,500 mm Y-axis: approx. 1,550 mm Fodsytf H Iepfx Adaopd Z-axis: approx. 2,550 mm B-axis: ± 210° C-axis: ± 104° Spindle speed: max. 16,000 rpm Tool holder: HSK 50A Linear axis drives Feed rate for X, Y, and Z axes: 16 m/min

Condition: new, I sell, milling machine new. Fodpfxeuuiyts Adaspd

Condition: used, Year of construction: 2013, Used machine Fpodjytkiuopfx Adaed Year of manufacture: 2013 Equipment/features: - Machine table with 13 running rollers for improved workpiece guidance - Edge feed, synchronized with the belt feed - Edge thickness adjustable via digital counter - Pneumatic roller separation with cutter (for cuttable edges) - Three pressure rollers - Belt feed motor 0.25 kW; approx. 1250 mm length; feed rate approx. 6.0 m/min; 50 mm wide timing belt with thick, workpiece-friendly rubber coating. Digital counter for height adjustment - Direct glue application to the workpiece: leakproof glue pot with glue supply from below and fast heat-up time after machine stoppage - Flush trimming unit for front and rear workpiece edges, automatic sensing at the workpiece, pneumatic trimming with a cutter for cuttable edges - Flush milling unit with vertical sensing and horizontal guidance, reproducible adjustment via digital counters, 2 high-performance 0.4 kW high-frequency motors, continuously adjustable from 4000 to 18000 rpm, cutter diameter 70 mm, Z4, radius 2 mm/15°; central extraction connection Ø 100 mm, 2 chip extraction hoods with hose Ø 60 mm - Automatic height adjustment of the upper cutter with the belt feed - Continuous workpiece support approx. 1800 mm long, workpiece support rail extendable by approx. 300 mm - Rotatable film disc Ø 800 mm Technical details: - Minimum workpiece width: approx. 80 mm - Workpiece thickness: 10 – 50 mm - Minimum workpiece length: approx. 220 mm - Edge thickness: 0.4 – 2.0 mm - Roller separation max.: 1.0 x 55 mm, 2 x 45 mm - Glue pot heating power: 2.7 kW - Electrical connection: 400V, 50 Hz, 3Ph + N - Total connected load: 3.8 kW - Heat-up time: approx. 10 minutes - Pneumatic connection: 6 bar - Working height: approx. 880 mm - Dimensions: approx. 1800 x 700 x 1300 mm (without film disc Ø 800) - Net weight: approx. 260 kg Availability: short-term Location: Flörsheim
