Used panel saws with a cutting length from 3000 to 3999mm for sale (39)

Condition: used, Year of construction: 1998, total length: 5,500 mm, total height: 1,800 mm, total width: 2,400 mm, Weight: 2.500 kg Price: On request Iodpfx Abew Dthvo Isa - Year: 1998 - Documentation available: Yes - └ Type Documentation: Electrical diagrams - CE marking present: Yes - CE certificate present: No - Serial number: 3129 - Max. cutting length [mm]: 3200 - Max. cutting width [mm]: 3200 - Transport dimensions: 5500mm x 2400mm x 1800mm (l x w x h) - Transport weight [kg]: 2500kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: good (used), Code: 0244 Brand: SCM Model: TECNOMAX FORMULA S 40 - CE Standard Panel saw with tilting blade and scoring unit for carpentry workshops, custom-made furniture, furniture, panels, doors, wooden window frames, plastics, composite materials, aluminium and various other materials - CE Standard Aluminium carriage length 3800 mm Cutting width with parallel guide 1500 mm Blade diameter 400 mm F30 Scoring blade diameter 120 mm F20 Iodsxzdt Uopfx Ab Iea Cutting height at 90° 130 mm Cutting height at 45° 92 mm Blade inclination 0-45 degrees Manual lifting and tilting by means of front handwheels Parallelogram blade guard Base suction port diameter 120 mm Blade guard suction port diameter 80 mm Motor power 7 Kw Outfeed table extension Overall dimensions of assembled machine mm 4000 x 4300 x 1500 h Overall dimensions of disassembled machine for transport mm 4000 x 1200 x 1500 h Weight kg 829

Condition: used, Year of construction: 2007, Cutting area: 3900 x 3100 mm Motor power: 11 kW Saw blade diameter: 350 mm Speed: 4070 rpm Feed speed: 0-70 m/min Maximum clamping jaw opening: 72 mm Maximum saw blade protrusion: 77 mm with scorer Storage location: Supplier Ijdsxfbwrepfx Ab Iea

Condition: ready for operation (used), cutting length 3000 mm cutting width 3000 mm side pressure device air tables SELCO OSI control main motor power 11 kW operating pressure 7 bar saw blade diameter 320 mm scoring saw diameter 20/30 mm optimization five panel clamps year of manufacture 2007 weight 3550 kg Ijdpfexz Dlwjx Ab Isa CE marking

Condition: reconditioned (used), Year of construction: 2018, functionality: fully functional, Built-in features: * Saw blade projection 80 mm * Cutting length 3200 mm * Right-hand machine * Machine table in the cutting line with air cushion * Stepless pressure beam control * 6 clamps * Main saw motor power: 11 kW * Scoring saw motor power: 2.2 kW * Labelling package * Postforming * Saw carriage speed: 130 m/min Machine operation * Operating panel * CADMATIC 5 * Additional information * CAD link conversion program * Data transfer online + USB Documentation: * Selected languages: English, German, Croatian * Documentation on data carrier, printed documentation General information: * Machine length 3200 mm Ijdpfjxv Sruex Ab Iea * Control: POWERCONTROL with POWERTOUCH system * CE mark * Commissioning date: November / December 2025

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Panel saw Homag HPL 300 Year of production: 2016 Technical data: * Cutting width: 3800 mm * Rear loading with rotation group and side loading * Labelling unit * Touchscreen * 3 front tables 600 × 2000 mm with air cushion Iedpfexzu E Iox Ab Isa * 8 grippers

Condition: used, No. 3248 Horizontal panel saw HOLZMA Optimat HPP 380/38/38 Used, year of construction 2003 Machine still in operation, expected to be available from 19.01.2026 Cutting length 3800 mm Cutting width 3700 mm Saw blade projection 95 mm Main saw motor 13.5 kW Scoring saw motor 2.2 kW Main saw blade 380 x 4.8 x 60 mm Scoring saw blade 180 x 4.8 - 5.8 x 45 mm 7 clamps 3 air cushion tables, of which 1 with angle stop 3 roller elements on front side LKT Operating software Schnitt Profi(t) 9.0 / CADmatic V3.0 15" monitor (replaced in January 2025) V program pusher up to 80 m/min V saw carriage up to 130 m/min Machine dimensions 7205 x 6100 mm LW Sale on behalf of customer, ex location near 90471 Nuremberg, without dismantling, without transport and assembly Dismantling, loading and transport by us optionally possible Subject to errors in the description and price Ijdpfxexrglne Ab Iea To avoid possible misunderstandings, an on-site inspection is possible and recommended by appointment Sold as is Technical specifications, condition description, year of manufacture and scope of delivery according to manufacturer's brochure or previous owner, without guarantee Subject to prior sale For used machines, any warranty is excluded, the following applies: “sold as seen” Images and videos serve as examples and do not represent the actual scope of delivery Terms of payment: Prices excl. VAT, payment before collection or shipping Terms of delivery: ex location

Condition: excellent (used), Pressure beam panel saw FIMAL CONCEPT 350 - used - Tiltable up to 46°, extendable angle stop up to 2,500 mm, digital display on the angle stop, mitre stop +/- 50°, automatic cutting length detection, stepless feed of the saw carriage, touchscreen, cutting line laser ----- Technical Data ----- Cutting length: 3,200 mm, Cutting width: 1,300 mm, Max. cutting height: 100 mm, Saw unit feed rate max.: 0 - 40 m/min., Main saw motor output: 5 kW, Main saw blade Ø: 350 mm, Dust extraction port (bottom) Ø: 120 mm, Dust extraction port (pressure beam) Ø: 100 mm, Compressed air connection: 7 bar Quality Info: - complete basic inspection - complete basic cleaning - electrics checked Iodpfx Ajxdl N Ajb Iea - immediately operational

Condition: used, Year of construction: 2023, Exhibition machine Garbsen HORIZONTAL PANEL SAW GABBIANI P Manufacturer: SCM Type: GABBIANI P80 Year of manufacture: 2023 1 unit MAIN FEATURES INDIVIDUALLY SELECTABLE AIR CUSHION TABLES: AN INDISPENSABLE TOOL SIDE SAFETY DEVICES: MORE SPACE FOR WORKING FLOATING GRIPPERS: GUARANTEED PERFECT CUT TECHNICAL DATA GENERAL INFORMATION gabbiani p80 Saw blade projection mm 80 Working table height mm 950 Standard number of grippers 5 Number of grippers for versions 33/38/43 9 / 10 / 10 Number of grippers for versions 33/38/43 with FlexCut 1 unit (single gripper with double fingers included) 10 / 11 / 11 CUTTING DIMENSIONS Version 33 mm 3300x2100 Version 33 (Opt.) mm 3300x3200 Version 38 mm 3800x3200 Version 38 (Opt.) mm 3800x3800 Version 43 mm 4300x3200 Version 43 (Opt.) mm 4300x4300 AXIS SPEED Variable saw carriage speed m/min 6 – 60 Variable pusher speed () m/min 60 MAIN SAW BLADE Motor power (S6 -40%) - 50hz (star-delta start) kW (HP) 7 (9) (11) Speed – 50 hz rpm 4650 Saw blade diameter mm 340 Shaft diameter main saw blade mm 80 SCORING BLADE Motor power (S6 -40%) - 50hz kW (HP) 1.5 (2) Speed – 50 hz rpm 5850 Scoring blade diameter mm 200 Shaft diameter scoring blade mm 80 INSTALLATION Installed power kW 12÷15 Base machine voltage Euro voltage (400 V / 50 hz) Compressed air demand NL/min 300 Required compressed air pressure bar 7 Extraction air requirement m3/h 2440 Extraction air speed m/sec 20 Extraction port diameter mm 4x120 () Note: in countries where EU standards apply, the forward pusher feed speed is limited to 25 m/min. GENERAL CHARACTERISTICS Fully automatic, PC/PLC-controlled horizontal panel saw suitable for cutting solid wood, MDF, chipboard, plywood, and similar materials. Frame and working table – Machine frame is a steel tube construction – Working table of rib-reinforced steel with Bakelite coating – Longitudinal fence on the left side Saw carriage made of steel, consisting of: – a motor for the main saw blade and a motor for the scoring blade – vertical lifting of the saw blade on linear ball bearing guides and shoes – running rollers of hardened and ground steel – balanced mass distribution for optimal cut quality – running direction towards the longitudinal fence – saw carriage drive via rack and pinion – carriage travel on cylinder guides – cylinder guides of hardened and ground steel (5-year warranty), protected by special dust wipers – pneumatic switch for fast and safe main and scoring blade change Pressure beam – pressure beam with uniform pressure across the entire cut length, recesses to prevent collision with grippers; pneumatic height adjustment via high-precision rack and pinion, pressure adjustable from 1.5 to 6 bar – dual extraction system with one unit above the pressure beam for cleaning the work table and one unit below on the saw carriage – side automatic aligner with pneumatic cylinder over the entire length. Sliding on linear ball bearing guides and shoes. * Travel distance: 1200 mm * minimum working width: 60 mm * maximum working width: 1200 mm Positioning pusher and rear part of the machine – Positioning pusher full length, powered by a robust drive shaft. Positioning pusher control... Iodpfxexyl U Re Ab Ija

Condition: excellent (used), Year of construction: 2007, Available soon. Iedpfx Aboxugdvo Iea Sample photo.

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, Mayer Format 4 Panel Saw Kappa 80 Automatic Year of manufacture: 11/2017 Operating hours: 425 Iedpfsw Niu Uox Ab Ioa Motor: 9 kW Pneumatic height adjustment of the pressure beam Stepless speed control of the motor Scoring unit with pneumatic lowering Angle table left 2300 x 600 mm with air cushion 2pcs extension tables 2300 mm with air cushion Lateral pressure device Material pusher, cutting length 3200 mm Package clamp, 6 pcs single-finger design Automatic trimming unit HW panel saw blade D 320 mm Tapered HW scoring saw blade D 150 mm Approx. dimensions 5.5 x 6 m Weight: 4200 kg

Condition: used, Year of construction: 2009, functionality: fully functional, machine/vehicle number: 731, feed length X-axis: 3,800 mm, cutting length (max.): 3,800 mm, cutting height with scoring (max.): 100 mm, saw blade diameter: 380 mm, cutting height (max.): 100 mm, cutting width (max.): 3,800 mm, feed rate X-axis: 70 m/min, main saw diameter: 380 mm, total height: 1,650 mm, overall weight: 4,500 kg, travel distance X-axis: 3,800 mm, workpiece weight (max.): 80 kg, extraction nozzle diameter: 120 mm, input frequency: 50 Hz, input current: 35 A, input voltage: 400 V, compressed air connection: 6 bar, rotational speed (max.): 4,800 rpm, rotational speed (min.): 2,800 rpm, air pressure: 6 bar, saw blade bore: 80 mm, Equipment: scorer, The saw is regularly serviced and in perfect working order. It is in daily operation on a single shift. Sale due to transition to a newer production system. Still functional, it can be seen in operation until October 10, 2025. Also supplied with a set of saw blades and a pre-cutter. Option to purchase a vacuum board lifter, which can be seen in the video. Iodpfx Abjxf Im Tj Iea

Condition: new, functionality: fully functional, power: 18.02 kW (24.50 HP), Maximum precision and high cutting heights with rapid feed rates – this is only possible with an uncompromisingly stable gantry construction. This level of uncompromising stability is achieved by using a proven tubular steel framework. The thick-walled steel tubes are meticulously welded into a complex support frame by our experienced staff, requiring many hours of dedicated craftsmanship. This creates the solid foundation for the high-precision guide rails, along which the saw carriage, weighing several hundred kilograms, will later move. Iedpfx Abswfdiyo Ija Perfect machine size for your workshop: 3200 x 3200 mm The machine allows the processing of workpieces up to 3200 mm in length and width. This means the saw carriage can execute cuts up to 3200 mm long. The material pusher can also be adjusted up to 3200 mm to the cutting line. Automatic cutting height adjustment up to 118 mm The powerful motor drives the saw blade through material at cutting heights up to 118 mm. For optimal cutting geometry, the blade should project about 10 mm above the workpiece. This optimizes energy consumption, noise emissions, and blade service life—a significant advantage for users. Every machine is therefore equipped as standard with automatic cutting height adjustment. The machine scans the height of the material and automatically sets the saw blade to the correct cutting height. Even when cutting multiple sheets in a stack, the saw blade drive must remain powerful. That’s why we equip our saw with a robust 18 kW (24.5 HP) main saw motor. Motorized, stepless cutting height control including grooving function A positioning drive allows the entire saw unit to be automatically raised or lowered to a set height, expanding production possibilities and ensuring precise grooves. Adjustment is made directly via the operator terminal. Motor: 18.0 kW (24.5 HP), 3x400 V / 50 Hz Optional equipment: - 14: Infinitely variable speed control, 2000–5000 rpm - 95: Pneumatic pressure device, 50–2100 mm - 24: Dust extraction pack on saw carriage for processing gypsum- and cement-bonded materials - 30: Air-cushion table, 2300 x 600 mm (2 units) - 28: Movable machine tables on linear guides and rollers - 40: Number of double-finger pack clamps, opening height 105 mm - 41: Additional double-finger pack clamp, opening height 105 mm - 38: Automatic trimming via laser measurement - 45: Additional double roller conveyor for sagging workpieces - 44: 24" touchscreen control unit - 90: Network connection preparation - 86: Control cabinet in special position - 700: Ardis module 1 - 710: Ardis module 2 - 714: Post-processor - 720: Ardis module 3 - 400: Helical rack for smoother operation - 401A: Saw carriage feed 0.2 m/min–60 m/min, return 80 m/min - 403: Cut length selection via switch - 404: Double pressure beam SL 3200 - 437: Technology database including controlled pressure regulation for pressure beam and pack clamps - 92: Transport preparation for crane unloading Including delivery and installation in postal code areas 71, 72, 73, 77, 78, 79, 86, 87, 88, 89.

Condition: used, Year of construction: 2023, machine/vehicle number: AEX0003705, Schnittbereich: 5600x5600 mm 1x Gabbiani G 3 130 (56) - Hochleistungs-Plattenaufteilsäge 1x kompakter Etikettendrucker 1x Bedienkonsole eye-M EVO Iodpfx Aboxlvkto Isa 1x Mensch-Maschine Oberfläche Software (HMI) MAESTRO ACTIVE 1x Maestro pattern 1x Hochleistung fester Luftkissentisch mit Führung, 2500x600 mm, mit Einlaufrollen 3x Hochleistung beweglicher Luftkissentisch - 2500x600 mm, mit Einlaufrollen 1x Doppelter seitlicher automatischer Ausrichter mit Motorantrieb 1x Fußschalter für START/STOP des Arbeitszyklus 1x Einrichtung für Nuten mit Höhenverstellung des Sägeblatts über die Steuerung 1x Autosetting Vorrichtung auf dem Sägewagen für die Schnittlänge/Breite 1x Hauptsägeblattmotor 25PS (18kW) 50 Hz mit Sterndreieckanlauf 1x Schnellspannung der Sägeblätter mit mechanischen Flanschen AKE 1x Selektiver Spannzangenverschluß (Fläche 0 - 1600 mm) 3x Zusätzliche doppelte Spannzange 4x Zusätzliche Spannzange mit einzelnem Finger 1x Kompakter Etikettendrucker Office 1x Cut editor 1x Maestro optiwise - Advanced - N. 1 Lizenz 1x Maestro connect: Dienstleistungsvertrag für 1 Jahr (kit Gateway plug&play inbegriffen) 1x Sockel 1x MASCHINENSPRACHE: Deutsch 1x PC SPRACHE DEUTSCH 1x SPEC01 Sonderausfuehrung 01 1x Europäische Sicherheitsvorschriften (Zeichen CE) inkl. 123 Stunden Inbetriebnahme vor Ort (innerhalb Deutschland) (die tägliche Arbeitszeit beträgt 8 Stunden inkl. An- und Abreise). inkl. 1 Tag Online-Schulung MAESTRO OPTIWISE PRO (nach Bedarf) inkl. MAESTRO CONNECT 1 Jahr inkl. MAESTRO PATTERN IMPORT (255€ kostenlos)

Condition: used, Year of construction: 2001, Cutting width: 3300 mm Cutting length: 3350 mm Weight: approx. 4000 kg Saw blade projection: 100-(115) mm Saw carriage: Feed speed: 100-(130) m/min. Return speed: 100-(130) m/min. Main saw blade: 400-(430) mm Motor: 7.5-(11-13.2) kW Scoring unit: 215 mm Motor: 2.2 kW Pusher: Rapid feed: 160 m/min. Return speed: 60 m/min. Extraction: Air speed: 30-35 m/sec. Extraction nozzle: 200 mm / 115 mm Compressed air: Pressure: 5-6 bar Consumption: 20-30 l/min. Iodpfxsvvkqgj Ab Ija Storage location: Nattheim

Condition: used, Year of construction: 2010, functionality: fully functional, Complete Automatic System Beam Saw Giben Prisma 3000 , Cutting 3800 + Systraplan , Professional Stacking and destacking System , Complete line , 24m * 10 m , 2 places for loadin palets by forklift , Capacity about 20-25 palet places , * 5 palets in one place, about 100 pallets , Speed 120m/min longitudinal , 80 m/min * short side , Load capacity of the vacuum system 500 kg , Iodpfx Ajv H Ufvsb Isa More pictures and videos avilable ,

Condition: refurbished (used), functionality: fully functional, Panel Dividing System PA 4115 – 3100 x 3100 DNC-AT Condition: Completely overhauled Warranty: 1-year warranty Technical Specifications: Left-angle stop according to AGA 4383 Longitudinal Saw FM 16-3100: - Hardened guides - Automatic forward and return travel of the saw unit - Return travel with automatic lowering - Feed speed: 2–50 m/min (stepless adjustment via potentiometer) - Return speed: 70 m/min (rapid traverse) - Integrated extraction channels in the machine base and pressure beam - Scoring saw adjustable from outside (without opening the safety hood) - Saw unit with controlled DC drive: - Precise positioning (e.g. for cutouts) - Slowed extraction from the cut - Includes safety hood locking, SZ 5008 lamella curtain - Offcut device SP 5004 – Offcuts down to at least 5 mm - Main saw motor: 7.0 kW - Scoring saw motor: 1.1 kW (can be switched off separately) - Cutting length: 3100 mm - Cutting height: 70 mm - Dust tested: Threshold of 2 mg/m³ is significantly undercut - CE compliant Ijdpfx Asxhg Ibeb Isa Angle Pressure Device WP 5003: - With pressure claw for cross cuts - Adjustment range up to 2400 mm - Semi-automatic function Material Feed Table HP 5021 (mounted at rear of FM 16): - Parallel fence with 6 spring-loaded clamping fingers - Direct drive of material pusher via servo motor - Table surface with closed Pertinax panels (suitable for narrow strips) - Feed speed: 25 m/min (safety limited) - Return speed: 40 m/min - Table length: 3100 mm - Stop depth: 3100 mm Multi-microprocessor control Integrated PC with hard disk Operating system: LINUX Interfaces: serial + parallel, USB Network connectivity (also wireless LAN) Optimize cutting plans in the office and send directly to the machine Multitasking capable Printing function via USB Remote maintenance via Internet (Remote Desktop, TeamViewer) Multilingual dialog programming 15” flat screen + multifunctional keyboard Swiveling control panel Graphical representation of cutting plans and work processes Additional Equipment: Angle Stop Table HP 5043 (front mounted): - Machined steel angle, Pertinax table top - Table size: 1800 × 800 mm Workpiece Support Table HP 5025 (front mounted): - Pertinax surface - Table size: 1800 × 800 mm Air Cushion Device LK 5030 - Integrated into HP 5043 and HP 5025 Accessories: - 1 Circular saw blade KSB 4005 – Ø 305 mm, Z=60 (for main saw) - 1 Circular saw blade KSB 4006 – Ø 200 mm, Z=60 conical (for scoring saw)

Condition: excellent (used), Year of construction: 2012, Panel saw SCM Sigma Impact with rear loading system. Machine dismantled. Isdsw Rdkaopfx Ab Iea

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, cutting length (max.): 3,200 mm, saw blade diameter: 350 mm, cutting height (max.): 105 mm, cutting width (max.): 1,300 mm, total length: 4,300 mm, overall weight: 1,300 kg, input frequency: 50 Hz, input voltage: 400 V, power: 7.35 kW (9.99 HP), rotational speed (max.): 4,000 rpm, pivoting range: 45 °, The Concept 350 combines the advantages of various saw systems: As flexible as a panel saw, the cutting quality of a pressure beam saw, and as ergonomic as a trimming saw. This is the sawing concept for modern industrial production. The machine is a leasing return. Iedpfx Abswzuips Ioa Further technical data: - Motorized rip fence with 4 aluminum stops, which move synchronously - Screen control with 8" touchscreen - Air requirement: 6 bar - Sliding table: 1,000 x 400 mm (extension table) - Outrigger table size: 3,200 mm with 2 digital stop jaws - Extraction connection: 1 x 100 mm, 1 x 120 mm - Feed speed: 0 - 40 m/min Special features: - Programmable saw blade height adjustment - Mitre fence +/- 50° - Cutting line laser - Additional support table 800 x 200 mm With the new Concept 350, you no longer need a panel saw! The workpiece rests on the machine and is positioned precisely with a pressure beam. The saw unit can be swiveled from 90° to 45°, is guided with precision, and cuts your workpiece at a constant feed speed of 0–40 m/min, ensuring the best possible cutting results. The standard crosscut fence enables quick cutting to length and efficient operation, with significantly less space required compared to any sliding table saw! Advantages over a sliding table panel saw: - Significantly less space required - The pressure beam secures the workpiece on the machine and guarantees optimal cutting results - The pressure beam prevents the operator from reaching into the saw blade - Ergonomic operation, as the operator no longer has to push the material through the saw blade - Time saving, as the operator does not need to guide the material during the sawing process Including delivery and installation within postal code areas 71, 72, 73, 77, 78, 79, 86, 87, 88, 89.

Condition: excellent (used), Year of construction: 1999, cutting length 3.200 mm cutting width 3.200 mm cutting hight 65 mm saw blade DM max. 300 mm saw blade motor: 5,5 kW scoring unit DM max. 160 mm motor scoring unit 1,5 kW front support tables 3 Stk. 1 x 2500 x 500 & 2 x 1500 x 500 mm cutting optimisation program no. of grippers 8 pcs saw blade hight adjustment on THK guides pressure beam with openings side pusher (alignment) saw blade quick change system suction DM1 x 120 & 1 x 150 mm space requirement L x B 5700 x 6000 mm weight approx. 2500 kg INVERTER NEW Advise used machines: • Technical data without obligation, mistake and intermediate sale reserve. • Price is considered ex-location price • All articles or machines are bought as seen without any entitlement on warranty. Iedpfohvan Iox Ab Ija • It is left to the choice of the buyer to view the machines before at its location. • Special arrangements are possible but only valid in written form. (We answer your inquiries only with stated address + telephone number!)

Condition: used, Year of construction: 2011, WINCUT Numerical Control Working dimensions mm 3800 x 3800 Max blade projection (mm) 107 Front panel loading N. 10 pincers on the pusher carriage Lateral aligner Scoring group (max blade diameter / power) 160 / Kw 1,5 Main blade unit (max blade diameter / power) 380 / Kw 7.5 Adjustable speed of the blade carriage (m/min) 1 - 135 Pusher carriage speed 70 m/min N. 3 air curtain front benches TECHNICAL DETAILS TO CHECK WHEN THE MACHINE WILL BE IN OUR WAREHOUSES Iedpfx Abewwrywo Iea

Year of construction: 2006, condition: ready for operation (used), AUTOMATIC FRONT-LOADING SECCIONADORA AUTOMATIC FRONT-LOADING OF OCCASION Make: SCM Model: SIGMA IMPACT year 2006 CE regulation Useful cutting dimensions: 3200 x 3200 mm. Cutting height 67 mm 3 long first air tables and two shorter wide air tables 6 Pneumatic clamps Main saw motor 10 HP Scorer. Iedpfx Abshkr A So Ija PC. WINCUT software.

Condition: as good as new (ex-display), functionality: fully functional, input voltage: 400 V, Mayer panel dividing saws impress with the usual well thought-out machine concept and numerous detailed solutions that get to the heart of every requirement. Each machine type stands for absolute top performance in its own right. However, the more varied the requirements of the materials to be cut, the more it is the small details that determine the success of the entire process. With heavy and solid saws, Mayer relies on durable quality and high-quality mechanical engineering. The overall concept is also impressive: the heavy-duty design with steel pressure beam and material pusher, simple operation in one-man operation and maximum process reliability with the modular cutting optimization program and the new software packages guarantee maximum performance and precision in efficient panel cutting. The modular cutting optimization program with barcode labelling stands for maximum process reliability. The saw carriage with main and scoring saw unit is guided on a hardened and ground round shaft guide system. The extremely smooth running of the saw carriage at cutting speeds of 5 to 100 meters per minute is ensured by the high-precision drive via a gear wheel and rack and pinion system. The high-end cutting edges are achieved by the automatic cutting height adjustment for the optimum saw blade entry angle and extremely smooth running of the saw carriage. The double measuring system guarantees the highest possible repeat accuracy. The pressure beam opens depending on the material height, which reduces material travel times to a minimum. The "Greenline package" with controlled suction slides and direct control of the motors can reduce energy consumption by up to 30%. Additional equipment 30 Air cushion table 2300 x 600 mm 42 Package clamp, single-finger design 41 Additional package clamp, position 493 mm 61 Thermal label printer 90 Preparation for network connection 700 Ardis module 1 710 Ardis module 2 714 Postprocessor 720 Ardis module 3 723 Label printing 725 Barcodes for labels 727 Edge calculation 740 Ardis module 4 747 Network license manager 748 Additional network workstation Further technical data: Iedpfx Aju Egygeb Ija Motor power: 12 hp (9 kW) Suction connection: 120 / 100 mm Feed speed: 5-100 m/min Saw blade projection: 77 mm Saw carriage and material pusher can perform cuts up to 3200 millimetres long Return speed: 130 m/min Angled table: 2300x600 mm 2x material table: 1800x600 mm

Condition: new, SCM gabbiani p90 panel dividing saw - exhibition machine - special price! Technical data: Saw blade projection mm 90 Worktable height mm 950 Number of collets 5 as standard CUTTING DIMENSIONS mm 3300 x 3200 Variable saw carriage speed m/min 6 - 60 Variable pusher speed m/min 0 - 60 Saw blade motor power kW 7.0 Speed rpm 4650 Saw blade diameter mm 340 Saw shaft diameter of main saw blade mm 80 Scoring motor power kW 1.5 Speed rpm 5850 Scoring blade diameter mm 200 Scoring blade shaft diameter mm 80 Compressed air requirement NL/min 300 Compressed air bar 7.0 Extraction air requirement m3/h 2440 Extraction air speed m/sec 20 Suction nozzle diameter mm 4x120 including the following options: 590134 Cutting depth 3200 mm (version 33) Ijdsiz A Amepfx Ab Ija OF0263 eye-M control panel with integrated PC 590261 Cut editor OF0454 Maestro pattern 590271 Maestro connect: preparation without "gateway" for subsequent installation OF0457 Human-machine interface software (HMI) MAESTRO ACTIVE 590258 Rear table with castors, on the side of the longitudinal stop 590246 Fixed air cushion table 2500x800 mm with castors and reinforced fan 590239 2 x movable air cushion table 1500x600 mm with castors and reinforced fan 590244 Saw carriage with independent stroke control of the saw and scoring saw blade 590245 Optimized vertical stroke of the saw blade on 2 levels (medium/maximum) 590143 Device for grooves with manual height adjustment of the saw blade 590241 Execution of grooves (feed/return of the saw carriage) 590164 Double lateral automatic aligner 301230 Foot switch for starting and stopping the work cycle 590044 Compact labeling unit - printing of labels with barcode 590144 4 x additional clamps 900088 Magnetic tape monitoring of the pusher position 102015 European safety regulations (CE mark) 109993 MACHINE LANGUAGE: German

Condition: new, NEW CAR Power Control Numerical Control with NX Cut System Software and NX Pareto optimizer Isdpfxjrufznj Ab Iea Barcode labeler with software Cutting length mm 3800 Cutting width mm 3800 Blade protrusion mm 90 Front panel loading and unloading Automatic lateral aligner positioned in the blade carriage N° 1 fixed front table in bakelite with air curtain system for unloading the panels N° 2 mobile front tables in bakelite with air curtain system for unloading the panels Main blade, max diameter 380 mm, 15 kW motor Scoring blade, max diameter 200 mm Blade carriage speed forward 1 - 90 m/min. - backward 120 m/min. Pusher speed 85 m/min. Pusher carriage with 9 pincers
