Used Toolholder for sale (278)

Condition: excellent (used), Here we offer you a ToX full punched rivet system. ToX full punched rivet system type TZ-VSN The full punch rivet severed all joining and pushes the slug from the joint. TOX PRESSOTECHNIK, supplemented with innovative technology for full self-piercing rivets the specialist for sheet metal connections, his delivery and performance program is a pioneering procedure. The full punch riveting offers an additional mechanical connection of sheet metal, This is for lightweight construction and the combination of hybrid parts and assemblies of great importance. The rivet advancements, forceps, and toolholders are also so universally designed, that full punching rivets with a diameter of 4.0 mm and lengths between 3.3 and 8.1 mm as well as full punching rivets with a diameter of 5.0 mm and lengths between 3.9 and 9.0 mm with TOX - hand pliers as well as with TOX robot pliers flexible can be processed. Type TZ-VSN Kdedpfx Ajdz Afwodwog Pressing force 55KN Total stroke 140 mm Rivet type: Diameter 5 x 4, 6 Connection values Performance: 3,4KW Power supply: 400/15/50-60 V / A / Hz Speed: 200mm / s Web form: 3 p + N + PE Control voltage: 24 V DC Back-up fuse: 25 A Type: TZ-VSN Condition: pre-owned / used Scope of delivery: (See image) (Errors and omissions in the technical data, information are reserved!) We can answer questions on the phone for you. Written order possible by email or fax

Condition: excellent (used), Here we offer you a ToX full punched rivet system. ToX full punched rivet system type TZ-VSN The full punch rivet severed all joining and pushes the slug from the joint. TOX PRESSOTECHNIK, supplemented with innovative technology for full self-piercing rivets the specialist for sheet metal connections, his delivery and performance program is a pioneering procedure. The full punch riveting offers an additional mechanical connection of sheet metal, This is for lightweight construction and the combination of hybrid parts and assemblies of great importance. Kedpsdz Af Ajfx Adwodg The rivet advancements, forceps, and toolholders are also so universally designed, that full punching rivets with a diameter of 4.0 mm and lengths between 3.3 and 8.1 mm as well as full punching rivets with a diameter of 5.0 mm and lengths between 3.9 and 9.0 mm with TOX - hand pliers as well as with TOX robot pliers flexible can be processed. Type TZ-VSN Pressing force 55KN Total stroke 140 mm Rivet type: Diameter 5 x 4, 6 Connection values Performance: 3,4KW Power supply: 400/15/50-60 V / A / Hz Speed: 200mm / s Web form: 3 p + N + PE Control voltage: 24 V DC Back-up fuse: 25 A Type: TZ-VSN Condition: pre-owned / used Scope of delivery: (See image) (Errors and omissions in the technical data, information are reserved!) We can answer questions on the phone for you. Written order possible by email or fax

Condition: used, Year of construction: 2003, Mazak Integrex E-410H Multi-Tasking Lathe with Mazatrol 640M Pro Control, Serial No. 164385 (2003). Country of Origin: Japan Kdjdox T Df Dspfx Adwog Please note: Toolholders/Tooling photographed in the toolchanger will not be supplied with this machine. Any available tooling will be a specifically described. Please Note: This lot is located in Birmingham, UK. A charge of £4,500 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: used, Year of construction: 2002, Mazak Integrex E-650H Multi-Tasking Lathe with Mazatrol PC-Fusion 640M Pro Control, 3000mm B/C, SMW-Autoblock KS-MSW 135-460mm Hydraulic Steady, Boring Bar Attachment, 120 ATC, Swarf Conveyor. S/No. 159927 (2002) Country of Origin: Japan Ksdpfsx T Dfwex Adwedg Please note: Toolholders/Tooling photographed in the toolchanger will not be supplied with this machine. Any available tooling will be a specifically described. Please Note: This lot is located in Birmingham, UK. A charge of £4,500 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, * Okuma LB 3000 MY. * Included equipment value: 20,000–24,000 euros. * 4-axis machine. * Fully independent tailstock, programmable in Z-axis movement and locking via M codes. * 12-station turret, all stations live (motorized). * C-axis. * Y-axis. * Main spindle with built-in motor, 18.5 / 22 kW. * Motor for driven tools: 5.5 kW. * Spindle start-up torque: 620 N·m. * Integrated motor, direct drive without belts or gear steps. * Main spindle nose: A2-8. * Tailstock Morse taper: MT5. * Bar capacity: 75 mm. * Spindle chuck: Kitagawa B-210. * Hardened box ways on all axes. * Main spindle speed: 4,200 rpm. * Driven tool speed: 4,000 rpm. * Swing diameter: 520 mm. * Max turned diameter: 380 mm. * Max turning length: 1,050 mm. * Headstock oil chiller. * IGF OSP P200-L conversational automatic programming system. * Automatic load monitoring and tool consumption monitoring. * Parameterized automatic tool collision avoidance system. * Tool life management and monitoring system. * Rapid traverse speed: 20 and 25 m/min on X and Z axes. * Turret index time: 0.2 seconds. * Renishaw automatic tool measurement arm. * Communication ports: USB, PCMCIA card, and RS 232. Kjdpfx Aoyaxmbjdwsdg * Dual pedal for main chuck and tailstock open/close. * Side chip conveyor, hinged type. * Complete set of external and internal static toolholders. * Complete set of axial and radial driven toolholders. * Electrical transformer. * Documentation: parts list, electrical diagrams, programming, and operation manuals. * Weight: 6,200 kg. * Machine currently in operation. * Immediate delivery subject to prior sale.

Condition: ready for operation (used), Year of construction: 2016, Control Unit Brand OKUMA Model OSP-P300S-H Movement Y-Axis Movement 160 Additional Equipment Y-Axis Machining Kit: Helical interpolation /Y-axis turning function with offset turning toolholders/ Coordinate conversion /Double pressure clamping system for main spindle chuck via M-codes (irreversible) /Double pressure clamping system for sub-spindle chuck via M-codes (irreversible) 60 tool ATC / High-pressure coolant preparation: 70 bar/ External coolant pump: 0.8 kW, 6 bar, 20 L/min/ Electric spindle orientation /Air blast for chuck cleaning Kdedpfx Aex D R Uwsdwsg Collision Avoidance System (CAS)/Chip Conveyor Preparation/Big Bore Spindle ASA 6": 22/15 kW, 3800 rpm/ High-precision C-axis positioning/ Continuous B-axis/ Tool Magazine with 60 positions/ 0.1 Micron Resolution Software/ API Library 2 for OSP-P300S/ Standard Right Side Chip Conveyor/ 15 Bar Coolant Pump 20 L/min/ Filtration unit with 4 fabric filter bags (25 micron), pump 15 bar, 20 L/min SCHUNK ROTA THW+260-81R A8 chuck with KITAGAWA SS1770 cylinder for Big Bore main spindle SCHUNK ROTA THW+215-66 A6 chuck with KITAGAWA SS1452 cylinder for sub-spindle 5-Axis Machining Kit: Super NURBS on 5 axes /Vector control /DNC-DT interface /Tool position control/ 3D coordinate transformation /Helical interpolation (includes inclined plane profile software) This 5-axis OKUMA MULTUS B300 II W was manufactured in 2016. It features an ASA 8 spindle offering 5,000 rpm and 65 mm bar capacity, capable of handling a max turning diameter of 630 mm. It includes a high-pressure coolant preparation of 70 bar, a continuous B-axis with HSK63, and a tool magazine with 60 positions, optimizing both turning and milling capabilities. If you are looking for high-quality turn-mill operations, consider this OKUMA machine. Contact us for more information about this machine. Application Types Turning

Year of construction: 2008, condition: ready for operation (used), General Data Kdjdpfx Adex D I Rioweg Machine weight 9100 kg Control Unit Brand MAZATROL Model Mazatrol Matrix Main Drive Spindle speed range 3300 Spindle motor power 30 kW Number of axis 3 Workpiece Workpiece drm over bed 830 mm Turret Number of turrets 1 Tools Number of station 12 Media Chip conveyor Yes Additional Equipment Chip conveyor Tool presetter Autoblock chuck Toolholders User and maintenance manuals This 3-axis Mazak QT Nexus 350 II M was manufactured in 2008. It features a Mazatrol Matrix control unit, a maximum swing over bed of Ø 830 mm, and a turning length of 1500 mm. The spindle supports speeds up to 3300 rpm with a power of 30 kW. It includes a chip conveyor and tool presetter. If you are looking to get high-quality turning capabilities, consider the Mazak QT Nexus 350 II M machine we have for sale. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 2001, Union KCU-130 Table Type Horizontal Boring & Milling Machine with Heidenhain TNC430 Control, X/Y/Z = 4000/3000/1500mm, Table Size 2000 x 2500 x 20,000kgs, B-axis 360 Deg, Spindle Taper BT50, 60 Position ATC, W-axis, U-axis, Swarf Conveyor, Through Spindle Coolant, Guarding Enclosure. S/No. 1370022 (2001) Please Note: Toolholders/Tooling photographed in the toolchanger will not be supplied with this machine. Any available tooling will be a specifically described. Kdsdpfx Adsx T Ddyewog Please Note: This Lot is located in Irvine. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: good (used), Year of construction: 2006, functionality: fully functional, The used SPINNER TC77 SMCY counterspindle Y-axis motorized cnc lathe is a robust CNC tilting lathe with ASA 8" size flat guideways, with BARUFFALDI automatic 2-speed gear-driven range change, equipped with a counterspindle and spindle both with "C" axis and a motorized Y-axis turret with 120mm travel (+60/-60 mm) VDI 50. Completing the configuration is the FANUC i-series cnc with color lcd and Manual Guide i conversational programming, ethernet interface, RS 232 port and memory card for program entry, chip evacuation, 315mm BB 3-jaw hydraulic chuck, a set of motorized toolholders (10 pieces) and several fixed ones, and a large set of clamps. Main features: Kdedpjuizuksfx Adwog Maximum turning diameter 690 mm Max. standard turning diameter 500 mm Max. workpiece length 800 mm Max. main spindle bar diameter 77 mm Max. secondary spindle bar diameter 52 mm Main spindle chuck self-centering 315mm Secondary spindle chuck chuck 210mm Max. x-axis travel 360mm Max. Y-axis travel 120 mm (-55/+65) Max. z-axis travel 980 mm Main spindle ASA 8" 26kW main spindle up to 1030 Nm torque and max. 4000 rpm. ASA 6" 18kW secondary spindle ASA 6" up to 113 Nm torque and rpm of maximum 4000 rpm. 12-position VDI 50 tool changer turret (rotating 4,000 rpm). Machine weight: approx. 6,000 kg Year of construction 2006, installed 2008, with about 5,800 working hours; "CE" compliant complete with manuals.

Condition: used, Year of construction: 2000, centre height 280 mm centre distance 1200 mm turning diameter over bed 570 mm turning diameter over slide 365 mm turning length 1000 mm spindle taper DIN 55027 Gr. 8 control Sinumerik 810 D SIEMENS bed width 360 mm spindle bore 62 mm turning speed range 3 - 2500 U/min feed: 5000 mm / min rapid travel - longitudinal/face 10 m/min 3-jaw-chuck diameter 250 mm quick change toolholder SANDVIK Coromant Capto drive capacity - spindle motor 25 kW taper in tailstock-quill MK 5 Kdedpfx Ajx E Dn Aedwog dia. of quill 100 mm quill stroke 190 mm voltage 400 V weight of the machine ca. 5,0 t dimensions of the machine ca. 3,55 x 2,20 x 1,95 m - Serial No.: 2022-3742-03 - CNC-Control SIEMENS Sinumerik 810 D - Rapid feed - Coolant equipment - Machine lamp

Condition: new, neu ca. 4 Monate ab Auftragse Bulgarien 36070 € 688.94 € 400 mm 1000 mm 200 mm 52 mm 235 mm 320 mm 6 6 M 12 50-2.240 1/min 80 0.015 - 0.6 mm/U 0.0075 - 0.3 mm/U 40 0.25 - 7.5 mm 120 - 4 Gänge/" 0.0625 - 1.875 480 - 16 235 mm 110 mm 50 mm 4 MK 100 mm 4 kW 2750 mm 1100 mm 1600 mm 1540 kg driven by manual transmission 3-axes digital readout Fagor 40i quick change toolpostMultisuissewith4 holders (3 square, 1 round) 3-jaw chuck Bison 3204/DIN6350, Ø 200 mm spindle noseNr. 6 DIN 55027 Kdedpfxjxzuu Aj Adwjg four way rapid traverse device spindle dead center coolant equipment 1 pce. flange plate for lathe chuckØ 200 mm 1 adapter sleeve full length rear splash guard leadscrew and shaft protection safety guard for the chuck toolholder guard levelling bolts and plates quick release tailstock low voltage machine lamp operating manual machine according to "CE" FURTHER TURNING LENGTHS: turning length 750 mm € 35 360,00

Condition: used, Year of construction: 2020, gebraucht 2020 1658 prompt, Zwischenverkauf v Bulgarien 26500 € 1 22600 € 400 mm 1000 mm 200 mm 52 mm 235 mm 320 mm 6 6 M 12 50-2.240 1/min 80 0.015 - 0.6 mm/U 0.0075 - 0.3 mm/U 40 0.25 - 7.5 mm 120 - 4 Gänge/" 0.0625 - 1.875 235 mm 110 mm 50 mm 4 MK 100 mm 4 kW 2750 mm 1100 mm Kodpjwirdtjfx Adwedg 1600 mm 1540 kg This machine is used in our workshop for repair work, therefore it has only been used very little so far. (New price € 36,070.00) driven by manual transmission 3-axes digital readout Fagor 40i quick change toolpostMultifix Type Bwith4 holders (3 square, 1 round) 3-jaw chuck Bison 3204/DIN6350, Ø 200 mm spindle noseNr. 6 DIN 55027 four way rapid traverse device spindle dead center coolant equipment 1 pce. flange plate for lathe chuckØ 200 mm 1 adapter sleeve full length rear splash guard leadscrew and shaft protection safety guard for the chuck toolholder guard levelling bolts and plates quick release tailstock low voltage machine lamp operating manual machine according to "CE"

Condition: like new (used), functionality: fully functional, tool type: VDI 40, overall weight: 10 kg, At a glance  Extremely compact construction for critical length threads  Thanks to disengaging clutch thread length is precisely controlled  One single head for internal and external threads  Integrated coolant supply (with coolant feed through centre on request)  Available in  ANGST Flex or ESX (ER) Collets  Sizes 1, 2, 3, 4 and 6  All usual shanks e.g. cylindrical, cylindrical with flat (Weldon), DIN 69880 / VDI 3425, SK DIN 69871, BT (Japan Standard MAS 403), ISO Caterpillar and Morse taper  Heavy-duty and durable Swiss quality products PAFIX Tapping Head for CNC machines  The PAFIX CNC head has been designed especially for all machines with programmable forward and Kdedpfoxltzvex Adwjg return feeds to the toolholder (turret, spindle, etc.). It is of extremely compact length and is fitted with a positive disengaging clutch which can be set to 3 different pull-out lengths if required, for example with head size 25-2…, 1,5/3/5 mm.  The head can be set to two different programmed tapping cycles as follows. Both cycles ensure a certain amount of pitch compensation (float). In order to make sure of faultless thread cutting with precise starting point and depth or length of the thread, no spring take-up thread lead or friction clutch against overload has been provided. The PAFIX CNC is designed to permit a quick change over from tapping head to die head. Simply unscrew the collet nut and replace with the die housing.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 7213, Country of manufacture: Switzerland Net weight: approx. 2550 kg Customs tariff number: 8458.11 20 Dimensions: 2000 x 1260 x 1950 mm TECHNICAL CHARACTERISTICS 10-axis machine – standard version 10 axes, 6 spindles: Axes and spindle designation: - 1 sliding headstock: Z1, S1 - 2 independent vertical gangs: X1Y1, S6 – X2Y2, S2 - 1 unit with 4 rotating spindles: X3Z3, S3 - 1 independent sub-spindle: Y4Z4, S4 - 1 independent rotating sub-operation axis: X4, S5 Bar feeder position: right of the operator Machine axis height: 1100 mm Main spindle travel: max. 255 mm Bar capacity: 1 to 16 mm Spindle speed: 12,000 rpm Spindle feed rate: max. 20 m/min Bar capacity, min./max.: 13 mm / 16 mm Max. workpiece length: Guide bush machining: 180 mm Collet machining: 30 mm Sub-spindle speed: 12,000 rpm Main spindle drive power: 2.2 kW (continuous) / 3.7 kW (intermittent) Sub-spindle drive power: 1.5 kW (continuous) / 2.2 kW (intermittent) Clamping collet, type: F20 (no. 76-201) Guide bush: fixed / rotating Collet for guide bush, type: Meister 605 Number of lateral tool stations, combined: Fixed: 2 x 5 Rotating: 3 + 3 Number of frontal tool stations, combined: Fixed: 4 Rotating: 3 Number of rear tool stations, combined: Fixed: 3 + 3 Rotating: 3 + 3 Tool section: 12 x 12 mm Standard revolving toolholder: ESX 20 Bar feeder: yes Kdsdow T Tcwopfx Adweg Part catcher: yes All technical details are provided without guarantee and subject to errors or omissions.

Condition: good (used), Year of construction: 2001, functionality: unexamined, machine/vehicle number: 2491, Country of manufacture: Switzerland Net weight: approx. 2550 kg Customs tariff number: 8458.11 20 Dimensions: 2000 x 1260 x 1950 mm TECHNICAL CHARACTERISTICS 10-axis machine – standard version 10 axes, 6 spindles: Axes and spindle designation: - 1 sliding headstock: Z1, S1 - 2 independent vertical gangs: X1Y1, S6 – X2Y2, S2 - 1 unit with 4 rotating spindles: X3Z3, S3 - 1 independent sub-spindle: Y4Z4, S4 - 1 independent rotating sub-operation axis: X4, S5 Bar feeder position: right of the operator Machine axis height: 1100 mm Main spindle travel: max. 255 mm Bar capacity: 1 to 16 mm Spindle speed: 12,000 rpm Spindle feed rate: max. 20 m/min Kdodpfx Adsw Uc D Hswog Bar capacity, min./max.: 13 mm / 16 mm Max. workpiece length: Guide bush machining: 180 mm Collet machining: 30 mm Sub-spindle speed: 12,000 rpm Main spindle drive power: 2.2 kW (continuous) / 3.7 kW (intermittent) Sub-spindle drive power: 1.5 kW (continuous) / 2.2 kW (intermittent) Clamping collet, type: F20 (no. 76-201) Guide bush: fixed / rotating Collet for guide bush, type: Meister 605 Number of lateral tool stations, combined: Fixed: 2 x 5 Rotating: 3 + 3 Number of frontal tool stations, combined: Fixed: 4 Rotating: 3 Number of rear tool stations, combined: Fixed: 3 + 3 Rotating: 3 + 3 Tool section: 12 x 12 mm Standard revolving toolholder: ESX 20 Bar feeder: yes Part catcher: yes All technical details are provided without guarantee and subject to errors or omissions.

Condition: good (used), Year of construction: 2006, CNC Swiss-Type Automatic Lathe Citizen Cincom M16 Technical Specifications Year of manufacture: 2006 Maximum machining diameter: ø16 mm Maximum machining length: 200 mm per chucking Maximum diameter for frontal drilling: ø6 mm Maximum diameter for frontal threading: M6 Main spindle bore diameter: ø16 mm Main spindle speed: 200 to 10,000 min⁻¹ Main spindle C-axis: 0.001° Maximum clamping diameter sub-spindle: ø16 mm Maximum back-working length: 125 mm Kodpfex Emnrsx Adwedg Maximum part overhang sub-spindle: 25 mm Maximum drilling diameter back-working: ø5 mm Maximum threading diameter back side: M5 Sub-spindle speed: 200 to 10,000 min⁻¹ Toolholder group: max. drilling diameter ø5 mm / max. thread cutting diameter M4 Spindle speed: 200 to 8,000 min⁻¹ Turret: max. drilling diameter ø5 mm / max. threading diameter M5 / spindle speed: 200 to 6,500 min⁻¹ Number of mountable tools: up to 21+α Axis rapid traverse speeds: 20 m/min Minimum programmable increment: 0.001 mm Axis travels: X1: 60.5 mm / Y1: 208 mm / Z1: 205 mm / X2: 107.5 mm / Z2: 133 mm / X3: 195 mm / Z3: 280 mm Main spindle motor power: 2.2 kW Sub-spindle motor power: 0.75 kW Driven tool spindle: 0.75 kW The Citizen Cincom M16 is a high-precision CNC Swiss-type automatic lathe designed for demanding series production of small and precision components. With a machining diameter up to ø16 mm, machining lengths up to 200 mm, and high spindle speeds up to 10,000 min⁻¹, this machine is ideal for complex machining tasks. The integrated C-axis on both main and sub-spindle enables precise positioning, as well as sophisticated milling and drilling operations. The machine offers extensive tool capacity with up to 21 tools and multiple driven tool stations, allowing even complex processes to be completed in a single setup. Generous axis travels and precise feed increments of 0.001 mm ensure the highest manufacturing quality with minimal tolerances. The delivery includes an LNS Express-220 bar feeder from 2011, providing automated material feed to significantly increase productivity and process reliability. Various toolholders are also included in the package. The machine is robustly built and designed for continuous industrial operation – ideal for the production of watch, medical, electronics, or automotive components. No guarantee is given for the correctness, completeness, or currentness of the information provided.

Condition: excellent (used), Year of construction: 2008, Miyano BX-26S CNC Lathe Kjdox Emmhopfx Adwodg TECHNICAL DATA Clamping Units Collet machine with main and sub-spindle: 26 mm Max. turning length with workpiece gripper: 67 mm Maximum part length: Max. 300 mm / Ø 26 mm Clamping cylinder L/R spindle: Stationary Max. drilling diameter L/R spindle: Ø 12.00 mm Max. threading diameter L/R spindle: M8 Spindle Motor power: VAC 2.2/3.7 kW Spindle speed range L/R spindle: 80 ~ 8,000 rpm L spindle travel Z1-axis: 70.00 mm R spindle travel X2-axis: 180.00 mm R spindle travel Z2-axis: 238.00 mm Tool Slides Tool slide: Vertical linear slide Number of tool stations: 16 Number of tool stations Slide 1: 6/4 Tool shank size: 16.00 mm Inner toolholder diameter: Ø 20.00 mm Travel range X1-axis: 135.00 mm Travel range Y1-axis: 260.00 mm Number of turning tools (L spindle) X-/Y-axis: 2/2 (Use for L/R spindle) Z-axis unit: 2+2 Speed range: 100 ~ 4,000 rpm Drive motor for driven tools: 0.5 kW / 0.5 kW Max. drill diameter for driven tools: 8.00 mm Max. drill diameter with driven tool motor: M6 Tool Slide 2 Tool slide: Vertical linear slide Number of tool stations: 7 Number of tool stations Slide 2: 3/4 Tool shank size: 16.00 mm Inner toolholder diameter: Ø 20.00 mm Travel range Y2-axis: 215.00 mm Machine Dimensions Machine height: 1,670.00 mm Floor space (W x D): 2,320 mm × 1,335 mm Machine weight: 3,000.00 kg No guarantee is given for the correctness, completeness, or up-to-dateness of the information provided.

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, DOOSAN PUMA 3100ULY (2012) CNC LATHE WITH ROTARY TOOLS AND “Y” AXIS – “Z” TRAVEL: 3,000 mm SPECIFICATIONS: - FANUC i Series CNC, 10.4” LCD Color Manual Guide - Swing over bed: 850 mm - Swing over saddle: 670 mm - Maximum turning diameter: 420 mm - Maximum turning length: 3,125 mm - Axis travel: X 210 mm, Y ±60 mm, Z 3,125 mm - Chuck size: 400 mm (*) - Bar capacity: 102 mm Kdodpfxex Sqkwe Adwog - Spindle nose: ASA A2#11 - Main spindle: 2,800 rpm, 22 kW - Turret: 12 stations (indexing time per position: 0.25 sec) - Rotary tool motor: 7.5 kW, 5,000 rpm - C-axis indexing: 0.001 mm - Tailstock travel: 3,135 mm INCLUDED EQUIPMENT: - Samchully MH-212 315 mm hydraulic chuck - C axis: 360° (0.001° increments) - Automatic tool setter - Built-in tailstock - Programmable tailstock - High-pressure pump - Chip conveyor - Mechanical, hydraulic, and electrical preparation for automatic steady rest - SMW AUTOBLOK SLU-X-4-ZS hydraulic steady rest - Complete standard toolholder set for internal and external machining, including 4 rotary holders (2 straight, 2 angular) - Set of manuals (Doosan and Fanuc) (All specifications to be confirmed) CONDITION: Under power, in excellent condition. Ready for inspection. Immediate delivery.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 4209.08, turning diameter: 670 mm, spindle speed (max.): 2,000 rpm, travel distance X-axis: 440 mm, travel distance Z-axis: 2,000 mm, controller model: Heidenhain Manual Plus 4110V2, TECHNICAL DETAILS Maximum turning diameter: 670 mm Travel X-axis: 440 mm Travel Z-axis: 2,000 mm Rapid traverse Z-axis: 5 m/min Rapid traverse X-axis: 10 m/min Ksdpfxox Ex A Us Adwodg Spindle bore: 106 mm Speed range: 1 – 2,000 rpm Spindle power: 33 kW Spindle mount: DIN 55026 – A8 Turret mount: Quick-change toolholder Multifix type C Number of turret stations: 1 Tailstock taper: MT5 MACHINE DETAILS Control system: Heidenhain Manual Plus 4110V2 Dimensions & Weight Machine dimensions (L x W x H): 1.9 m + center distance x 2.1 m x 1.9 m Control cabinet dimensions (L x W x H): 1.2 m x 0.5 m x 1.6 m Weight: 5,100 kg EQUIPMENT Ethernet and USB interface for network connectivity Chip conveyor Fixed and traveling steady rest Self-centering 3-jaw chuck (diameter 400 mm) Independent 4-jaw chuck (diameter 600 mm) Faceplate (diameter: 650 mm) Various clamping jaws and top jaws Fixed and revolving centers Approx. 30 Multifix holders type C Drill chuck with MT5 shank

Condition: good (used), Year of construction: 1972, LZ Lathe Manufacturer: HEIDENREICH & HERBECK Type: 21RO Year: 1972 with Parat quick-change toolholder, 10 pieces, machine documentation, thread dial indicator, live center, 250 mm Forkardt chuck. Kedpfx Ajt Ipi Iodwodg Swing over bed: 430 mm Swing over cross slide: 255 mm Center distance: 1000 mm Turning length: 750 mm Spindle speeds: 19-2000 rpm, 5.5 kW motor Spindle bore: 56 mm Further technical data available in the data sheet Required space: Length 2900 mm, Width 1100 mm, Height 1300 mm, Weight approx. 1750 kg Machine documentation available. Coolant system installed, chip guard/rear panel. The machine is in good condition and can be demonstrated under power.

Condition: good (used), Year of construction: 1980, LZ lathe, manuf. VDF HEIDENREICH&HARBECK, Type: 21 RO, year approx. 1980 Equipped with 2-axis digital readout Heidenhain ND 730, rapid traverse in longitudinal and cross directions. Chuck: 200 mm Forkardt. Toolholder: Multifix size B with 2 toolholders. 1 fixed steady rest and 1 traveling steady. Centre height: 240 mm Centre distance: 1250 mm Kdjdpfow S Ituex Adwog Spindle bore: 55 mm Spindle speeds: 19–2000 rpm, motor output 5.5 kW Dimensions (LxWxH): 3.1 m x 1.2 m x 1.3 m. Weight approx. 2000 kg. Machine in good condition.

Condition: good (used), Year of construction: 1962, Centre lathe manufacturer VDF HEIDENREICH&HARBECK type: 24 RO, year of manufacture 1962, overhauled in 1992. Equipped with 3-axis digital readout Heidenhain, 250 mm Forkardt chuck, Multifix B toolholder. Centre height: 255 mm Swing over bed: 510 mm Swing over cross slide: 270 mm Kedpfx Aoxziuwodwjdg Distance between centres: 1000 mm Spindle bore: 55 mm Spindle speeds: 20 - 900 rpm, Motor power: 6.5 kW The machine is in good condition, electrical diagrams available. Required floor space: Length 3 m, Depth 1.2 m, Height 1.3 m, Weight approx. 1800 kg.

Condition: used, Year of construction: 1999, Technical details: x-travel: 1250 mm y-travel: 880 mm z-travel: 800 mm control: Heidenhain TNC 430 tool change unit: 60 Pos. Tool bore: SK 50 turning speeds: 8000 1/min size of pallet: 1000 x 800 mm total power requirement: 56 kVA weight of the machine ca.: 14,3 t dimensions of the machine ca.: 5,5 x 3 x 3,1 m 5-axis machine with controlled universal milling head (B-axis), 2-palett changer incl. 2 palets, 1000 x 800 mm Production package: - internal coolant supply 40 bar with 900l coolant box (2,25 x 1.3 x 2,2m / 950kg), - chipconveyor (4,85 x 1,2 x 1,75m / 600kg), - ROTOCLEAR, - 3D touchprobe RENISHAW MP 10 - 60 pos. ATC SK 50 - el. handwheel - mech. tool-breakage control, accessories (SK 50 toolholders approx. 100.200 h "machine on", approx. 52.200 h "spindle on", last spindle change in 2020 * Kodpfx Adjtq Nlcjwsdg

Condition: used, Year of construction: 2016, Technical details: x-travel: 1000 mm y-travel: 610 mm z-travel: 600 mm table-size: 1150 x 600 mm table load capacity: 1000 kg rapid traverse X- and Y-axis: 24 m/min rapid traverse Z-axis: 24 m/min spindle taper:: SK 40 spindle turning speed range: 10.000 1/min spindle drive: 15/22,5 kW tool change unit: 30 Pos. CNC-control: SIEMENS 828D operate shopmill distance spindle nose and table: 110 / 710 mm weight of the machine ca.: 7 t dimensions of the machine ca.: 3,2 x 2,2 x 2,7 m vertical machining center, - internal coolant supply 30 bar - chipconveyor Kdodpfxjw Hg Syj Adwjg - cartridge filter - flat tracks - el. handwheel - prepared for 4th axis - 3D touchprobe RENISHAW OMP 60 - indirect measuring system - accessories (approx. 30 pcs. SK 40 toolholders incl. 2 racks, chip tray) approx. 6.000h "spindle on" *

Condition: ready for operation (used), Year of construction: 2016, operating hours: 46,976 h, Control Unit Kdsdpfox D Iq Aox Adwsg Brand FANUC Model Series Oi-TD Additional Equipment Transformer 8 KVA / Airblow through the spindle / LNS chip conveyor / Interface for high pressure coolant system with 4 M-codes This Citizen Miyano GN-3200 was manufactured in 2016. It features a Fanuc 0i-TD control, an 8 KVA transformer, MAS quick change toolholders, and a collet chuck device. Additional features include an airblow through the spindle, a tool breakage sensor, a Blum measuring probe, and an LNS chip conveyor. Interface for high-pressure coolant system with 4 M-codes also included. Contact us for more information about this machine. Application Types Turning
