Condition: excellent (used), Year of construction: 2017, operating hours: 1,412 h, Functionality: fully functional, CNC: Brother CNC Interface Unit CNC Vertical Machining center – Quick Turn Table Type 0 deg. / 180 deg. Turnable system Table dimension: 600 x 420 mm Max. turning diameter: 1021 mm Max. jig height: 300 mm Table work area size: 600 x 300 mm Max. loading capacity: 120 kg. Table position time 2.9s X axis travel: 450 mm Kelhccqsvta R Rstelp Y axis travel: 320 mm Z axis travel: 305 mm Spindle nose to table: 200 mm – 505 mm Automatic toolchanger 22 stations Spindle taper BT30 Spindle speed: 16.000 rpm Spindle Motor: 6.5 HP (4.9 kW)

Condition: excellent (used), Year of construction: 2013, Functionality: fully functional, Control: Fanuc 31i Model B Incl. Barfeeder FMB Turbo 3-36 Number of axes: 7 Number of spindles: 2 Main spindle: Max bar diameter: 32 mm Travel: 380 mm Spindle speeds: 8000 rpm Klelhccqsu E S Nmetop Spindle power: 7,5 / 10,5 kW Counter spindle: Max bar diameter: 32 mm Z stroke: 295 mm Spindle speeds: 8000 rpm Spindle power: 3,7 / 5,5 kW Machine floor space: 3000 x 1400 mm Machine height: 1857 mm Machine weight: 4300 kg.

Condition: excellent (used), Year of construction: 2000, Functionality: fully functional, Model: MIRACLE 081507  With RATIONAL-DMIS CAD version 6.9       Measurement range:   X = 800 mm, Y = 1500 mm, Z = 700 mm    Accuracy:   LEADER MIRACLE incl. PH10 head + SP25 – MPEe  SP25 E=2,7+3L/1000 L=mm    Temperature range:  Degrees: 20 – Total temperature variation +/-1°C over 48 hours.  Klelourf Egjhccqtop Otherwise according to the technical documentation    Renishaw probe system:  Renishaw PH10M  Renishaw SP25 Body scanning  Renishaw TM-20 “gentle” module incl. 1 pcs. Module  Renishaw SP25-1 incl. 1 pcs. Holder  Renishaw SP35-2 incl. 1 pcs. Holder  Key/probe set – Renishaw M2  Renishaw S3 Plus controller  Calibration ball Ø25.000 incl. Stand  Renishaw Rack for FCR25 incl. 6 pcs. Gates  Incl. Option “Tip changer”  Renishaw Joystick    Rational DMIS for Windows is an interactive graphics software that provides advanced options such as:  User-friendly operating system WIN7 or WIN8  Unique interactive 3D graphic engine import of Iges and Step format  Off-line programming and support of a simulated measuring machine environment  Powerful analytical report generation  Automatic intelligent naming of the measured object  Possibility of connecting a measuring machine to an optional CAD system that uses either IGES, STEP or DMIS  RATIONAL-DMIS CAD option for measuring and analyzing contours and form tolerances

Condition: good (used), Year of construction: 1998, Functionality: fully functional, Controller: OSP-7000L  Ø = 650 mm  Z = 1060 mm    Spindle bore: Ø120  VDI 60  Machine weight: 16000 kg.  Kjlhccjurf Dceqtjlp

Condition: excellent (used), Year of construction: 2006, Functionality: fully functional, machine/vehicle number: 188270, Controller: Mazatrol Matrix  Incl. Motoman Robot ES165-D100 – Payload 100 kg     Max. Machining diameter: 760 mm  Max. Machining length: 1524 mm    Main spindle:  Chuck size: 12  Max. Speed: 3300 rpm  Motor output: 30 kW / 40.0 hp    Milling spindle:  B-axis Travel 225°  Kelhccsurf Axoqtelp Magazine capacity: 20  Max. Speed: 12000 rpm  Motor output: 19 kW / 25 hp    Feed axes:  Travel:  X = 630 mm  Y = 230 mm  Z = 1585 mm  Full integrated Z-axis main and sub spindle

Condition: excellent (used), Year of construction: 1992, Functionality: fully functional, Controller: MF-T4  SMV Steady rest hydraulic  Kslsurf Arehccqtolp 15” Cartridge    Swing over bed: 670 mm  Swing over cross slide: 460 mm  Between centers: 1200 mm  Max. Machining diameter: 490 mm  Standard machining diameter: 257 mm  Max. Machining length: 1030 mm    X-Axis: 270 mm  Z-Axis: 1100 mm    Number of spindles: 1  Spindle speed rpm: 5 – 2500 min –1  Number of spindle speed rangers: 4  Spindlebore: Ø110  Front bearing inside diameter: 160 mm    Number of turrets: 1  Turret type: 12-station turret  Number of tool positions: 12    Rapid traverse rate mm/min: X: 12000 Z: 15000  Tailstock travel: 955 mm  Tailstock spindle diameter: 130 mm  Taper hole of tailstock spindle: MT4  Tailstock spindle travel: 150 mm    Main motor: 30/22 kW  Machine dimensions: 5410 x 3439 x 2379 mm  Machine weight: 11000 kg.

Condition: excellent (used), Year of construction: 1999, Functionality: fully functional, Controller: OSP 7000 L – DNC Option  Max. turning diameter 580 mm Turning length 1500 mm Greates pass round over bed 610 mm Swing diameter over slide rest 580 mm Main spindle: turning speed range - main spindle 12 - 2.800 min/-1 Spindle bearing diameter 150 mm Spindle bore 110/96 mm Spindle nose JIS A2-11 Power capacity - main spindle 37 (30) kW C-Axis 0,001 ° Axis stroke: x-axis 598 mm y-axis 230 (+110 / -120) mm z-axis 1.660 mm Feeds: rapid traverse X / Y: 12.000 mm/min cutting feed speed X / Z / Y: 0,001 - 1.000 mm/U Turret: type H2 ATC number of tool positions 2 (1x L-Tool / 1x M-Tool) pos. driven station stepless  Spindle speed - driven tool stations 40 - 3.000 min -1 Tool shank height 25 mm Boring bar shank diameter 50 mm  Tailstock: diameter of quill 120 mm quill stroke 170 mm taper of center MT 5  Tool magazine:  ATC 72 tool taper MAS BT 50 max. tool diameter 170 mm max. tool length 465 mm max. tool weight 20 kg drive of magazine 3,2 kW Kelhccqeurf Alotolp total power requirement 53 kVA  Helix Cutter  Weight of the machine ca. 18,5 t Dimensions of the machine ca. 6,0 x 3,2 x 3,0 m

Condition: excellent (used), Year of construction: 2005, Functionality: fully functional, machine/vehicle number: 114358, Controller: OSP-100L Turning diameter: 280 mm Circumference diameter: 320 mm Turning height: 200 mm Rapid traverse X-axis: 60m/min Rapid traverse Z-axis: 30m/min Speed range – spindle 40-4000 U/min Number of tool stations: 12 VDI 40 Machine dimensions: L=4500 x W=3000 x H=2700 Machine weight: 5500 kg. Kolourf Afjhccqtjlp

Condition: good (used), Year of construction: 2019, Functionality: fully functional, Including KUKA Robot “Smart Zell” KR 60-3 - Payload 60 kg   Serial number: 706912  Year 11/2019 Klelhccqsurfz Ujtsp

Condition: good (used), Year of construction: 2006, operating hours: 21,437 h, Functionality: fully functional, machine/vehicle number: 122574, Controller: OSP P200 L  Remarkably few spindle hours.    Max. turning diameter ø 720mm  2.000 mm distance between spindles  Spindle speed 3.500 rpm  Spindle power 30 kW  Sub-spindle; spindle speed 3.800 rpm  Spindle power 22 kW  Spindle speed aangedr. Ger 5.000 rpm  Spindle power aangedr. Ger. 22 kW  Klelhccqeurfz Ijtop Number ger. Under 12 Turret  Upper mill spindle HSK100 ATC 32 HSK 100   Y-axis 250 (+125 / 1-125) mm  Floor space: 6150 x 3073
