Used Holzma for sale (54)

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 0-341-07-8150, cutting length (max.): 4,300 mm, saw blade diameter: 380 mm, cutting width (max.): 3,800 mm, throat depth: 75 mm, Equipment: scorer, TECHNICAL DETAILS Blade extension: 75 mm Cutting length: 4,300 mm Dodpfjxx Svrjx Addscr Cutting width: 3,800 mm Main saw blade, max. diameter: 380 mm Main saw blade, power: 9.2 kW Scoring saw blade, max. diameter: 180 mm Scoring saw blade, power: 2.2 kW Pusher carriage speed: up to 80 m/min Saw carriage speed: 1–120 m/min MACHINE DETAILS Numerical control: POWER CONTROL Software: Cad Matic 4.0 Electrical Data Voltage: 400 V Current: 31 A Frequency: 50 Hz Secondary current: 40 A Control voltage: 24 V DC EQUIPMENT Front panel loading Front-side unloading Automatic side aligner Fixed front table made of Bakelite with air cushion system 3 mobile front tables made of Bakelite with air cushion system Pusher carriage with 6 clamps

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, cutting length (max.): 4,300 mm, workpiece length (max.): 4,300 mm, workpiece width (max.): 2,200 mm, plate height: 60 mm, Placing a bid obligates the buyer to collect the equipment by calendar week 02 in 2026. Forklifts and transport aids can be provided by the seller. Up for auction is a combination consisting of two Holzma saws, connected to a Bargstedt storage system. TECHNICAL DETAILS HOLZMA PROFILINE HPL 380 Cutting and Lift Table Data Cutting length: 4,300 mm Lift table cutting size: 4,300 mm x 2,200 mm Maximum panel size for lift table loading: 4,300 mm x 2,200 mm Minimum panel size for lift table loading: 1,200 mm x 400 mm Stack Heights Stack height for lift table, floor installation max.: 560 mm Stack height for lift table, pit installation max.: 780 mm Lift table maximum load capacity: 4 t Roller Rails Roller rail element, 10 tracks: 1 piece Roller rail element, 2 tracks: 6 pieces Clamping Jaws Pitch: 75/275/475/1,075/1,825/2,625/3,425 mm Extraction and Air Cushion Tables Push-off device position: 2,375 mm Air cushion table with rollers 2,160 x 800 mm: 1 piece Air cushion table with rollers 2,160 x 650 mm: 3 pieces Central blower: 1 piece Nozzle duct for air cushion tables: 70 x 70 mm HOLZMA PROFILINE HPP 380 Cutting Data Cutting length: 4,300 mm Cutting width (programmable pusher travel): 4,250 mm Saw blade projection: 95 mm Combi and Clamping System Combi profile rail element, 2 tracks: 9 pieces Clamping jaws: 7 pieces Pitch: 75/275/475/1,050/1,850/2,650/3,450 mm Manual trimming stops on clamping jaws: 4 pieces (positions 75/475/1,050/2,650 mm) Air Cushion Tables and Extraction Air cushion table with roller element 2,160 x 650 mm: 4 pieces Central blower: 1 piece Nozzle duct for air cushion tables: 70 x 70 mm Feed and Programmable Pusher Saw carriage feed forward: 1–130 m/min Saw carriage feed reverse: constant 130 m/min Programmable pusher speed forward: 80 m/min Programmable pusher speed reverse: 80 m/min BARGSTEDT PROFILINE TLF 420 Djdpfsxy Ng Rsx Addecr Panel thickness: 3–60 mm Maximum panel size: 4,300 mm x 2,200 mm Maximum traverse length: 5,200 mm Measuring and Correction System Length measurement: integrated Width measurement: integrated Automatic rotation correction: available Note: Further technical details can be found in the attached order confirmations.

Year of construction: 2001, operating hours: 22,539 h, condition: ready for operation (used), This HOLZMA HCL 11/56/22 was manufactured in 2001. It features a maximum panel size of 5600 × 2200 mm and a cutting length of 5600 mm for longitudinal sawing. The saw blade projects up to 125 mm, and it includes a turning station sized 1250 × 1250 mm. With a lifting capacity of 10 tons and a maximum lifting height of 1430 mm, consider the opportunity to buy this HOLZMA HCL 11/56/22 panel saw. Contact us for more information. Application Types Dcodpfsx D Exdjx Addjr Sawing (Wood)

Condition: used, machine/vehicle number: 008131, Max. panel width: 4300 mm Dcedpfxow Idh Hj Addjr Max. panel length: 4300 mm Main saw blade projection: 80 mm No of Grippers: 7

Condition: excellent (used), Year of construction: 2021, Angular sawing plant Numerical Control PowerControl V2.1 - CADmatic 5 (Tapio ready) No. 1 Rollers table for pre-loading (useful mm 2200 x 4500 approx) Lifting table (mm) 4300 x 2200 1st Rear-pusher, with No. 4 clamps/grippers 1st Panel Saw - Max cutting width mm 4300 Max blade projection (mm) 125 Scoring Unit (max. diameter saw / power) mm 180 (Kw 2,2) Dcjdex Aqdcopfx Addor Main Sawing Unit (max. diameter saw / power) mm 450 (Kw 28) Adjustable speed of the saw carriage (m/min) 1 - 150 m/min 2nd Rear-pusher, with No. 8 clamps/grippers 2nd Panel Saw - Max cutting width mm 2200 Max blade projection (mm) 125 Scoring Unit (max. diameter saw / power) mm 180 (Kw 2,2) Main Sawing Unit (max. diameter saw / power) mm 450 (Kw 28) Adjustable speed of the saw carriage (m/min) 1 - 150 m/min No. 2 Front supporting tables with Air blowing system (2 x mm 800 x 2810) Total installed power A 102 OPTION: No. 1 Waste grinder

Condition: used, Empty weight: 2.000 kg Dimensions (LxBxH): 605 x 235 x 124 cm Dcedpfx Aoxx Tlzsddjr - Documentation available: No - CE certificate present: No - Transport dimensions: 6050mm x 2350mm x 1240mm (l x w x h) - Transport weight [kg]: 2000kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: excellent (used), Holzma B14/4 drilling machine in excellent condition. Ready for operation. Video of the machine in operation available. Dcjdexyxgtopfx Addor

Condition: used, Year of construction: 2005, functionality: fully functional, Manufacturer: HOLZMA Model: OPT HPP 350/43/43/X Machine type: Beamsaw Year of manufacture: 2008 Operating status: still connected Cutting length 4.300 mm Width of lifting table 2.200 mm Number of grippers 8 Feedrate max 150 m/min Saw blade projection 80 mm Saw blade diameter max 350 mm Scoring saw Yes Labelling manually Lift table loading from behind Stop side Right side HOLZMA | HOMAG Machine table with air nozzles throughout Control HOLZMA CADMATIC 4.1 Declaration of CE-conformity Conformity marking CE mark Space requirement Length 8,2 m Dcedpfx Ajxwwfvodder Space requirement Width 6,5 m

Year of construction: 2000, condition: ready for operation (used), Technical Specification Max. Cutting Length 3300 mm Dcodpfxox D Hlfe Adder This HOLZMA HPL 23/X/33/22/30/L was manufactured in 2000. A robust used panel saw featuring a cutting length of 3300 mm, 3 air cushion tables, and a lifting table measuring 3300 x 2200 mm. It includes a main saw with 18 kW power and a scoring saw of 2.2 kW, controlled by a CADMATIC system. Contact us for more information about this machine. Application Types Sawing (Wood)

Condition: used, machine/vehicle number: 008021, Max. panel width: 4300 mm Max. panel length: 2200 mm Main saw blade projection: 125 mm Dcjdpfx Aow Uz Spoddor No of Grippers: 11 Panel Rotation Station: yes Thin sheet loading: yes Vacuum sheet loading: yes

Condition: used, No. 3248 Horizontal panel saw HOLZMA Optimat HPP 380/38/38 Used, year of construction 2003 Machine still in operation, expected to be available from 19.01.2026 Cutting length 3800 mm Cutting width 3700 mm Saw blade projection 95 mm Main saw motor 13.5 kW Scoring saw motor 2.2 kW Main saw blade 380 x 4.8 x 60 mm Scoring saw blade 180 x 4.8 - 5.8 x 45 mm 7 clamps 3 air cushion tables, of which 1 with angle stop 3 roller elements on front side LKT Operating software Schnitt Profi(t) 9.0 / CADmatic V3.0 15" monitor (replaced in January 2025) V program pusher up to 80 m/min V saw carriage up to 130 m/min Machine dimensions 7205 x 6100 mm LW Sale on behalf of customer, ex location near 90471 Nuremberg, without dismantling, without transport and assembly Dismantling, loading and transport by us optionally possible Subject to errors in the description and price To avoid possible misunderstandings, an on-site inspection is possible and recommended by appointment Sold as is Technical specifications, condition description, year of manufacture and scope of delivery according to manufacturer's brochure or previous owner, without guarantee Subject to prior sale Dcsdpfx Adexrglnjdor For used machines, any warranty is excluded, the following applies: “sold as seen” Images and videos serve as examples and do not represent the actual scope of delivery Terms of payment: Prices excl. VAT, payment before collection or shipping Terms of delivery: ex location

Condition: excellent (used), operating hours: 565 h, functionality: fully functional, machine/vehicle number: 0-240-10-3388, incl. panel storage and loading system, Bargstedt, Type: OPTIMAT TLF210 /12 /12 Recorded operating hours: 565h Cutting length: 4300 mm Cutting width: 4250 mm (program pusher travel) Saw blade projection: 95 mm Main saw motor: 13.5 kW Scoring saw motor: 2.2 kW POWER CONCEPT ANGLE CUTTING PACKAGE GROOVE CUTTING PACKAGE Dsdpfxsw R Ur Uj Addocr AUTOMATIC EJECTION FENCE (pushes panel remnants from the rear machine table to the front over the cutting line) LABELING PACKAGE CONTROL: POWER CONTROL: CADmatic 4-Professional DATA CONNECTION TO STORAGE SYSTEMS

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, COMPLETE FACTORY FOR MOBILE PRODUCTION FOR SALE 1 pc AUTOMATIC ANGULAR PANEL SAW Manufacturer: HOLZMA – Germany Model: HCL 11/56/22 Serial No.: 0-241-17-0009 Year: 2001 1 pc AUTOMATIC SIZING, EDGEBANDING, AND BORING LINE INCLUDES: - BRIDGE VACUUM LOADER - AUTOMATIC SIZING AND EDGEBANDING MACHINE Manufacturer: HOMAG – Germany Model: OPTIMAT KFL 525/6/A3/15 Serial No.: 0-202-10-1687 Year: 2007 - 90-DEGREE ROLLER CONVEYOR Manufacturer: HOMAG – Germany Model: PROFI TB 10/25/12 Serial No.: 0-205-10-5100 Year: 2007 - AUTOMATIC SIZING AND EDGEBANDING MACHINE Manufacturer: HOMAG – Germany Model: OPTIMAT KFL 526/8/A3/15 Serial No.: 0-202-10-1689 Year: 2007 - ROLLER CONVEYOR Manufacturer: HOMAG – Germany Model: OPTIMAT TDL 310/25/12 Serial No.: 0-205-10-1688 Dcjdpfx Aoxwt Igjddsr Year: 2007 - BORING MACHINE Manufacturer: WEEKE – Germany Model: OPTIMAT BST 500 D Serial No.: 0-251-04-2754 Year: 2007 - BORING MACHINE Manufacturer: WEEKE – Germany Model: OPTIMAT BST 500 D Serial No.: 0-251-04-2755 Year: 2007 - BRIDGE VACUUM UNLOADER

Condition: used, machine/vehicle number: 008001, Max. panel width: 4300 mm Max. panel length: 4300 mm Dcsdpfewuz Tbsx Addjr Main saw blade projection: 125 mm No of Grippers: 8

Condition: used, machine/vehicle number: 005108, Position 1: Front-Loading Panel Saws HOLZMA-HPP 380/43/43 + TLF Position 2: Horizontal Storage Systems HOLZMA-HPP 380/43/43 + TLF Dodjwuck Iopfx Addocr

Condition: used, machine/vehicle number: 007875, Max. panel width: 3800 mm Dsdpfewkf Axox Addscr Max. panel length: 2200 mm Main saw blade projection: 130 mm No of Grippers: 7

Condition: used, machine/vehicle number: 007596, Max. panel width: 3800 mm Max. panel length: 3800 mm Main saw blade projection: 55 mm Djdpfxjuxg Ttj Addjcr No of Grippers: 4

Condition: used, machine/vehicle number: 008206, Max. panel width: 4300 mm Max. panel length: 4300 mm Dedpfxox A Tizo Addocr Main saw blade projection: 125 mm No of Grippers: 9

Condition: used, machine/vehicle number: 008207, Max. panel width: 2200 mm Max. panel length: 3300 mm Dedpfx Adex A Tiujdocr

Condition: used, machine/vehicle number: 008208, Position 1: Front-Loading Panel Saws HOLZMA-HPP 510/43/43 + HEE 33/22 Dcjdjx A Thkepfx Addsr Position 2: Lift Table HOLZMA-HPP 510/43/43 + HEE 33/22

Condition: used, machine/vehicle number: 008177, Max. panel width: 4300 mm Max. panel length: 4300 mm Main saw blade projection: 125 mm No of Grippers: 7 Dsdsx A Tamjpfx Addjcr

Condition: used, machine/vehicle number: 007277, Max. panel width: 800 mm Dcodjt H Tynopfx Adder Max. panel length: 2500 mm Max. panel stack height from the ground: 1650 mm Lifting capacity: 4500 Kg

Condition: used, machine/vehicle number: 007276, Max. panel width: 800 mm Max. panel length: 2500 mm Max. panel stack height from the ground: 1650 mm Lifting capacity: 4500 Kg Dsdpfst H Tx Djx Addscr

Condition: used, machine/vehicle number: 007278, Max. panel width: 800 mm Max. panel length: 2500 mm Dcedpfjt H Txqsx Addjr Max. panel stack height from the ground: 1650 mm Lifting capacity: 4500 Kg

Condition: used, machine/vehicle number: 005255, Max. panel width: 4300 mm Max. panel length: 2200 mm Main saw blade projection: 110 mm Dcjdsg E Tcxepfx Adder No of Grippers: 7
