Used Radial Drilling Machine for sale (65,389)

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 30100 € 574.91 € 50 mm MK 5 360 - 1.250 mm 44 - 1.206 (12) U/min Stahl/Guß: M40/M50 2060 mm 995 mm 2240 mm 2300 kg 441 - 1.345 mm 0,06 - 0,2 (3) mm/min 3.7 kW 300 mm 270 mm 1.785 x 785 x 190 mm 0,75 kW 635 x 520 x 420 mm 2645 mm 0,75 kW left/right rotation automatic feed drilling depth limit manual headstock adjustment with hydraulic clamping electric height adjustment of extension arm andhydraulic clamping hydraulicclamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment Hedpfx Aoynmt Esh Uefn machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH

Condition: excellent (used), Year of construction: 1987, functionality: fully functional, Drilling capacity in steel: 50 mm Throat depth: 30 - 1650 mm Max. workpiece height: 940 mm Horizontal travel of drill head: 1300 mm Spindle taper: MT 5 Drill spindle stroke: 360 mm Spindle speeds: 31.5 - 1400 rpm in 12 steps Hfsdpfxjxl Tqqe Ah Usn Weight: 3.8 t

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, drilling capacity: 40 mm, quill travel distance: 200 mm, table length: 1,200 mm, table width: 600 mm, drill spindle length: 200 mm, overall weight: 1,700 kg, input voltage: 400 V, travel distance Y-axis: 780 mm, input frequency: 50 Hz, distance table to spindle center: 800 mm, Donau DR40 Z Manufacturer: Donau Machine type: Radial drilling machine / Quick-change radial Designation: DR40 Z Year of manufacture: 1992 Drilling capacity: 40mm Threading capacity: M33 in steel Taper: SK 40 Feed rate: 0.075 - 0.15 – 0.3 – 0.45 – 0.6 / revolution Drilling spindle speed: 18 Overhang: 800mm Drilling spindle stroke: 200mm Vertical adjustment of the drilling spindle head (electric): 450mm Max. distance between table and spindle: 780mm Table: 600x1200mm Machine weight: 1700 kg Documents: Operating manual, wiring diagram, spare parts list, test report The machine was completely overhauled by Vaumatec, 89431 Bächingen, in 2016 and has been used very little since. The machine is in very good condition. Purchased in 2016. Hsdpfx Ahez Da Idj Usfn

Year of construction: 1973, condition: used, bore capacity in steel (diameter) 32 mm arm length 410 - 1000 mm workpiece height max. 765 mm coolant ja boring spindle diameter 38 mm diameter of quill 70 mm spindle stroke 225 mm boring spindle MK 4 mm/min spindle turning speed - stepless 70 - 2000 U/min feed range - spindle 0,04 - 0,32 mm/U column diameter 225 mm bore radius max./min max. 1130 mm table surface area 630 x 1320 mm height adjustment 500 mm base plate 1500 x 1000 mm T-slots 4 Stück Hsdpfx Ahsgmu A So Ujfn T-slot - distance 18 mm total power requirement 2,2 kW weight of the machine ca. 1,8 t dimensions of the machine ca. m shift of supports: 590 mm without turntable and tools

Condition: used, Year of construction: 2007, bore capacity in steel (diameter) 40 mm arm length 1050 mm turning speeds 15 - 2800 U/min feed range 0,075 - 0,45 mm/min dimensions 2450 x 1300 x 2300 mm Weight 1500 kg Equipment: Machine in top condition Hfsdpfey Nd T Hjx Ah Ujn 2026 serviced and repaired by the factory customer service Machine design - Work table 1800 x 600 mm with 4T-slots - Boom travel 1050 mm - SK 40 drilling spindle with tool clamping device - Infinitely variable speed programming - Infinitely variable quill feed via three-phase servo motor - 2 T-slots 18 mm on the machine base at the rear - 2 T-slots 18 mm on the left machine base frame - Thread cutting device - Central lubrication - Coolant device - Machine light - CE marking - Safety device - USB interface Dimensions and travels Tool holder SK 40 Column diameter mm 195 Table dimensions mm 1800 x 600 Number of T-slots 4 Distance between T-slots mm 125 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 410 Distance spindle bottom edge - min mm 70 Table top edge max. mm 680 Distance spindle bottom edge - min mm 970 Floor max. mm 1580 Drilling radius mm 540 - 1590 Worktable height mm 900 Cutting values Drilling capacity into solid St 60 ? 40 GG 22 ? 50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100 % ED. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 2000 Feed drives X-axis - AC - servo motor kW 0.25 Y-axis - AC - servo motor kW 0.25 Z-axis - AC - servo motor kW 4.50 W-axis - AC - servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7,5 / 7,5 / 5 Rapid traverse speeds (W): m/min. 3 Feed rates stepless mm/min 5 - 2000 Accuracy Positioning accuracy X-, Y-axis to 1200 mm mm ± 0.075 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC control Axes: 3 (X, Y, Z, ) Processor: 32-bit CPU Screen: TFT flat screen, backlit, easy to read from all sides readable from all sides, 215 x 160 mm Position information: Cartesian or polar, absolute or incremental measurements, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, material-dependent cutting data suggestions Tool management: max. 500 tools Subroutine technology: yes Standard software options: Programming in dialog, 38 zero offsets, rotation and mirroring, teach-in for X,Y,Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for by manually probing the workpiece for: - any clamped rectangular parts - any clamped round parts - Mediation of cast and flame-cut parts - Angular position detection for round parts by touching reference edges or surfaces Test graphic Graphic display of drilling patterns

Condition: like new (used), Year of construction: 1990, Drilling capacity in steel: 50mm Drilling capacity in cast iron: 63mm Hfodjg I I Ekjpfx Ah Ujn Spindle: MK4 Spindle Speeds: (12) 45-2000 RPM Drill head displacement: 350-1250mm Distance spindle base plate: 350-1420mm

Condition: good (used), Year of construction: 1962, High speed radial drilling machine, radial drilling machine, drilling machine, boom drilling machine, high speed radial drilling machine Hodpfx Aheirax Uj Usfn -Clamping table: 400 x 1100 mm -Projection: 930 mm -Taper mount: MK4 -Engine power: 1.35/1.8 kW -Speed: 41-1700 rpm -Columns: Ø 200 mm -Spindle stroke: 125 mm -Thread cutting device: YES -Feed: 0.075 - 0.3 mm/rev -Dimensions: 1800/1235/H2240 mm -Weight: 1500kg

Condition: good (used), Year of construction: 2000, machine/vehicle number: 152362081, functionality: fully functional, throat depth: 2,700 mm, spindle diameter: 110 mm, sheet thickness steel (max.): 100 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 9 rpm, Radial drilling machine MAS U 1000 Hedpsrwxpfsfx Ah Usfn Year of construction 2000 Conventional / digital control With face plate 1,000 mm and tool package Viewing is possible at any time by arrangement. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: Radial drilling machine MAS | MAS1000 | U1000

Condition: good (used), Year of construction: 1965, functionality: fully functional, throat depth: 930 mm, For sale is a Donau brand DR30 high-speed radial drilling machine. The machine is in good and fully functional condition. Technical specifications: Year of manufacture: 1965 Drilling capacity in steel (diameter): approx. 30 mm Hfodpfx Aswal Hpsh Ujn Tapping capacity in steel: approx. M36 in cast iron Spindle mount: MK 3 Spindle speeds: Continuously variable approx. 45 - 2240 rpm Quill stroke: approx. 170 mm Thrust: approx. 930 mm Boom swivel range: 360° Table size: 1200 x 500 mm Spindle motor power: 4.0 kW Weight: approx. 1.8 t Dimensions (L x W x H): approx. 1.3 x 2.1 x 2.45 m Tapping device with shut-off and reversing. Motorized boom height adjustment. Left-hand drilling control, hand and foot. Transport and loading can be arranged throughout Europe upon request for an additional charge. Prices exclude VAT. Viewings are available by appointment. Contact us; our team will be happy to assist you. Trade-ins or exchanges are possible! Machine Purchase/Sale PURCHASE/SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality, yet affordable metalworking machine for your production? Or do you want to sell yours? For further information or to contact us, visit our website.

Condition: refurbished (used), Year of construction: 2006, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, • Work table 1200 x 750 mm with 5 T-slots Hfjdpsx Uwpxofx Ah Uon • Arm travel 1050 mm • Drill spindle Morse taper 4 (MK 4) • Infinitely variable speed control • Infinitely variable quill feed • Thread cutting attachment • Two 18 mm T-slots each on rear and left of machine base • 3-axis digital readout • Machine lamp • Central lubrication • Table top machined all around • Drill guard • Coolant system Dimensions and Travels Tool holder MK 4 Column diameter mm 195 Table size mm 1200 x 750 Number of T-slots 5 T-slot spacing mm 125 Quill stroke mm 220 Column travel mm 450 Distance spindle nose - table top min 40 mm, max 710 mm Distance spindle nose - base plate min 840 mm, max 1510 mm Drilling radius min 540 mm, max 1590 mm Work table height mm 900 Machining Capacities Drilling capacity (solid) St 60 ⌀ 45 mm GG 22 ⌀ 55 mm Tapping St 60 M 36 GG 22 M 45 Main Spindle Drive AC motor, frequency controlled kW 5.5 at 100% duty cycle Speed range min⁻¹ 15 – 2,800 Torque Nm max. 250 Constant from min⁻¹ 15 – 200 Feed Drives Feed, stepless mm/rev 0.02 – 0.7 Feed force N 12,000 Electrical Data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Total connected load kVA 9.3 Weight DANUFLEX 145 (without packaging) with table 750 x 1200 mm kg 2,600 Documentation Operating manual, incl. Lubrication and hydraulic system diagram Electrical wiring diagram

Condition: used, Year of construction: 1957, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1000 horizontal adjustment of the boring slide: 700 mm vertical adjustment of arm: 600 (motorisch) mm swivel range of the arm: 90° rechts/links Grad distance table - lower edge spindle: min./max.: 200 / 1120 mm Hjdpfxevhbpqe Ah Ujfn spindle taper MT: 4 bore spindle stroke: 420 (manuell-automatisch) mm range of revolutions per minute - continous: 20 - 2000 / 3 step U/min feed: 01, / 0,2 / 0,3 / 0,4 / 0,8 / 1,2 mm/U column diameter: 250 mm base plate surface area: 1100 x 600 mm total power requirement: 4,6 kW weight of the machine ca.: 2,5 t dimension machine xH: 1,8 x 0,8 x 2,5 m Tool ejection via expulsion wedge Equipment: Coolant system with pump (without feed) Drill cube L: 760 x W: 500 x H: 510mm / horizontal surface 760 x 500mm and vertical surface 760 x 510mm Machine ilumination *

Condition: used, Year of construction: 1960, Technical details: workpiece height max.: 600 mm Arm length: ca. 700 mm bore capacity in steel (diameter): 25 mm Table dimensions: 1100 x 400 mm Hfsdpfxjx Afn Nj Ah Uon

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Machine Specification • Work table 1800 x 600 mm with 4 T-slots • Traversing arm travel 1050 mm • Drilling spindle SK 40 with tool clamping device • Infinitely variable speed programming • Infinitely variable quill feed via three-phase servo motor • 2 T-slots, 18 mm, rear side of machine base • 2 T-slots, 18 mm, left side of machine base • Thread cutting unit • Central lubrication • Coolant system • Machine light • CE marking • Safety device • USB interface Dimensions and Travel Ranges Tool holder: SK 40 Column diameter: 195 mm Table dimensions: 1800 x 600 mm Number of T-slots: 4 Distance between T-slots: 125 mm Quill travel (Z-axis): 200 mm Column travel (W-axis): 410 mm Distance spindle nose – table (min): 70 mm Distance spindle nose – table (max): 680 mm Distance spindle nose – floor (min): 970 mm Distance spindle nose – floor (max): 1580 mm Drilling radius: 540 – 1590 mm Working table height: 900 mm Machining Capacities Drilling capacity (solid): St 60: ⌀ 40 mm GG 22: ⌀ 50 mm Tapping: St 60: M36 GG 22: M42 Main Spindle Drive AC motor, frequency controlled: 5.5 kW at 100% duty cycle Speed range: 15 – 2800 rpm Torque: max. 250 Nm Constant torque from 15 – 2000 rpm Feed Drives X-axis - AC servo motor: 0.25 kW Y-axis - AC servo motor: 0.25 kW Z-axis - AC servo motor: 4.50 kW W-axis - AC servo motor: 2.50 kW Rapid traverse (X/Y/Z): 7.5 / 7.5 / 5 m/min Rapid traverse (W): 3 m/min Infinitely variable feeds: 5 – 2000 mm/min Accuracy Positioning accuracy X, Y axis (over 1200 mm): ± 0.075 mm Electrical Data Operating voltage/frequency: 400 V / 50 Hz Control voltage: 24 V Hydraulic unit for clamping: 0.75 kW Total connected load: 13.0 kVA Weight (Danumeric 440, without packaging, with 1800 x 600 mm table): 2800 kg CNC Control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Display: TFT flat screen, backlit, easily readable from all sides, 215 x 160 mm Position indication: Cartesian or polar, absolute or incremental Measurement units: mm or inch or degrees Interpolation: 2 axes (X, Y) Hodezrr Uujpfx Ah Ujfn Technology Database: Tool management, tool suggestions based on machining operation, material-dependent cutting data suggestions Tool management: max. 500 tools Subprogram function: yes Machining Cycles Standard software options: Conversational programming, 38 reference point shifts, rotation and mirroring, teach-in for X, Y, Z, program restart with selectable entry functions Zero point determination: cycles for determining reference points by manual probing of the workpiece for: - Arbitrary clamped rectangular parts - Arbitrary clamped round parts - Centering of cast and flame-cut parts - Angle position detection for round parts by probing reference edges or surfaces Test graphics: Graphical display of drilling patterns

Condition: used, Year of construction: 1956, total width: 900 mm, total length: 2,050 mm, total height: 2,100 mm, Colour: Green Empty weight: 2.400 kg - Year: 1956 - Serial number: 3706 - Drive system: Conventional - Drive system: Gear drive - Number of drills [pcs]: 4 - Power [kW]: 6 - Table type: Fixed table - Table length [mm]: 1800 - Table width [mm]: 350 - Drilling depth [mm]: 160 Hodpjz R Dt Eefx Ah Uofn - Drilling capacity [mm]: 25 - Reach [mm]: 275 - Main spindle power [kW]: 6.0 - Min. spindle speed [rpm]: 180 - Max. spindle speed [rpm]: 2000 - Options: Tapping function - Transport dimensions: 2050mm x 900mm x 2100mm (l x w x h) - Transport weight [kg]: 2400kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 1972, bore capacity in steel (diameter) 50,0 mm arm length 1.350 mm workpiece height max. 1630 mm turning speeds 19 - 1320 U/min bore spindles - Morse Taper 5 MK engine output 5,5 kW weight 5 t Hfodpfx Ahowiikdj Uon range L-W-H 2,4 x 1,0 x 3,55 mm feed movement 475 mm floor plate size: 1650x1000 mm feeds 0,07-2,9 mm/U

Condition: used, Year of construction: 1997, bore capacity in steel (diameter) 40 mm arm length 1.000 mm workpiece height max. 1.250 mm table-size 1.150 x 690 mm spindle taper MT 4 spindle turning speed range 40 - 1.400 U/min feed range 0,08 - 0,40 mm/min crossrail adjustment horizontal 800 mm crossrail adjustment vertical 700 mm spindle stroke 220 mm power requirement 3,5 kW voltage 380 V total power requirement 4,0 kW weight of the machine ca. 1,6 t - Serial-No.: A01/446/97 - adjustable cube table 600 x 500 x 500 mm Hfodel Ha Twjpfx Ah Uen - coolant device - machine light

Year of construction: 2003, condition: not inspected (used), functionality: unexamined, clamping length: 3,200 mm, pipe diameter (max.): 30 mm, HEBÖ RBV 12 Pipe Drilling Machine - Through-hole diameter of the chuck: 30 mm Hodpfoz Spx Ajx Ah Uefn FCA D-35614 Aßlar - loaded onto a truck.

Condition: used, Year of construction: 1964, bore capacity in steel (diameter) 65 mm arm length 2000 mm workpiece height max. 1800 mm surface area 900x2000 mm Hfsdpsy Swhpofx Ah Usn turning speeds 1400 U/min The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1969, arm length 1600 mm Hjdpfxsx H Txte Ah Uofn taper MK 5 Würfel

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 32 mm arm length 1000 mm workpiece height max. 1400 mm total power requirement 6 kW Hfodpfx Ahjt H Smye Ujn weight of the machine ca. 3.700 kg dimensions of the machine ca. m

Year of construction: 1963, condition: used, Radial drilling machine, drilling machine, boom drilling machine, universal drilling machine, milling machine -Projection: 645 mm -Taper mount: MK3 -Speeds: 95 - 1050 rpm -Columns: Ø 190 mm -Spindle stroke: 195 mm -automatic feed: 0.05/0.10/0.20 mm/rev -Clamping table: 735 x 520 mm -Dimensions: 1350/705/H2170 mm Hfjdpfjdvnbxox Ah Uen -Weight: 1100 kg

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 50 mm arm length 1250 mm workpiece height max. ca. 1150 mm bore capacity in cast iron 60 mm spindle taper MK 5 spindle turning speed range 25 - 2000 U/min feeds 0,06 - 0,5 mm/U crossrail adjustment vertical 620 mm column diameter 350 mm total power requirement 7,5 kW weight of the machine ca. 4,6 t Hedpsvh Nbhsfx Ah Ujfn dimensions of machine L x W x H 2,50 x 1,08 x 2,50 m Accessories: box table 1100 x 700 x 550 mm, coolant pump

Condition: used, Year of construction: 2005, Second-hand machine Year of manufacture: 2005 Features and technical specifications: - Motor: 400 V, 50 Hz, 3-phase, 1.5 kW - Pneumatic single-head drilling machine with 23 spindles - Aluminium ruler with 4 stops (2 profiles on the right/left, 1500 mm each) - with quick-action chuck - 2 patented, accident-proof pressure clamping cylinders - Connection for extraction system in accordance with EC standards - Aluminium drilling beam, spindle centre distance 32 mm - Work table made of MDF and cast iron - Patented spiral system for fine adjustment of the drilling depth - Pneumatic drilling head oscillation with Lockable in any position between 0° and 90° - Fold-down side stops with fine adjustment via counters with decimal display - Drilling height adjustment via dial gauges with decimal display - Back stop, travel up to 300 mm - Fixed stops 37 mm for fitting pot-type band drills - Complies with EC standards - Max. drilling width 704 mm - Max. drilling depth 65 mm - Max. workpiece width 960 mm Hsdpfszk N S Uex Ah Uofn - Max. workpiece length 3000 mm - Max. workpiece thickness 60 mm Availability: at short notice Storage location: 63934 Röllbach

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 585 mm, travel distance Y-axis: 240 mm, travel distance Z-axis: 145 mm, spindle speed (max.): 2,340 rpm, spindle speed (min.): 32 rpm, spindle mount: MK 0, throat depth: 293 mm, quill diameter: 72 mm, quill stroke: 145 mm, total length: 1,340 mm, total height: 2,050 mm, table width: 225 mm, total width: 1,280 mm, table length: 800 mm, drilling capacity: 40 mm, spindle nose: ISO40, spindle diameter: 72 mm, nominal power: 3 kW (4.08 HP), Milling-/Drilling Machine, DRO, drilling capacity Ø 40 mm, motor 2,2/3,0 KW, table size 800x225 mm, spindle speed 32-3240 rpm stepless, ISO40, pneum. tollclamping el. tapping device, table stroke X/Y 585/240 mm, automatic spindle feed, coolant device, dimensions 1340x1280x2050 mm, weight ca. 780 kg Hfedpfx Ahoz Rqfzj Uon

Condition: used, Year of construction: 1997, Second-hand machine Year of manufacture: 1997 Condition: well-maintained Features and technical specifications: - Number of drilling spindles: 21, spaced at 32 mm intervals - Drilling direction: from below & from the front - Swivel range: 0–90 degrees via handwheel Hfjdpfx Aozk Nuijh Usn - Pneumatic workpiece clamps: 3 pcs. - Passage dimensions: max. 100 mm in height and max. 640 mm in width - Motor: 1.5 kW - Extraction diameter: 120 mm - Includes a wide range of stops (see images) Availability: at short notice Storage location: Röllbach
