Used glue coating machines for sale (81)

Condition: excellent (used), CATALOGUE NUMBER 7554 Technical data: - roller width 1350mm - max. pass height 70mm - glue application on one or both sides - 2-roller - diameter of glue-applying rollers (top/bottom) 160mm - main motor 0.75kW - dimensions (length/width/height) 2000x750x1550mm - weight approximately 534kg Prsdpfxjzx R R Uj Airjc ADVANTAGES – German production – used glue applicator – very good condition Net price: 13900 PLN Net price: 3230 EUR, depending on the exchange rate of 4.3 EUR (Prices may vary due to exchange rate fluctuations)

Condition: ready for operation (used), functionality: fully functional, External dimensions: 2500 × 1300 mm Stepless feed speed adjustment Prodpfoxcw Afjx Airsc Year of manufacture: 2017 Motor power: 0.75 kW

Condition: excellent (used), Catalog number: 7721 TECHNICAL DATA - Working width: 1300 mm - Maximum pass height: 60 mm - Rubber rollers: 2 pcs - Rubber roller diameter: 190 mm - Motor: approximately 1.1 kW Psdpfxezrlrae Airsrc - Dimensions (L/W/H): 2020x770x1260 mm - Weight: 500 kg FEATURES – Used glue applicator – Very good condition Net price: 14,900 PLN Net price: 3,470 EUR, depending on the exchange rate of 4.3 EUR (Prices are subject to change due to fluctuations in the exchange rate)

Condition: used, Year of construction: 2010, Used machine Year of manufacture: 2010 Features and technical specifications: Right-hand configuration 2 side tables are still in their original packaging H&H / HARDO TH 1020-V46 BV DA (twin unit) Max. application width: 2,040 mm (2 × 1,020 mm) Configuration: Twin-unit system, both machines can also be operated individually Application roller: reinforced version Application roller diameter: 46 mm Knurling on application roller: 0.5 mm Bearings: reinforced roller bearings Bearing shells: hardened Squeegee: pneumatically operated, needle-bearing mounted Main bearing lubrication: external lubrication, filled using a hand-operated grease gun Tank seal: adjustable and replaceable without removing the application element Application speed control: via frequency converter Speed range: 3.2 – 19.3 m/min Control: Potentiometer Display: digital speed display Pressure rollers: 2, silicone-coated Pressure rollers, length: 2,040 mm Pressure rollers – diameter: 159 mm Pressure rollers – Actuation: pneumatic Pressure rollers Lowering: automatic after the drive motor is switched off Height adjustment of material feed: electrically driven in manual step mode Stroke of application unit: 0 – 200 mm Conveying height: 925 mm (lower edge of material) Drive for pressure rollers: separate drive Motor: including motor console, mounting and cladding Additional application speed control: via separate frequency converter Additional speed range: 3.2 – 19.3 m/min Additional control: Potentiometer Predpszk Nzvjfx Airjc Additional display: digital speed display Base frame: aluminium profile system Stands: 2, made from anodised aluminium plates Adjustable feet: Adjustment range ±25 mm Material flow direction: right to left Heating control: Timer (daily and weekly programme) Temperature control: electronic with digital actual value display Melting tank volume: 2 × 25 litres Heating capacity: 2 × 8.0 kW Rated power: 18.5 kW Control voltage: 24 V Rated frequency: 50 Hz Operating voltage: 400 V Phases: 3 Fuse rating: 63 A Compressed air connection: < 8 bar Application: Melting and application of non-reactive hot-melt adhesives Weight: 1,560 kg Availability: at short notice Location: Rhineland-Palatinate

Condition: excellent (used), Profiles / mouldings wrapping line Composed by: a) “DOUCET” loading-infeeding system, Model MSP-APV-408 Predpfx Aszxrakjiroc b) “SCM” moulding machine, model SuperSet XL c) “BARBERAN” wrapping machine, model PUR-31-LD d) “NORDSON” PU glue melter-dispenser, model VersaBlue

Condition: excellent (used), LAMINATING LINE for panels (particleboards, MDF, HDF) Minimum/maximum panel dimensions: mm 600-1550 (width) x mm 1854-3660 (length) Minimum/maximum panel thickness: PB/MDF mm 8 - 44 (standard mm 16-19-22) // HDF mm 2,5 - 8 Predpfszxrgwox Airoc Adjustable working speed: m/min 8 - 29 Minimum/maximum working cycle (Feeder and Stacker): 6 cycles/min - 10 cycles/min 01) "KONTRA" Loading station (with stack chain conveyor, 2 Lifting platforms, Feeding station) 02) "KONTRA" Roller conveyor with length guide rail 03) "KONTRA" 1 Vacuum transporter + 1 Stack chain conveyor for protection boards 04) HYMMEN LAMINATING SYSTEM a. "HYMMEN" Mod. FRB (Cleaning Machine) b. "HYMMEN" Mod. GLK-V (Smoothing Calender to uniform the workpieces surface) c. "HYMMEN" Mod. TLA (Glue spreading machine) d. "HYMMEN" Mod. TRC (Conveyor) e. "HYMMEN" Mod. ADZ (Evaporation / Flashing-off Zone) f. "HYMMEN" Mod. KKL (Laminating Calender) g. "HYMMEN" Mod. DSS (Double-belt continous press) h. "HYMMEN" Mod. PWG (Pressing conveyoring rollers) i. "HYMMEN" Mod. FAA (Foil Unwinding Station) j. "HYMMEN" Mod. GLK (Final Calender) 05) "KONTRA" 1 Speed-up roller conveyor with length guide rails on both sides and pusher 06) "KONTRA" Unloading station 07) "KONTRA" 1 Protection board magazine

Condition: used, Year of construction: 2009, Adhesive application machine Manufacturer: Wirth Type: LW 120.5/1300 Year of manufacture: 2009 Technical data: - Roller width: 1300 mm - 2 rollers (application + metering) - 1 spare application roller Podpfszuzvyex Airsrc Note: Cables cut. Special price: 1,000.00 EUR

Condition: new, Year of construction: 2024, Osama Automatic 4-Roller Glue Application Machine Model: S4R/P-1400 Automatic gluing machine with 2 motors Working width: 1,400 mm Max. pass-through height: 0 - 100 mm Speed: 22 m/min Working height: 900 mm Diameter of application rollers: 250 mm Motor power: 3 kW Electrical: 400 V / 50 Hz / 3 phase Automatic gluing machine with 4 rollers for polyvinyl acetate (PVAC), urea-formaldehyde (UF), and polyurethane adhesives, suitable for various materials such as MDF, multi-layer boards, particle boards, composites, and gypsum plasterboard. This type of gluing machine allows for precise and homogeneous dosing of adhesive, taking into account the corrugation of the rollers, which must be suitable for the respective production requirements. The heavy-duty structure and the roller cores, manufactured with greater thickness compared to earlier models, enable a high production rate without issues and bonding of materials up to 2200 mm in width. Roller removal for maintenance is straightforward, as the supports can be split in two via a simple bayonet coupling. The gluing machine can also be equipped with different accessories, such as an electronic speed controller, automatic roller washing device, and an automatic upper roller lifting mechanism with position display on the control panel. The S4R/P gluing machine is used in various production sectors, including construction and the manufacturing of foam panels and mattresses. Equipment: - Automatic roller cleaning - Infeed roller - Outfeed roller - Working height: 900 mm - Infeed table TRF 1400x3000 mm with PVC rollers, 60 mm diameter, 200 mm spacing - Outfeed table TDF 1400x3000 mm with disc rollers, D: 122 mm, stainless steel Prsdpfx Aeu I R Uteiroc Location: in stock at 54634 Bitburg - Available immediately -

Condition: excellent (used), Year of construction: 1994, I sell the side glue spreader Fischer Ruckle FLA,  Year 1994. Pedjt N Hhkspfx Airerc Suitable for solid wood glulam boards production. Throughfeed with feeding. Very good condition. Available immediately.

Condition: excellent (used), Year of construction: 1998, HÖFER LAN 1300 Adhesive Coating Machine For the efficient application of water-soluble dispersions (white glue, etc.) on one or both sides. Coating width: maximum 1300 mm Drive: 0.37 kW geared motor Rubber-coated coating rollers: Ø 170 mm Grooving for coating quantity: approx. 120 g/m² (for veneers) Constant coating speed: approx. 16 m/min Working height: approx. 900 mm Maximum workpiece thickness: 80 mm Design complies with CE standards Psdpfx Aisza A Aajrsrc Manual feed Operating side: right Including swivel casters Machine dimensions L x W x H = 1750 x 660 x 1300 mm

Condition: used, Year of construction: 2008, used, good condition with automatic length measuring device Manufacturer: Ayen Type: Magnum 8/10 V Year of manufacture: 2008 Machine No.: 0826788 Glue tank: 1.4 ltr. Prjdpfxoy A Tbgj Airec Dowel diameter: 8 x 10 mm Dowel length: 30-45 mm with glue indicator CE type-tested Glue gun mobile Space requirement approx. 480 x 480 x 900 mm Weight approx. 71 kg Storage location: 97447 Gerolzhofen, free loaded, unpacked Delivery in as-inspected condition without warranty or guarantee

Condition: used, Year of construction: 2016, Used machine Year of manufacture 2016 Equipment and technical data: Prjdpfx Aozlbn Reirjc - Bag melter for 2 to 3 kg aluminium-bag packs - Type of glue pump: gear pump - Nominal pump speed: 93 rpm - Base tank size (reservoir): approx. 2 l/h - Melting capacity: up to 5 l/h - Temperature sensor PT-100 device and external heaters - Control accuracy: +/- 1° C - Heaters (device): 2 heating zones; base tank and pre-melting plate, separately controllable - Connected load: 5 kW Dimensions: 1100 x 500 x 1100 mm Weight: approx. 110 kg Availability: at short notice Location: 63934 Röllbach

Condition: used, Year of construction: 2009, Second-hand machine Year of manufacture: 2009 Condition: factory-refurbished by Osama Technologies Features and technical specifications: Pedpozk Nxbsfx Airerc - Automatic gluing machine with two rollers - Working width: 1000 mm - Usable working thickness: 0–100 mm - Application rollers Ø 185 mm - Feed speed 24 m/min - Work surface height: 800 mm - Groove spacing between rollers: 2 mm - Motor power 0.37 kW - Glue distribution tank made of painted sheet metal - Water tank made of galvanised sheet metal - CE marking - Voltage 400/50/3Ph Availability: at short notice Location: Röllbach

Condition: good (used), Code: 0383 Brand: DUE B.ERRE STEMA - ITALY Model: SPINAMATIC GLF HP - CE Standard Machine for applying thick glue and dowels with pneumatic gun for panels, for doors, windows and various - CE Standard Technical data Max insertion capacity 60 dowels per minute Dowel diameter mm 10/12 mm Dowel length mm 25 to 50 mm Prsdey N Uq Aopfx Airoc Max insertion depth 30 mm Machine works with one diameter of dowels at a time Electronic dosing of glue quantity Washing system Flexible arm provided with counterweight that makes the gun lighter during the work cycle (gun weight approx 3 kg) Recommended adhesive type: Water-based emulsion adhesive - Viscosity Brookfield 580 mPa.s - Solids content 30% - Min film formation temperature 3–5 °C - Cleaning with water Wheels on base Voltage 220 V single-phase Max pressure 6 atm Overall dimensions mm 600 x 1000 x 2100 h Weight kg 130

Condition: used, Two-roll spreader with manual cleaner Prsdpfsywy T Eox Airsc

Condition: used, Technical data: Working width: 300 mm Maximum roller spacing: 60 mm Safety switch Adhesive dosage adjustment Manual roller spacing adjustment Pjdpfox Hgrgsx Airerc Power supply: 400 V Motor power: 1.5 kW Overall dimensions: Length: 830 mm Width: 880 mm Height: 1410 mm

Condition: good (used), Year of construction: 2021, functionality: fully functional, PUR melting device for aluminum pouches/cartridges, with hose and filling head for use on edge banding machines Weight approx. 73 kg Melting capacity up to 2 kg Gear pump Pedpfxjy S Rw Re Airjrc All heaters can be adjusted separately With electronic interface for glue level detection in the gluing section of the edge banding machine (level sensor "Tippkemper" for glue application, provided by the edge banding machine manufacturer) Connection value 400 V, 50 Hz, 3Ph, N Device delivered completely cleaned and with PUR cleaner.

Condition: as good as new (ex-display), Year of construction: 2026, - NEW - Manufacturer: Ganner Gannomat Type: SELEKTA 253 220 V, 1 phase, 50 Hz complete in standard version with: - Fully automatic electronic control with program selector switch COILING-GLUING-INSERTING - Dowel feed via electronic vibratory feeder with potentiometer for stepless adjustment of the dowel feed rate - Automatic dowel diameter and dowel length control with Auto-DL-Select system (automatic ejection of incorrect dowel lengths +/- 5 mm into the collection container) - Closed gluing system with 6 bar glue pressure via glue nozzle for glues with a viscosity of 150 to 350 mPas - Stepless electronic glue quantity adjustment with potentiometer via time preselection through electronic control Prjdedwi Rkspfx Airjc - Selector switch GLUE/WATER for flushing/cleaning the gluing system with EasyClean function button (automatic cleaning program for glue hose and glue nozzle via spray funnel and dirty water collection container) - Control light for glue residue level indicator in the glue container - 1 stainless steel container for 5 kg of glue and 1 stainless steel container for 5 l of water for flushing/cleaning - 4 rollers for moving the machine including 1 gun for dowels Ø 8 mm, dowel length 25 - 40 mm Insertion allowance 7 - 20 mm Air connection: 6 bar Price ex warehouse 54634 Bitburg - immediately available -

Condition: used, functionality: fully functional, Equipment: double-sided, Amod CDL 1300, double-sided adhesive applicator Working width: 1300 mm Min./max. clearance: 0-90 mm Diameter of application rollers: 170 mm Two feed speeds Year of manufacture: 1994 Pedpfx Ajzrlykjirsrc

Condition: good (used), Code: 0298 Brand: OSAMA Model: S1R-250 - CE Standard Manual 1 roller gluing machine for edges and block wood, carpentry, furniture, laminated wood beams, and various - CE Standard Technical data: Max working length 250 mm Roller diameter 150 mm Feed speed 28 m/min Motor power Hp 0,25 Working table height 800 mm Overall dimensions mm 1500 x 700 x 850 h Weight kg 100 Psdpfx Aisyi E Hgsrsrc

Condition: like new (used), functionality: fully functional, Dowel inserting machine with operating gun for simultaneous glue application and dowel insertion Standard dowels Ø8 mm Dowels lenght 25 - 80 mm Predpjqu N U Djfx Airec Nominal capacity 1 dowel/second (includes glue application) Uses PVA adhesives (glue) in water dispersion viscosity 200-400mPa 1 pcs TANK FOR GLUE capacity 8 kg 1 pcs TANK FOR WATER capacity 8 kg Maximum pressure 5 bar

Condition: used, Year of construction: 1999, machine/vehicle number: 4127, SECOND-HAND 4 ROLLERS GLUE SPREADER OSAMA S4RP-1300 - WORKING WIDTH CM. 130 WITH GLUE MIXER Pjdpfxowr Dc Tj Airsrc - Mixer CLT-A (Automatic feeder for bi-component glue) Automatic mixing and feeding system of two-components vinyl and urea glues with catalysers, sulphate and isocyanate, for rollers gluing machine. This device is required for production in continuous. Standard version includes a mixing head mounted on the gluing machine, fed by special pumps for glue and catalyser. The pumps take the products directly form the storage tanks and they are activated by the level sensors placed between the rollers, thereby ensuring a constant level of glue. - Working width 1300 mm - Automatic washer for rollers - N. 4 rollers - Volt. 380/50 - S/N 4127 - Year 1999 - *m57

Condition: used, Year of construction: 2008, machine/vehicle number: 21543, SECOND-HAND 2 ROLLERS GLUE SPREADER OSAMA S2R 1300 - CE RULES - Chiller (Heat conditioner) Cooling system for vinyl glue, urea glue and polyurethane glue for rollers gluing machines with two and four rollers. This device is required to maintain the glue temperature between the rollers always constant, and to ensure the scheduled pressure time even with high temperatures - Mixer CLT-A (Automatic feeder for bi-component glue) Automatic mixing and feeding system of two-components vinyl and urea glues with catalysers, sulphate and isocyanate, for rollers gluing machine. This device is required for production in continuous. Standard version includes a mixing head mounted on the gluing machine, fed by special pumps for glue and catalyser. The pumps take the products directly form the storage tanks and they are activated by the level sensors placed between the rollers, thereby ensuring a constant level of glue. - Automatic washer for rollers Prsdpfxor Ixy Is Airec - N. 2 rollers - Volt. 400/50 - SN 21543 - Year 2008

Condition: like new (used), functionality: fully functional, Single-sided glue applicator OSAMA S2R-1300 Working width: 1300 mm Min./max. clearance height: 0-90 mm Applicator roller diameter: 185 mm Feed speed: 18 m/min Pjdpfx Ajx Tha Soirerc Motor: 0.37 kW Upper roller: grooved Lower roller: smooth New rubber roller coverings

Condition: excellent (used), functionality: fully functional, working width: 700 mm, pass-through height: 80 mm, Double-sided roller gluing machine / glue application machine Manufacturer: Bohrer Model: SL 70 Double-sided glue application machine, with disc roller conveyor at the outfeed Working width: 700 mm Passage height: approx. 80 mm Predpfxsx U T Tye Airoc Application roller grooved Height adjustment manually via handwheel Dimensions approx. 1300 x 600 x 1500 mm (LxWxH, without disc roller conveyor)
