Used Briquetting Machine for sale (64,249)

Condition: defective spare-parts repository (used), Year of construction: 1991, functionality: not functional, travel distance X-axis: 700 mm, travel distance Y-axis: 350 mm, table width: 380 mm, table length: 925 mm, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel X-axis: 700 mm Travel Y-axis: 350 mm Table size: 925 mm x 380 mm Spindle taper: SK 40 Spindle speed: up to 6,000 rpm Drive power: 11 kW Tool changer capacity: 20 MACHINE DETAILS Ppedpfxoyf Ac Ds Afhol Dimensions & Weight Dimensions (L x W x H): 2,600 x 2,100 x 3,000 mm Machine weight: approx. 3,600 kg Note: The machine no longer starts. It is being sold for spare parts.

Condition: ready for operation (used), Year of construction: 2009, operating hours: 1,572 h, functionality: fully functional, travel distance X-axis: 3,230 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 750 mm, table width: 1,650 mm, table length: 3,000 mm, TECHNICAL DETAILS X-axis travel: 3,230 mm Y-axis travel: 2,100 mm Z-axis travel: 750 mm Table length: 3,000 mm Table width: 1,650 mm Max. spindle speed: 3,500 rpm Tool holder: ISO50 Tool magazine: 30 pcs Positioning accuracy: 0.005 mm Traverse speed: 250 mm/s MACHINE DETAILS Control: CNC Number of axes: 4 Power: 22 kW Main spindle power: 22 kW Tool magazine: 30 pcs Control operating hours: 5,269 h Podpjyd Acbofx Afhjpl Spindle hours: 1,572 h EQUIPMENT External cooling Tool magazine Touch probe Tool measuring system Spindle cooling Chip conveyor

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2012, operating hours: 18,000 h, machine/vehicle number: A0215A0232, laser power: 2,500 W, sheet thickness (max.): 15 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, positioning accuracy: 0.1 mm, overall weight: 8,900 kg, TECHNICAL DETAILS X-axis travel: 3,000 mm Y-axis travel: 1,500 mm Psdpfxoyb Rzyo Afhopl Laser power: 2,500 W Maximum sheet thickness (mild steel): 15 mm Maximum sheet thickness (stainless steel): 6 mm Maximum sheet thickness (aluminum): 5 mm Axis speed: max. 60 m/min Positioning accuracy: ±0.1 mm MACHINE DETAILS Dimensions & Weight Dimensions (L × W × H): approx. 7,400 × 3,300 × 2,300 mm Machine weight: 8,900 kg Mains connection: 400 V / 50 Hz Connected load: 65 kVA Control voltage: 24 V Required fuse protection: 3 × 100 A Compressed air connection: 7–14 bar Nitrogen connection (N₂): 29 bar Oxygen connection (O₂): 14 bar Operating hours: approx. 18,000 h EQUIPMENT Automatic pallet changer FocusLine laser technology NitroLine laser technology Maintenance-free AC servo drives

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 3,250 mm, travel distance Y-axis: 1,265 mm, travel distance Z-axis: 120 mm, saw blade diameter: 120 mm, Equipment: CE marking, Dismantling and loading can be handled by the seller! TECHNICAL DETAILS Working area X: 3,250 mm Working area Y: 1,265 mm Working area Z: 120 mm Tool holder: HSK-F63 Tool changer: 10 positions, mounted on the milling head Drilling and sawing units Vertical drilling spindles: 12 Horizontal drilling spindles X-axis: 4 Horizontal drilling spindles Y-axis: 2 Groove milling unit X-direction: 1 Saw blade diameter: 120 mm Table system Pod and rail table: available Consoles: 6 MACHINE DETAILS Drive data Main motor power: 9.2 kW Total connected load: 15 kW Vacuum pump capacity: 100 m³/h EQUIPMENT Positioning aid Safety mat Digital LED display on the consoles Auxiliary device for tool change Two rows of stops Workpiece supports Pjdpfx Afoyddqmehepl Handheld control device Pendulum processing CE marking

Condition: ready for operation (used), functionality: fully functional, cutting length (max.): 3,550 mm, cutting width (max.): 530 mm, overall weight: 9,000 kg, stroke length: 100 mm, TECHNICAL DETAILS Usable cutting length (as double guillotine): 3,200 mm Usable cutting length (as single plate shear): 3,550 mm Press stroke: 100 mm Press width: 550 mm Min. cutting width: 18 mm Max. cutting width: 530 mm Scrap setting range: 0/50 mm Operating pressure: 6/7 bar MACHINE DETAILS Installed total power: 13.9 kW Dimensions & Weight Dimensions (L x W x H): 5,200 x 1,700 x 1,800 mm Weight: 9,000 kg EQUIPMENT Robust steel construction Blade beam made of cast iron Self-lubricating prismatic guides Adjustable rear support Press for holding the veneer package during cutting Photoelectric cells Electronic programming device Perimeter safety guards Podpjyf Eucefx Afhopl

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 60 mm, workpiece length (max.): 3,000 mm, overall weight: 2,700 kg, TECHNICAL DETAILS Working area X-axis: 3,000 mm Working area Y-axis: 1,000 mm Working area Z-axis: 60 mm Maximum workpiece length: 3,000 mm Minimum workpiece length: 90 mm Maximum workpiece width: 1,000 mm Minimum workpiece width: 70 mm Maximum workpiece height: 60 mm Minimum workpiece height: 8 mm Vertical electrospindle power: 4.8 HP Circular saw unit diameter: 150 mm Circular saw unit power: 2.3 HP Vertical drilling spindles: 29 Horizontal drilling spindles (X-axis): 8 Horizontal drilling spindles (Y-axis): 2 MACHINE DETAILS Compressed air: 7/8 bar Total installed power: 20 kW Machine weight: 2,700 kg EQUIPMENT Numerical control with Biesseworks software Infeed table with motorized belts (left) 2 panel clamps Outfeed table with motorized belts (right) Protection for machining head with emergency stop front mats Ppodpjyf Elzefx Afhel Transfer system for panel loading and unloading with aluminium profiles Belt-driven table for panel transfer/lifting bar BiesseWorks machining programming system

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 3,085 mm, travel distance Y-axis: 1,385 mm, travel distance Z-axis: 180 mm, controller model: Xylog, milling spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS X-axis working area: 3,085 mm Y-axis working area: 1,385 mm Z-axis working area: 180 mm Programmable X-axis speed: 50 m/min Programmable Y-axis speed: 45 m/min Programmable Z-axis speed: 22.5 m/min Drilling unit Vertical spindles: 10 Horizontal spindles X-axis: 2 Horizontal spindles Y-axis: 2 Motor power: 2.2 kW Speed: 4,000 rpm Milling unit Electrospindle: 10 HP Speed: 18,000 rpm Engraving unit Motor power: 2.2 kW Speed: 6,000 rpm Worktable Number of worktables: 6 Vacuum suction cups: 18 Loading supports: 4 Vacuum pump Flow rate: 100 m³/h MACHINE DETAILS Pedpfx Afjyf Ekkehopl Control system: Xylog Installed power: 17/20 kW Compressed air: 6/7 bar Weight: 3,000 kg EQUIPMENT Automatic lubrication

Condition: ready for operation (used), functionality: fully functional, overall weight: 5,000 kg, working width: 1,300 mm, workpiece height (max.): 130 mm, TECHNICAL DETAILS Working width: 1,300 mm Maximum working thickness: 130 mm Minimum working thickness: 1 mm Conveyor belt feed speed: 5/25 m/min MACHINE DETAILS Installed power: 32 kW Compressed air: 7 atm Dimensions & Weight Dimensions (L x W x H): 4,400 x 2,500 x 1,600 mm Weight: 5,000 kg EQUIPMENT Cross belt - Motor: 15 Hp - Electronic speed controller with display Transversal belt - Motor: 15 Hp - Electronic speed controller with display Transversal sanding belt size: 1,350 x 150 mm Chevron belt size: 5,510 x 140 mm Belt blower Fixed table and moving head for inline processing Rotary blower for panel cleaning Vacuum table Belt cleaning brush Ppedpfjyf Eh Nex Afhsl Infeed roller conveyor Extraction ports: No. 2 diameter 200 mm – No. 2 diameter 150 mm – No. 2 diameter 100 mm

Condition: ready for operation (used), Year of construction: 1983, operating hours: 6,348 h, functionality: fully functional, drilling depth: 1,500 mm, travel distance X-axis: 1,250 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 900 mm, drill diameter: 50 mm, The machine was overhauled in 2009! TECHNICAL DETAILS Drilling depth: 1,500 mm Drill diameter: 5 - 50 mm Travel X-axis: 1,250 mm Travel Y-axis: 900 mm Travel Z-axis: 900 mm Table length: 1,000 mm Table width: 1,000 mm Max. table load: 3,000 kg Spindle speed: 100 - 6,000 rpm Spindle taper: SK 40 MACHINE DETAILS Control: Siemens 802 D Dimensions & Weight Dimensions (L x W x H): 5,000 x 2,600 x 2,000 mm Weight: 6,000 kg Operating hours: 6,348 h Psdjyfhciopfx Afhjpl

Condition: ready for operation (used), Year of construction: 2001, operating hours: 85,355 h, functionality: fully functional, machine/vehicle number: 71.405627, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain Millplus, table width: 630 mm, table length: 500 mm, TECHNICAL DETAILS Travel X-axis: 600 mm Travel Y-axis: 700 mm Travel Z-axis: 600 mm Number of pallets: 2 pcs Pallet clamping surface: 500 x 630 mm Max. load pallet changer (one-sided): 600 kg Max. load pallet changer (double-sided): 1,200 kg Pjdpoyfhahefx Afhopl Max. table plate rotation: 13.6 rpm Feed rate: max. 15,000 mm/min Rapid traverse speed: max. 40 m/min Set-up operation: 2,000 mm/min Magazine positions: 60 slots Max. tool weight: 10 kg Max. tool diameter: 100 mm Max. tool length: 350 mm Measuring System Resolution: 0.001 mm Input increment: 0.001 mm Positioning tolerance: 0.010 mm MACHINE DETAILS Control: Heidenhain Millplus Dimensions & Weight Machine without tool magazine: 8,400 kg Weight of tool magazine (60 tool positions): 600 kg Floor dimensions: 4.50 m × 2.72 m × 2.63 m Electrical Data Rated power: 44 kVA Current consumption, maximum: 64 A Current draw: 80 A Supply voltage: 400 V Frequency: 50 Hz Control voltage: 24 V Operating Hours Power-on hours: 96,878 h Spindle hours: 85,355 h

Condition: ready for operation (used), Year of construction: 2016, operating hours: 400 h, functionality: fully functional, travel distance X-axis: 1,050 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 500 mm, controller model: Siemens 828D, spindle speed (max.): 12,000 rpm, The machine spindle was replaced in 2022! TECHNICAL DETAILS Podpfx Aoyf E Szofhopl Travel X-axis: 1,050 mm Travel Y-axis: 550 mm Travel Z-axis: 500 mm Milling spindle (BT40): 12,000 rpm MACHINE DETAILS Control unit: Siemens 828D Operating hours: Power-on hours: 26,247 h Spindle hours: approx. 400 h (total 4,727 h) EQUIPMENT - Active electrical cabinet air/air cooler - Network connection - USB interface - Spindle chiller - Side windows left and right for large components - Safety cabin with armoured glass - Coolant pump at spindle - Pump for chip flush device - Air at the spindle via M-code function - Operating status light - Oil separator - Electronic handwheel - ICS system (internal coolant supply) - Pump for ICS - 24-position tool changer - Hinge-type chip conveyor, rear discharge - Glass scales including purge air by Siemens - Wireless workpiece measuring system Renishaw OMP60 - Tool measuring system Renishaw NC4 - Automatic machine door Note: The Halter automation system as well as vices including zero-point clamping system are not included in the scope of delivery.

Year of construction: 2004, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 9,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 630 mm, spindle speed (max.): 24,000 rpm, machine/vehicle number: 031809, TECHNICAL DETAILS Travel X-axis: 9,500 mm Travel Y-axis: 1,000 mm Travel Z-axis: 630 mm Feed rate X-axis: 70 m/min Feed rate Y-axis: 40 m/min Feed rate Z-axis: 40 m/min Swivel angle A-axis: ±110°, freely programmable in 0.1° increments Swivel angle C-axis: ±182°, freely programmable in 0.1° increments Spindle speed: max. 24,000 rpm Spindle power: 15 kW S1 Ppsdpfxeycul Se Afhol Milling cutter diameter: max. 100 mm Slitting cutter diameter: max. 100 mm Saw blade diameter: max. 400 mm Tool holder: HSK-63F MACHINE DETAILS Compressed air connection: 7 bar Electrical connection: 400 V, 3~, 50 Hz, 80 A Air consumption: approx. 200 l/min with spraying EQUIPMENT Machining operations: milling, drilling, tapping, thread milling, slotting, and sawing with stationary profile bar 6-sided machining: optional from the front, possible from below Profile bar protection: machining with stationary profile bar Robust and low-wear direct drives on all axes Axes: 5-axis control for spatial machining Display: 15-inch color screen Interfaces: USB ports, network connection 2-layer machining for pendulum operation Included tools (HSK holders) Two circular saws for aluminum

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, controller model: Ferrocontrol DARC, TECHNICAL DETAILS Upper drilling heads: 3 Psdsydn Ezopfx Afhepl Drill spindles per head: 36 Vertical pantographs: 2 Working dimensions: 2,500 x 800 mm MACHINE DETAILS Control: Ferrocontrol DARC EQUIPMENT Electronic drilling machine Automatic loading system with motorized roller conveyor Automatic hinge insertion system Unloading and transport roller conveyor with automatic stop

Year of construction: 2005, condition: ready for operation (used), functionality: fully functional, working width: 2,400 mm, working height: 32 mm, working length: 800 mm, TECHNICAL DETAILS Working width X-axis: 267 - 2,400 mm Psdsydn A Tepfx Afhopl Working length Y-axis: 120 - 800 mm Working height Z-axis: 16 - 32 mm 2 upper drilling heads + independent Y-axis grooving consisting of: Left head with 15 vertical spindles in X and Y-axis + one blade for grooving Right head with 15 vertical spindles in X and Y-axis + one automatic hinge installation unit 2 independent lower vertical drilling heads in Y-axis each with 5 + 5 independent spindles MACHINE DETAILS Control: Numerical control with WoodWop software EQUIPMENT Automatic loading system with motorized roller conveyor Tank with vibrator for hinge storage and automatic feeding Unloading system with automatic roller conveyor

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 0-250-12-2554, workpiece height (max.): 80 mm, workpiece length (max.): 1,000 mm, workpiece width (max.): 3,000 mm, controller model: PC 85, TECHNICAL DETAILS Workpiece width min.: 250 mm Workpiece width max.: 3,000 mm Workpiece length min.: 100 mm Workpiece length max.: 1,000 mm Workpiece height min.: 8 mm Workpiece height max.: 80 mm Upper vertical working unit ETP-6 vertical spindle power: 6 kW Grooving cutter diameter: 125 mm Vertical drilling spindles: 32 (power 2.7 kW) Horizontal drilling spindles: 10 (8 in X + 2 in Y) Ppodpfx Afjydnu Nohjl Lower vertical working unit ETP-6 vertical spindle power: 6 kW Grooving cutter diameter: 125 mm Vertical drilling spindles: 32 (power 2.7 kW) Horizontal drilling spindles: 10 (8 in X + 2 in Y) MACHINE DETAILS Control: PC 85 Software: woodWOP 6 EQUIPMENT Safety enclosure for tool set 2 clamping chucks for securing and moving the workpiece during machining Loading bench with air cushion table Powered roller conveyor for panel discharge Capability for simultaneous processing of two panels

Condition: ready for operation (used), functionality: fully functional, working height: 60 mm, working width: 850 mm, controller model: POWER PC 85 + WOODWOP 6.0, working length: 3,050 mm, TECHNICAL DETAILS Working dimensions: 3,050 x 850 mm Working height: 12 - 60 mm Ppedpfx Afoydmcrshol Drilling Head Vertical spindles X-axis: 8 Vertical spindles Y-axis: 5 Horizontal spindles X-axis: 4 Horizontal spindles Y-axis: 2 Milling Head Axes: 3 Tool change: Automatic Diameter of integrated saw unit: 100 mm MACHINE DETAILS Control: POWER PC 85 + WOODWOP 6.0 (updated in 2023) EQUIPMENT 4-position tool changer

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, travel distance X-axis: 3,680 mm, travel distance Y-axis: 1,380 mm, travel distance Z-axis: 250 mm, controller model: Xilog Maestro, spindle speed (max.): 24,000 rpm, TECHNICAL DETAILS Working Area X-Axis: 3,680 mm Working Area Y-Axis: 1,380 mm Working Area Z-Axis: 250 mm Spindle Speed: 24,000 rpm Number of Working Zones: 2 Number of Adjustable Bars: 6, 1,300 mm Number of Pneumatic Bakelite Bars: 4 Number of Adjustable Suction Cups: 3 Front Tool Changer System: 10 positions Rear Tool Changer System: 16 positions F 12L Vertical Drilling Head Spindles: 8 F 12L Horizontal Drilling Head Spindles X-Axis: 2 F 12L Horizontal Drilling Head Spindles Y-Axis: 2 MACHINE DETAILS Electrospindle: 12 kW, HSK 63F Vacuum Pump: 250 m³ Control System: Xilog Maestro EQUIPMENT Tecpad Mobile Console Bar Worktable Laser Line for Virtual Zero Positioning on Y-Axis Ppsdpfx Afoydmbnshol Prisma KS 5-Axis Vertical Electrospindle Tool Group Blades for Groove Cutting Pro-Speed Safety System Front Guard and Safety System Automatic Lubrication System

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 0-201-09-5124, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,650 mm, controller model: Homatic PC 85 Power Control, TECHNICAL DETAILS X-axis working range: 6,000 mm Y-axis working range: 1,650 mm – up to 1,750 mm for milling Max. travel height during edge banding: 60 mm Max. applicable edge height: 65 mm Minimum internal radius: 30 mm Automatic tool changer: 18 positions Drilling head: 27 spindles (4 kW) Max. unit saw blade diameter: 200 mm MACHINE DETAILS Ppedpfx Aoydl Nwsfhel Control system: Homatic PC 85 Power Control Software: WoodWop Electrospindle C Vector: 11 kW, HSK F63 Edge specification: Rolls, PVC / ABS 0.4 - 3 mm EQUIPMENT 10 adjustable support rails for vacuum cups Loading and unloading aid with 8 pneumatic rods Vacuum cup positioning with laser system Edge banding unit with 360° rotation, glue pot, and preheater for granular EVA glue Rubber-coated pressure roller + Rubber-coated pressure roller Preheating lamp Edge trimmer and edge scraper Edge holder magazine Front and side safety system with carpets Protective cage around access area Chip extraction with motorized conveyor belt Air conditioning for machine control cabinet Automatic lubrication system Vacuum pump

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: AL/008514, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, controller model: PC mit Xilog Plus Software, workpiece height (max.): 60 mm, overall weight: 2,800 kg, TECHNICAL DETAILS Ppjdpfx Afsydl Adshel Working area X-axis: 3,000 mm Working area Y-axis: 1,000 mm Workpiece thickness (processable): 60 mm Upper drilling and milling unit Electrospindles: 1 Vertical spindles: 24 Horizontal spindles X-axis: 2 Horizontal spindles Y-axis: 2 Grooving saw unit X-direction: 1 Grooving saw unit power: 2.2 kW Lower drilling and milling unit Electrospindles: 1 Vertical spindles: 24 Horizontal spindles X-axis: 2 Horizontal spindles Y-axis: 2 Grooving saw unit X-direction: 1 Grooving saw unit power: 2.2 kW MACHINE DETAILS Control: PC with Xilog Plus software Weight: 2,800 kg EQUIPMENT Panel clamps Manual workpiece loading on Flotex table Automatic workpiece unloading Automatic central lubrication

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, workpiece weight (max.): 50 kg, working height: 80 mm, working width: 1,300 mm, working length: 2,500 mm, TECHNICAL DETAILS Working length: 300 - 2,500 mm Working width: 60 - 1,300 mm Working height: 10 - 80 mm Maximum workpiece weight: 50 kg MACHINE DETAILS Working height: Up to 1,300 mm Dimensional tolerance readability: ±0.15 mm Tool change: NC-controlled Programming: PC - TPA Albatros software Operating system: Windows 7 Professional EQUIPMENT Machining on 6 sides of the panel Double-section chain – X axis patent Linear, circular, and spiral interpolation Double zero point reading Mirror program management Turret tool diameter optimizer Optimizer for independent spindle diameter DXF file conversion (geometric conversion) Import of work lists in ASCII format Additional key for programming from the office Gun-type barcode reader 17-inch LCD monitor Panel loading and handling via motorized vertical comb feed with rollers Height reading system with independent axis Thickness measuring system with mechanical probe Brushless motors with programmable speed control via NC Ppjdpfx Ajydlk Iefhel Drilling unit with independent vertical and horizontal spindles Upper turret milling unit with 10 positions Automatic lubrication 180° panel transfer and rotation system Discharge system with motorized belt

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, Production line consisting of the following components: Ppsdpfx Ajydlapofhel Motorized comb with multiple positions Vertical machining center Bremen Vektor Motorized panel handling system Vertical machining center Bremen Vektor Motorized transfer unit Motorized return conveyor TECHNICAL DETAILS Motorized comb length: 2,000 mm Vertical machining center Bremen Vektor Drilling head: 1 with 7 horizontal spindles in X, 16 vertical spindles in Y Pantograph: With turret tool changer for 8 positions Horizontal drilling unit: 1 for stop drilling Motorized panel handling Return: With 180° rotation and THK guide rails Length: 2,500 mm Vertical machining center Bremen Vektor Automatic infeed: By motorized chain and vertical pressure rollers Working height adjustment: Automatic via CNC Storage containers: 5 for hinges/buffers/tie rods Motorized transfer unit Output: From vertical to horizontal towards operator Length: 2,000 mm Motorized conveyor Return: To operator EQUIPMENT Computer, keyboard and mouse 15" monitor CD-ROM Automatic infeed by motorized chain and vertical pressure rollers Automatic working height adjustment via CNC

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 55595, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 60 mm, overall weight: 3,000 kg, controller model: Xp 600, TECHNICAL DETAILS Working Area X-axis: 3,000 mm Working Area Y-axis: 1,000 mm Working Area Z-axis: 60 mm MACHINE DETAILS Control: Xp 600 with Biesse Works Software Weight: 3,000 kg EQUIPMENT Automatic loading system with motorized belt conveyor 2 clamps for securing and transporting the panel 1+1 vertical electrospindle (lower + upper) with 3 axes Ppedpjydk Rmofx Afhsl 1+1 independent saw (lower + upper) 29 + 29 independent spindles for vertical drilling in X and Y direction (upper + lower) 10 + 10 independent spindles for horizontal drilling in X and Y direction (upper + lower) Automatic unloading system with motorized belt conveyor

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 1000012445, travel distance X-axis: 3,600 mm, travel distance Y-axis: 1,800 mm, overall weight: 4,000 kg, TECHNICAL DETAILS Working area X-axis: 3,600 mm Working area Y-axis: 1,800 mm Number of working zones: 2 Ppedpeydk Aijfx Afhsl Tool change positions on the rear: 16 Tool change positions on the machine: 8 Vacuum pump: 250 m³/h Drilling head BH 10 configuration: 15 vertical spindles on the X-axis 17 vertical spindles on the Y-axis MACHINE DETAILS Electrospindle power: 13.2 kW Electrospindle type: ISO 30 Control: CNC with B-Solid software Weight: 4,000 kg EQUIPMENT Nesting work table Automatic loading system with side lift table Label printing system with automatic application on the loading table Panel separation system with suction cups Automatic unloading system with motorized conveyor belt Worktable cleaning system Protection and safety system with perimeter fencing Safety system with bumper Automatic lubrication system Air-conditioning system for cooling and cleaning the machine control unit

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 94464, travel distance X-axis: 3,400 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 155 mm, controller model: XNC Numerical Control, TECHNICAL DETAILS Working Area X-Axis: 3,400 mm Working Area Y-Axis: 1,300 mm Working Area Z-Axis: 155 mm Number of Work Fields: 2 Tool Changer Positions (lateral): 3 Tool Changer Positions (chain): 20 Drilling Head Configuration: 10 vertical drills X-axis 12 vertical drills Y-axis 6 horizontal drills X-axis 2 horizontal drills Y-axis MACHINE DETAILS Control System: XNC Numerical Control Ppedpfx Aoydkkgjfhel Vertical Spindle Type: C-axis Vector, ISO 30 cone type EQUIPMENT Extraction pump 8 manually adjustable beams for suction cup support with display 8 pneumatic bakelite rails for panel lifting 3 manually adjustable suction cups per beam Front safety and protection system with mats Comprehensive safety fencing Motorized mat for chip removal

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 57269, travel distance X-axis: 4,300 mm, travel distance Y-axis: 2,205 mm, controller model: NC 1000, TECHNICAL DETAILS X-axis working range: 4,300 mm Y-axis working range: 2,205 mm Vertical spindle: 1 unit, HSK F63 Tool changer system: 8 positions (head) Tool changer system: 21 positions (rear, chain) Drilling head: BH 20 Vertical spindles on X-axis: 8 units Vertical spindles on Y-axis: 8 units Horizontal spindles on X-axis: 4 units Horizontal spindles on Y-axis: 4 units Saw unit on X-axis: diameter 120 mm Saw unit on Y-axis: diameter 120 mm MACHINE DETAILS Control: NC 1000 Ppjdpfx Ajydkdgefhsl Software: Biesse Works Weight: 400 kg EQUIPMENT FT nesting table with full surface Automatic loading system with side lift table Automatic labelling machine for barcode printing Automatic printing and dispensing system for adhesive labels Automatic unloading system with motorized conveyor belt Front safety and protection system with mats and fences Automatic lubrication system Air conditioning for control cabinet Vacuum pump
