Used Lorenz for sale (34)

Condition: refurbished (used), Year of construction: 2027, functionality: fully functional, wheel width: 200 mm, stroke length: 230 mm, feed length X-axis: 500 mm, type of input current: three-phase, total height: 2,900 mm, table load: 2,750 kg, table diameter: 1,005 mm, overall weight: 12,000 kg, input frequency: 50 Hz, total width: 3,300 mm, total length: 3,800 mm, distance table to spindle center: 640 mm, gear diameter: 1,000 mm, distance table center to spindle nose: 640 mm, workpiece diameter (max.): 1,000 mm, controller manufacturer: Siemens Sinumerik ONE, drive type: Siemens Sinamics S120, control type: CNC control, stroke rate (min.): 15 1/min, stroke rate (max.): 510 1/min, The universal machine for gearings that cannot be milled: The Lorenz LS 1000 CNC machines internal and external toothed spur gears up to 1000 mm in diameter – hollow gears for planetary gearboxes, gear rings, couplings, gears with a flange or chamfer. Completely modernized with Siemens Sinumerik ONE, new electrical system, hydraulics and lubrication, designed for maximum performance and accuracy in flexible manufacturing. Acceptance according to DIN and manufacturer's standards with a protocol. Offered by Serwema Retrofit Solutions, Chemnitz. The LS 1000 was developed as a universal machine for construction machinery, wind turbine and machine tool gearboxes, mining technology, aerospace and textile machines, and is suitable for both single parts, small series and large series. The main application is the hobbing of straight-toothed and – with a helical guide and matching cutting wheel – helical-toothed spur gears with internal or external teeth. With software options, the machine can also process non-circular gears, grooves and cams; with special cutters, couplings as well as involute and spur gears are produced. The Sinumerik ONE with electronic gear unit guides the user through workpiece and tool data using masks, without the need for programming. Fpodoz E H Rnepfx Ap Djn

Condition: used, Year of construction: 2021, functionality: fully functional, input voltage: 230 V, total width: 830 mm, total length: 870 mm, total height: 1,710 mm, overall weight: 150 kg, operating temperature: 60 °C, compressed air connection: 6 bar, Lorenz FMP04 Filter Test System, 2021 – EN 143/149, ISO 16900-3 – €47,900 net, negotiable Test respirator filters and masks (FFP and medical face masks) in-house instead of paying for lab time: the Lorenz FMP04 automatic filter test system measures filter penetration and breathing resistance in a single run, with results available within seconds. New price currently: approx. €95,000 net. Your price: €47,900 net (negotiable), ex works (EXW) Hamburg. One unit only, lightly used. What you get: • Standards-compliant testing according to EN 143, EN 149, ISO 16900-3, ISO 17420-2, and NIOSH 42 CFR Part 84; all parameters adjustable for customer-specific tests. • Two laser aerosol photometers (upstream and downstream) with automatic reference calibration and auto-ranging across six orders of magnitude. • Aerosol generator using paraffin oil heated to 60 °C, automatic oil supply from external reservoirs, software-based switching between standards. • Quick-change filter holder, Ø 112.8 mm (100 cm²), face velocity 5–40 cm/s, automatic flow reversal; canister filter adapter plate. • Extension for differential pressure testing per EN 14683 Annex C.4 (surgical masks) with adapter plates (2.5 cm bore); a €1,836 option in 2021. • 15" full-HD touchscreen, integrated PC, filter database, test history, CSV export, test reports with your logo, graphs for loading tests; USB and network. • Flow 8–300 l/min, efficiency 0.0001–100 %, breathing resistance 5–1,000 Pa (manufacturer data for the FMP04 series). • Scope: all adapter plates and accessories are included. Specifications: built 2021, approx. 150 kg, 870 × 830 × 1710 mm, 115/230 V. Requires compressed air ≥ 6 bar, ≥ 50 l/min (oil-, water- and particle-free). Please note: service is due. The unit has seen little use. Service and recalibration are due and are already reflected in the price. Why act now? Inspection and a test run in Hamburg can be arranged. Sold ex works (EXW) Hamburg. Fpjdpfx Apoz Inf Se Dsn Inquire today: response within one business day. Price negotiable. Location: Hamburg, Germany.

Condition: used, functionality: fully functional, total height: 1,100 mm, table diameter: 310 mm, overall weight: 5,000 kg, total width: 2,300 mm, total length: 1,800 mm, For sale is a gear hobbing machine as shown in the attached pictures. Manufacturer: LORENZ Max. wheel diameter: 500 mm Max. module: 5 Max. gear width: 100 mm Max. gear shaping length: 75 mm Number of strokes/min of the cutter: 45 / 424 Cutting speed: 18 Screw diameter: 78 mm Max. gear shaping diameter: 500 mm Max. external shaping diameter: 500 mm Max. internal shaping diameter: 450 mm Hole diameter of the table: 125 mm Diameter of table: 310 mm Total power: 3.0 kW Fpodpfx Apezz Ilno Djn Voltage: 220 / 380 V

Condition: ready for operation (used), Equipment: documentation/manual, Lieberr - Lorenz S800 / Gear Hobbing Machine -Well-maintained machine with extensive accessories -1 pallet / Change gears -1 pallet / Hobbing cutters -1 pallet / Clamping arbors DOCUMENTATION -Max. workpiece length with counter support 600mm -Max. workpiece length with retracted counter support 800mm -Max. travel of the milling slide 360mm -Largest millable pitch with the largest workpiece 5 PI / Normally 8 PI -Taper for spindle - Milling spindle MK 5 -Milling arbors / 22 / 27 / 32 / 40 mm -Max. cutter diameter 186mm -Max. cutter length 170mm -Max. cutter feed 80mm -Cutter speeds 40 - 220 rpm -Feeds infinitely adjustable / Horizontal -Feeds infinitely adjustable / Vertical -Feeds infinitely adjustable / Tangential -Clamping table without water trough 550mm -Clamping table bore 100mm -Clamping arbor taper MK 4 Dimensions: L x W x H 3.6 x 1.8 x 1.9 meters / Weight: 5000 kg Fsdpfxezv Ed Do Ap Depn Errors and omissions excepted.

Condition: used, Year of construction: 1988, machine/vehicle number: 14411, stroke length: 220 mm, table diameter: 730 mm, For sale is a Lorenz LS 630. A robust and precise machine, renowned for its high build quality. The machine requires technical refurbishment due to the control system, but is in very good mechanical condition. It can process components up to module 12. A stable and high-quality Lorenz LS 630 that can be made fully operational again with some effort. Fedpfx Asxrcmbjp Djpn

Condition: ready for operation (used), Year of construction: 1990, total width: 3,900 mm, total height: 3,400 mm, travel distance X-axis: 360 mm, travel distance Z-axis: 154 mm, overall weight: 9,000 kg, product length (max.): 5,300 mm, table load: 1,000 kg, number of axes: 3, This 3-axis LORENZ LS 424 shaping machine was manufactured in 1990. It features a maximum wheel diameter of 420 mm and a stroke rate of 32 - 800 strokes/min. The machine has an impressive X-travel of 360 mm and a Z-travel of 154 mm, with a maximum table load of 1000 kg. If you are looking to get high-quality shaping capabilities, consider the LORENZ LS 424 machine we have for sale. Contact us for further details. - Control Defect: Control unit reported as defective - Wheel Diameter Max.: 420 mm- Wheel Width: 120 mm- Module Max.: 8- Module Min.: 0.5- Control Unit: BWO CNC- Stroke Rate: 32 - 800 strokes/min (infinitely variable 25 - 800 strokes/min)- Total Power Requirement: 50 kW- Machine Elevation: 200 mm- X-Travel: 360 mm- Z-Travel: 154 mm- L-Travel: 137 mm- External Gear Cutting Max. Outer Diameter: 420 mm- Internal Gear Cutting Max. Inner Diameter: 370 mm- Workpiece Outer Diameter: 420 mm- Max. Stroke Length: 130 mm- Wiring Diagram: E8 Additional Equipment: Straight Guide, Leveling Feet Fpjdpfx Ajz Hk Iyjp Den

Condition: like new (used), number 1 Stück LORENZ disc cutting wheel HM: HB10 - F Z2/Z0= 15/60 Fpodezupl Aspfx Ap Don 14 - 44C 46 711/1 mn3.08 an21° z60

Condition: used, Year of construction: 1997, material width 820 mm coil weight 7,5 t material thickness 0,8 - 5,0 mm coil internal diameter 470 - 520 mm coil external diameter 1600 mm material cross-cut 1600 mm² no. of straightening rolls 7 straightening roll diameter 50 mm number of draw-in rolls 2 speed 0 - 40 m/min Decoiler HH 7500.1 with: - hydraulic expansion and automatic re-tensioning - material centre adjustment - adjustable pneumatic disc brake - counter-holder with quick clamping - circular guard ring - fixed coil loading chair Insertion aid consisting of: - snubber roll (driven) - infeed wedge - hold-down roll Straightening machine BRM 50/820.7 with: - automatic circular oil lubrication of the cardan shafts - torque-dependent overload protection - motoric roller cassette adjustment with digital display - quick-change device of the cardan shafts - quick-change device of the straightening rolls Transfer table + ultrasonic control BÜU-5 with: - loop control via ultrasonic sensor (analogue) - strip sag monitoring (min/max) Fedpszrpp Asfx Ap Djpn - strip end monitoring

Condition: like new (used), number 1 Stück Fpedpfx Apozupmao Dsn LIEBHERR/LORENZ disc cutting wheel Modul 4 - EW 30° - Zähne 12 - DIN 5480 - new

Year of construction: 2021, condition: ready for operation (used), An automatic Lorenz filter test station for the automatic testing of filter media, half masks, canister filters, and medical face masks is available. Standards: EN143/EN149/EN14683/ISO16900-3 and more, module components: flow meter/photometer upstream and downstream of the test specimen/aerosol generator/suction and extraction unit, aerosols: paraffin oil/Emery oil/DOP/DEHS, volume flow range: 8L-300L/min, min. separation efficiency measuring range: 0.0001%, min. breathing resistance measuring range: 5Pa-1000Pa, max. filter air velocity: 10.2cm/s, max. test area: 237.8cm³. The device has been used little and would not need to be serviced. Documentation available. An on-site inspection is possible. The image is an example. Fpsdpfx Apjy Tx Sls Djn

Condition: used, Year of construction: 1979, max. wheel diameter 420 mm gear width 120 mm max. module 7 mm min. module 0,5 gear hobbing diameter - external 420 mm gear hobbing diameter - internal 370 mm table diameter 400 mm boring diameter 125 mm spindle stroke 120 mm stroke position adjustment 230 mm strokes - infinitely variable 30 / 800 Hub/min depth feed stepless 0,016 - 0,063 mm/Hub total power requirement 35 kW weight of the machine ca. 7,5 t dimensions of the machine ca. 2,46 x 3,48 x 2,66 m Accessories: - Various replacement wheels and blade holders Fpodpszv Ulqjfx Ap Den - Documentation

Condition: used, Year of construction: 2001, sheet width 1650 mm plate thickness 0,5- 3 mm number of rolls 21 straightening feed 0- 60 m/min straightening roll diameter 50 mm adjustment 30 mm weight of the machine ca. 24,5 t dimensions of the machine ca. 4,5x 2 x 2,8 m voltage 400 V passage width 1720 mm number of support rolls 18 main drive motor 45 kW run-in height 1250 mm Fodszafi Njpfx Ap Dopn 6 HI High-performance straightening machine with 21 rolls for fine straightening work of steel or non-ferrous metals. Machine has 23 intermediate rolls and 18 support points. Working rolls are adjustable with DRO in 0,01 mm. Main Gearbox was renewed in 2021.

Condition: used, max. wheel diameter 500 mm gear width 75 mm max. module 5 min. module 0,5 Fpsdpfxezw N E Ue Ap Don no. of strokes 45 - 424 Hub/min total power requirement 6 kW weight of the machine ca. 3,6 t dimensions of the machine ca. 2,0 x 1,4 x 2,3 m Rapid traverse in the table. Change gears, toolholders, manuals.

Condition: excellent (used), Year of construction: 1985, functionality: fully functional, machine/vehicle number: 20-14446, wheel width: 1,000 mm, stroke length: 200 mm, Gear shaper with cutter – module 10 – max. diameter 1000 mm – vertical rise 250 mm – stroke 200 mm – equipped with two additional tables of 850 mm and 1500 mm diameter – many accessories and programs for 1-2-3-4 cycles and for spiral cutting. Fpjdpfx Aeybaz Nsp Don

Condition: ready for operation (used), Year of construction: 2015, controller manufacturer: SIEMENS, controller model: n/a, overall weight: 7,000 kg, This 3-axis LORENZ LS 150 was manufactured in 2015. It features a connected load of 60KVA, a rated current of 50A, and operates on a 400V system. Weighing 7000kg, this machine has been modernized to enhance performance. If you are looking to get high-quality milling capabilities, consider the LORENZ LS 150 machine we have for sale. Contact us for more information. Additional equipment • Rolling, single tooth parts, spiral feed Machine Benefits Technical Machine Benefits • Operating voltage: 400v Fpjdsx D Iyqopfx Ap Don • Connected load: 60kva • Rated current: 50a • Frequency: 50hz • Main fuse: 63a • Retrofit: a cnc retrofitting was carried out in 2015, sinumerik 840d control system. • All mechanical components checked, all hydraulic components checked and hoses replaced. • All necessary components were installed to guarantee problem-free production. Extra Information Machine still under power // All necessary components were installed to guarantee problem-free production.

Condition: used, Year of construction: 2007, machine/vehicle number: 001669, Lg 33121 Single-sided unwinding reel ARKU AH 3000/ST-M Year of manufacture: 1995 Maximum strip width: 600 mm Maximum load capacity: 3,000 kg Maximum coil outer diameter: 1,800 mm Spreader: hydraulically operated Presser arm: hydraulically operated Fpsdpfx Apshigmbj Djn Take-up reel with auxiliary drive and brake Coil loading table, fixed + reel traversing device including: Lg 33221 High-performance strip straightening machine LORENZ BRM 50/620.9 Year of manufacture: 2007 Machine no. 001669 Maximum pass width: 620 mm Number of straightening rollers: 9 Straightening roller diameter: 50 mm Material thickness: 0.7 to 6.0 mm Straightening rollers are multiply supported to prevent deflection. Drive for all rollers via a distributor gearbox and universal joints. Used, as is, ex warehouse, immediately available. Overhaul possible upon request. Delivery time upon agreement. Further data will be available shortly or upon request.

Condition: excellent (used), max. wheel diameter 300 / 400 mm gear width 76 mm max. module 6 min. module 0,5 Control BWO CNC 921 adjustment of stroke position 94 mm/Hub stroke 82 mm no. of strokes 75 - 1000 Hub/min Fsdpszq Hmcefx Ap Djpn number of teeth 5 - 200 taper of shaper cutter SK 45 table diameter 400 mm total power requirement 50 kW weight of the machine ca. 7,5 t dimensions of the machine ca. 5,0 x 3,8 x 3,4 m Machine in top condition.

Condition: ready for operation (used), The WS 1250 CNC gear shaping machine features a configuration comparable to the Lorenz LS 1000 or LS 1250 models, is designed as a universal machine, and is employed by manufacturers of gears and transmission technologies for the process of gear shaping. Technical Data Diameter: 1250 mm Module: 12 mm Face width: 210 mm Dimensions: 3,750 x 2,500 x 3,600 mm Machine weight: approx. 19,000 kg Fsdpfx Apeyw Hxnj Djpn *All details and data are non-binding. Subject to prior sale. Special Features: The machine is equipped with a digital CNC control by Siemens type 840 D, as well as digital servo motors and drive amplifiers. The control cabinet is air-conditioned. Sinumerik 840 D: PCU 50, 566 MHz, 256 MB RAM, NCU 572.4, 3-axis/spindle, NC memory 2.5 MB, PLC memory 96 KB, 19” flat operating panel OP 10 C, 10.4” flat screen, electronic handwheel for linear axes, diagnostic system for error messages, warnings, and informational texts.

Condition: good (used), max. ram stroke 230 mm throat 230 mm table diameter 0 mm are offered : 2 pieces of shaping spindle for Lorenz gear shaping machines type LS 630 to LS 1250 1x overhauled new 1x has to be overhauled. Year of manufacture: unknown Fsdpfxsw Ny S Rs Ap Dspn

Condition: used, Year of construction: 1998, machine/vehicle number: 000373, Comm. no.: Lg 34723 Double decoiler LORENZ HH 2000.2 Used, in good condition year of construction 1998 - machine no. 000373 with - hydraulic spreading and automatic retensioning - belt center adjustment manually via spindle - counterholder with quick clamping - circular protection ring - easily exchangeable clamping cylinder (service-friendly) - manual swiveling - direction of rotation changeover (top-bottom unwinding) load capacity max. 2.000 kg/side strip width max. 300 mm Coil inner diameter approx. 360 to 420 Coil inner diameter approx. 460 to 520 mm Coil outer diameter max. 1,800 mm Fsdpfx Asnbdyaep Dspn with drive via three-phase geared motor and pneu. brake. drive power approx. 2.2 KW/side Unwinding speed approx. max. 40 m/min. Coil limitation via fixed limiting ring at the rear and adjustable counterholder (with quick clamping) at the front. Coiler stand with base frame with lateral shifting for coil center positioning. Currently without electric control. Can be re-engineered and offered on request.

Condition: like new (used), functionality: fully functional, overall weight: 7,000 kg, This machine is configured with 4 fully electronic CNC axes and has integrated software that generates the automatic program. Description Maximum gear diameter: 400 mm Gear width: 76 mm Stroke: 82 mm Rotation: 150 - 700 rpm Module: min. 0.5 mm Module: max. 6 mm Machine weight: approx. 7500 kg Electrical equipment: – Operating voltage: 380/400 V – Protection: 20kva Machine with new CNC Siemens 808D Siemens drives and servomotors New update 2025 Screens for automatic program generation Automatic cycles NR12 Included in Chip conveyor Coolant tank Automatic lubrication Fedpfx Apswvbqij Depn Digital pressure controls Hydrostatic guide

Condition: good (used), Year of construction: 1965, max. wheel diameter 900 mm max. module 6,5 stroke up to 150 mm table diameter 900 mm table hole 360 mm weight 3,7 t External: max. diameter 900 mm Max. gear width 150 mm Internal: Max. diameter 630 mm Max. gear width 150 mm Spindle bore table 360 mm Table diameter Ø 900 mm Module 6.5 mm Length 2500 mm Width 2300 mm Fsdpjywnt Tjfx Ap Dopn Height 2600 mm Weight 4100 kg

Condition: good (used), Year of construction: 1975, max. wheel diameter 630 mm y-travel 560 mm gear width 180 mm Fpjdpfx Apeyb Sx Ts Dsn max. module 8 min. module 1 workpiece dia. 750 mm table diameter 450 mm draw-in arbor diameter 58 mm spindle stroke 200 mm adjustment range 230 mm distance between table/spindle 225-450 mm taper Morse 4 down feeds 0,03 mm/Hub roll feed 10n: 0,18-0,74 mm/Hub no. of strokes 12n: 47-300 Hub/min electrics - voltage/frequency 380/50 V/Hz weight of the machine ca. 5500 kg The machine was raised by 100 mm.

Condition: used, max. wheel diameter 180 mm gear width 45 mm Fsdpfju Uu S Tjx Ap Dopn max. module 4 min. module 0,5 stroke length max. 0 - 52 mm spindle taper innen MK 4 table diameter 160 mm table bore diameter 75 mm no. of strokes 355 - 630 Hub/min feed range 0,008 - 0,4 mm/Hub dimensions of the machine ca. 2,30 x 1,50 x 2,36 m power capacity 6 kW weight of the machine ca. 2.500 kg Year of construction: Approx. 1970

Condition: used, Year of construction: 1998, sheet width:130 mm coil weight:0,150 t coil internal dia.:300 mm Fpjdeh Ra I Tspfx Ap Dsn coil external diameter:1000 mm dimensions of the machine ca.:0,75 x 1,50 x 1,70 m volt:230 V total power requirement:0,25 kW weight of the machine ca.:0,3 t Motor-driven Decoiler with mechanical central expansion, stepless coil speed, tip switch, emergency cut-off.
