Used Chiron Dz for sale (84)

Condition: excellent (used), Year of construction: 1998, HIRON FZ 18 S MAGNUM HIGH SPEED – 1998 – after a major factory overhaul by CHIRON For sale: a vertical CNC machining center, CHIRON FZ 18 S MAGNUM High Speed, manufactured in 1998. The machine is equipped with a Siemens SINUMERIK control system, an automatic tool changer, and a high-speed spindle designed for efficient and precise machining. It also features an oil mist extraction system with a filter, plus air conditioning for the control system. The most important advantage of the offered machine is the major inspection and overhaul carried out by CHIRON in 2020. As part of the work, key machine components were replaced, including: spindle, control computer, pumps, systems, and other components included in the modernization program. Complete service documentation is available, confirming the scope of the overhaul. Technical specifications: Manufacturer: CHIRON Model: FZ 18 S MAGNUM High Speed Year of manufacture: 1998 Control system: Siemens SINUMERIK Machine number: 493-01 Weight: approx. 7,990 kg Power supply: 400 V Connected power: 27 kVA Automatic tool changer Vertical CNC machining center Podpfx Aezdklpobpjra The machine is complete and ready for further operation. Thanks to the major overhaul performed by the manufacturer, it represents an attractive alternative to much more expensive, newer machining centers. Complete CHIRON overhaul documentation from 2020 is available. Inspection and verification of the machine's condition on-site are possible.

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, overall weight: 7,990 kg, CHIRON FZ 18 S MAGNUM HIGH SPEED – 1998 – after a comprehensive factory overhaul by CHIRON For sale is a CHIRON FZ 18 S MAGNUM High Speed vertical CNC machining center manufactured in 1998. The machine is equipped with Siemens SINUMERIK control, an automatic tool changer, and a high-speed spindle designed for efficient and precise machining. It also has an oil mist extraction system with a filter. The most important advantage of the offered machine is the comprehensive inspection and overhaul carried out in 2020 by CHIRON. As part of the work, key machine components were replaced, including: spindle, control computer, pumps, systems, and other components included in the modernization program. Complete service documentation is available for the work performed, confirming the scope of the overhaul. Technical data: Manufacturer: CHIRON Model: FZ 18 S MAGNUM High Speed Year of manufacture: 1998 Prsdpfezdkhqsx Abpja Control: Siemens SINUMERIK Machine number: 493-01 Weight: approx. 7,990 kg Power supply: 400 V Connected power: 27 kVA Automatic tool changer Vertical CNC machining center The machine is complete and ready for further operation. Thanks to the comprehensive overhaul carried out by the manufacturer, it represents an attractive alternative to much more expensive, newer machining centers. Complete CHIRON overhaul documentation from 2020 is available. Inspection and verification of the machine's condition on-site are possible.

Condition: excellent (used), Year of construction: 2016, Siemens 840 SL control, twin spindle, 20,000 rpm, HSK 63, 2 x 32 tool positions, internal coolant supply at 30 bar, X 550 mm, Y 400 mm, Z 400 mm, direct measuring system, workpiece changer, laser control, Knoll coolant system, fixture flushing system, central lubrication system, automatic loading doors, year of manufacture 2016. Psdpjzb D Rnjfx Abpsra

Condition: excellent (used), CHIRON DZ 18.2 KW, Pedpfsuviiwox Abpsra YOM 2012 Control: Fanuc 31i Path: X / Y / Z 630 x 520 x 400 mm, Pallet changer 2x 940 x 470 mm, 2 spindles Spindle distance 320 mm, 2×32-fold tool changer SK40 tool Max. Spindle rotation 10,000 rpm

Condition: good (used), Year of construction: 1997, The photo shows a Fanuc Series 0-M (a popular CNC controller used in the 1980s/90s). It supports X, Y, Z axis interpolation and a tool magazine. Features include a CRT screen and a classic push-button keyboard. 3. Electrical parameters (nameplate) Power supply: 3-phase, 380 V, 50 Hz Control voltage: (not specified, but typically Fanuc 110/220 V → transformer) Prjdpfx Absw Uab Ajpoa Auxiliary voltage: 24 V Protection: 16 A (flink) Electrical diagram number: 711 792 01 01 4. Machine construction Vertical CNC machining center (milling machine) with a fully enclosed housing. Worktable with grid of holes for mounting workpieces. Carousel tool magazine (visible in the photo) – most often 12, 20, or 24 tools (depending on version). Automatic tool changer (ATC). Z-axis operates vertically (guideway assembly and telescopic way covers visible). 5. Typical technical data (for Chiron FZ 12/15 machines from this period) (values may differ depending on the model, but these are approximate parameters): Travels (X/Y/Z): approx. 500 – 700 / 400 / 400 mm Table surface: 800 × 400 mm (example) Table load: 200 – 300 kg Spindle speed: 20 – 6000 rpm (some versions up to 8000 rpm) Spindle taper: SK 40 (DIN 69871) Spindle drive: 7.5 – 15 kW (depending on version) Tool magazine: 12 – 24 tools Positioning accuracy: ±0.005 mm Rapid traverse: 30 m/min (X/Y/Z axes) 6. Application Metalworking (steel, aluminum, cast iron, light alloys). 📌 General information: • Manufacturer: CHIRON, Germany • Type: CNC machining center • Control: as seen in the photo (Fanuc Series 0-M) • Automatic tool changer • Heavy-duty worktable with workpiece clamping options • Solid industrial construction 📌 Machine condition: • Used machine, in good condition • Regularly serviced • Shows normal signs of use • Fully functional 📌 Application: • High-precision milling • Machining of metal components • Single-part and batch production

Condition: ready for operation (used), Year of construction: 1998, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 630 mm, controller manufacturer: SIEMENS, table width: 850 mm, table length: 1,250 mm, overall weight: 8,000 kg, spindle speed (max.): 10,500 rpm, number of slots in tool magazine: 24, number of axes: 3, This 3-axis CHIRON DZ 18 W MAGNUM was manufactured in 1998. It features an X-axis travel of 400 mm, Y-axis travel of 400 mm, and Z-axis travel of 630 mm. The machine includes a table size of 1250 × 850 mm and a tool magazine capacity of 24 tools. If you are looking to get high-quality machining capabilities, consider the CHIRON DZ 18 W MAGNUM vertical machining centre we have for sale. Contact us for further details. - Control System: Siemens CNC- Spindle Taper/Chuck: SK40- Spindle Speed Range: 320 – 10,500 rpm- Tool Magazine Capacity: 2 × 12 slots (24 tools total)- Tool Change Time: approx. 1.9 s- Chip-to-Chip Time: approx. 3.9 s- Retrofit/Overhaul Date: 2021 - Complete modernization: • main spindles overhauled • ball screws replaced • tool changer overhauled, • axis systems/guides/bearings overhauled • hydraulic/pneumatic systems updated • electrical system and cabling modernized Psdpfx Aozcyh Eobpora • safety elements replaced • geometry adjusted- Cooling System: Internal cooling (IKZ) via Knoll paper band filter and high-pressure unit (Unit Number: 646)- Chip Management: Integrated chip conveyor and swarf bin- Workholding: Hydraulic workpiece clamping on a 180-degree workpiece changing table (W-axis)- Additional Features: Prepared for 4th/5th axis integration, attached cabinet climate control unit

Year of construction: 2006, operating hours: 82,068 h, condition: good (used), functionality: fully functional, machine/vehicle number: 258-22, Moving column machine in steel-concrete composite construction with workpiece changing device. Low-maintenance model from the world-renowned manufacturer CHIRON. Double spindle - vertical - machining center incl. chip conveyor KNOLL AE 1058.009 and a compound unit (already dismantled). Prescribed maintenance intervals for plant and plant parts have always been observed. TECHNICAL DETAILS Drilling capacity in steel: 60: 2 x 6 36 mm (with insert drill) Guides: with long term grease lubrication speed range: 20-12.000 rpm CNC control: SIEMENS 840D spindle distance in X-axis: 250 mm X-axis: 300 mm Y-axis: 400 mm Z-axis: 425 mm (with variable tool change plane) rapid traverse speed 60 m/min in X-, Y- and Z-axis Main spindle drive: 1 piece with 2 AC motors power at 100 % ED: 9,5 kW power at 15 % ED:14,0 kW Drive: digital direct drives with indirect absolute path measuring system (no reference point approach) tool places: 212 Tool diameter: max. 65 mm Tool diameter with free neighboring places: max. 175 mm Tool weight: max. 2.5 kg (5.0 kg at 2 stations) Tool change time: approx. 0.9 s (depending on control) Chip-to-chip time: approx. 2.1 s (control-dependent) Workpiece changing device: 0 / 180 Tool holder: HSK A 63 1 MACHINE DETAILS type of current: 3 / N / PE - 50/60 Hz operating voltage: 400 V power: 44 kVA rated current: 63 A Coolant system HL 450 / 900 LATE CONVEYOR Manufacturer: KNOLL Type: AE 1058.009 Year of manufacture: 2006 EQUIPMENT - CHIRON maintenance manual on screen - Operating hours and piece counter - Socket 230 V - Socket for portable mini handwheel - Control cabinet cooler as door-mounted unit - Signal lamp - splash guard cladding - chip conveyor - mini control panel - Rinsing gun - Central pneumatic connection - Fixture flushing - 70 bar HP pump - 1 internal cooling package with suction unit - Fully enclosed working chamber - Extraction unit with air cleaner - Extraction capacity 800 m³/h - CHIRON mold life monitoring with: - Automatic loading door of the splash guard Prodpfx Aomt A Ivobpoa - "opening" and "closing", actuation via two-hand start release - Integrated IWW 0/180° workpiece changing device - Chiron Lasercontrol Single F500 - Ethernet connection RJ45 at the control cabinet instead of in the control panel - Pneumatic and hydraulic connections - Central hydraulic and pneumatic connection prepared for max. 20 connections, 6 connections are designed including connection couplings, 4 of them for hydraulics, max. 210 bar and 2 for uncontrolled pneumatics. - 4 Additional hydraulic connection(s) - Hydraulic power unit - 2 Hydraulic aggregate extension for further clamping circuits

Condition: ready for operation (used), Year of construction: 2011, operating hours: 21,578 h, travel distance X-axis: 630 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 360 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle speed (max.): 12,000 rpm, number of axes: 4, This 4-axis CHIRON DZ15KWM HS was manufactured in 2011. Ideal for precision vertical machining, this model offers robust construction and reliable performance. If you are looking to get high-quality milling capabilities, consider the CHIRON DZ15KWM HS machine we have for sale. Contact us for more information. Extra Information • Machine still under power • Table width 860 mm • Spindle spacing 320 mm • Tool positions 24 • Tool holder HSK63 • Hours 21578 • Internal coolant pressure: 80 bar Pjdpfjzicf Sox Abpera Optional for extra charge • Optional for extra costs: Tool holders available. see pictures • Kuka robot (see nameplate attached for specification) • Platform, robot base, control cabinet including electronics, fence including door and locking mechanism • 3 conveyor belts including sensors, camera including lighting, automatic washing and blow-off station • Gripper including sensors, PC and touchscreen Technical Specification Taper Size HSK 63 Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 2015, travel distance X-axis: 730 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 425 mm, controller manufacturer: FANUC, controller model: Series 31i B5, spindle speed (max.): 12,000 rpm, spindle motor power: 15,000 W, number of axes: 3, This 3-axis CHIRON DZ15W MAGNUM HS was manufactured in 2015. It features an X-travel of 730 mm, Y-travel of 400 mm, and Z-travel of 425 mm. The machine is equipped with a robust table surface measuring 1,060 mm x 430 mm. If you are looking to get high-quality machining capabilities, consider the CHIRON DZ15W MAGNUM HS vertical machining centre we have for sale. Contact us for further details. • Quantity: 4 units available • Spindle drive: 14/15 kW Prjdezhm Emepfx Abpea • Max. torque: 95 Nm • Table surface: 1.060 mm x 430 mm Technical Specification Taper Size HSK 63

Condition: used, Year of construction: 2014, operating hours: 24,209 h, functionality: fully functional, machine/vehicle number: 286-56, total height: 3,000 mm, total length: 4,545 mm, total width: 2,450 mm, table width: 860 mm, table height: 975 mm, overall weight: 10,800 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 7,500 W, number of spindles: 1, number of slots in tool magazine: 48, Equipment: chip conveyor, documentation/manual, For sale is a CHIRON FZ15 W Magnum high-speed machining center (Type 286-56) from 2014. The machine is a fast, single-spindle traveling column machine with an integrated workpiece changer and a FANUC control (31i series), designed for productive series machining of metal and plastic parts (milling, drilling, threading, reaming, boring). Technical data: Control: FANUC 31i Travel ranges X/Y/Z: 730 / 400 / 360 mm Rapid traverse X/Y/Z: 75 m/min Spindle speed max.: 12,000 min⁻¹ Spindle power: 7.5 – 15.0 kW Spindle torque max.: 95 Nm Tool holder: HSK-A63 Tool magazine: Chain magazine, 48 positions Max. tool length: 300 mm Max. tool diameter: 78 mm (140 mm with free adjacent position) Max. tool weight: 8 kg (10 kg with reinforced positions) Workpiece changer (tandem/tilting device), bridge dimension 800 mm, max. fixture height 234 mm Enclosed cabinet, coolant emulsion Equipment / Peripherals: Coolant system TPF 350S (Bürener) with paper band filter and double safety filter, filling volume approx. 980 l Tool internal cooling (high pressure through spindle) Chip conveyor Extraction system / emulsion mist separator (Handte, EM Compact 800) Control cabinet cooler Oil central lubrication Prsdpfx Aszv Tlvsbpsa Table measuring probe Renishaw TS27R Coolant gun Energy-saving and warm-up functions (PowerSave / WarmUp) Connection values: Electrical connection: approx. 27 kVA, connection M40 Compressed air: min. 5.5 bar, approx. 510 Nl/min Coolant connection DN40 Dimensions / Installation: Footprint approx. 4,543 × 4,441 mm (L × W, incl. peripherals) Height approx. 2,405 mm (max. 3,042 mm with extraction system)

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 550 mm, controller manufacturer: Siemens, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Number of axes: 4 Travel in X-axis: 2,000 mm Travel in Y-axis: 500 mm Travel in Z-axis: 550 mm Psdpszuw Aisfx Abpora C-axis rotation: 360° Control system: Siemens CNC Table length: 2,600 mm Table width: 550 mm Tool holder: ISO 40 Main spindle power: 22 kW Spindle speed max.: 12,000 rpm Positioning accuracy: 0.01 mm Travel speed: 667 mm/s MACHINE DETAILS Control system: Siemens CNC Connected power: 24 kW Dimensions & Weight Dimensions (L x W x H): 7,500 x 3,700 x 2,500 mm Empty weight: 9,600 kg Transport packages: 2 EQUIPMENT Documentation CE marking

Condition: reconditioned (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 550 mm, travel distance Y-axis: 320 mm, travel distance Z-axis: 420 mm, rapid traverse X-axis: 75 m/min, rapid traverse Y-axis: 75 m/min, rapid traverse Z-axis: 75 m/min, torque: 90 Nm, controller manufacturer: FANUC, controller model: series 31i-B5, rotational speed (max.): 24,000 rpm, tool length: 200 mm, tool diameter: 60 mm, tool weight: 4,000 g, input voltage: 400 V, type of input current: three-phase, number of tool turrets: 1, number of tool stations in tool turret 1: 12, number of driven tool stations in tool turret 1: 12, Equipment: chip conveyor, CNC Machining Center CHIRON FZ12 MT TECHNICAL CHARACTERISTICS: Year of manufacturing: 2013 CNC control: FANUC series 31i-B5 Stroke X axis: 550 [mm] Stroke Y axis: 320 [mm] Stroke Z axis: 420 [mm] Traversing feeds X, Y and Z axes: 75000 [mm/min] X/Y/Z axis acceleration: 10/12/15 [m/s] Max. bar diameter in turning spindle: 32 [mm] Main spindle max. speed: 8000 [rpm] Max. turning spindle torque: 90 [Nm] Prsdpfx Abozqbdiopoa Max. counter spindle speed: 6500 [rpm] Counter spindle torque: 14.3 [Nm] Tool changer magazin number of stations: 24 Max. tool lenght: 200 [mm] Max. weight of single tool: 4 [Kg] Max. tool diameter: 60 [mm] Number of tool stations: 12 Number of tool stations driven: 12 Max. speed driven tools: 5000 [rpm] Milling head spindle attachment: HSK-A 50 Stroke B axis: -10 [°] / +100 Max. milling spindle speed: 24000 [rpm] Max. milling spindle power: 36 [kW] Max. milling spindle torque: 29 [Nm] Tool change time: 0.9 [sec] Chip to chip time: 2.4 [sec] Rated current: 125 [A] Total power required: 85 [kVA] Supply voltage: 400 [V] INCLUDED EQUIPMENT: 1 × High Speed Plus package 1 × LNS QUICK LOAD SERVO 80 S2 bar feeder 1 × KNOLL KF 150/500 paper band filtration unit 1 × 40 bar high-pressure coolant system 1 × Oil cooling unit 1 × KNOLL 600 K-1/200 chip conveyor 1 × RENISHAW workpiece probe 1 × RENISHAW TS27R tool setter 1 × ELBARON oil mist extraction unit Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine similar to Mikron, Hermle, DMG MORI, Mazak, Hedelius, AXA, Chiron, Matec, Reiden, Lagun, Haas and Alzmetall, as well as CNC milling, drilling and tapping machines, and CNC grinding machines.

Condition: used, Year of construction: 2017, operating hours: 18,074 h, machine/vehicle number: 302-58, Travel ranges (X/Y/Z): 550/300/425 mm, spindle speed max.: 10,500 rpm, tool holder SK 40, machine weight: 6,500 kg, control system SIEMENS Sinumerik 840 D, chip conveyor KNOLL 600 K-1/320, belt filter system BÜRENER MASCHINENFABRIK KA M. TPF 150/510S, year of manufacture: 2017, rotary table. Drilling emulsion/lubricants must be extracted and disposed of by the customer in a professional manner. Prodpezqy Utsfx Abpsa

Condition: used, Year of construction: 2014, x-travel 2000 mm y-travel 630 mm z-travel 550 mm Control Siemens 840 D total power requirement 7,5 - 22,5 kW weight of the machine ca. 10,5 t Predpfx Abeyan Rcopoa Maximum table load:1,000 kg / m table length Movement range: X-axis:2000 mm Y-axis:630 mm Z-axis:550 mm Speed range up to:12,000 min-1 Maximum speed range:140 Nm Drilling power:average 42 mm (with insert drill) Milling power:600 cm³/min Tool places:24 Tool shaft:HSK A 63 DIN 69893 Tool average:max. 75 mm Tool average with: free neighbouring places:max. 160 mm Tool length:max. 320 mm Tool weight:max. 8 kg (max. magazine load 100 kg Tool change time:approx. 1.5 s (depending on control

Condition: used, Year of construction: 2000, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 310 mm, controller manufacturer: Fanuc, spindle nose: HSK 32, number of slots in tool magazine: 12, input voltage: 400 V, type of input current: three-phase, Equipment: documentation/manual, We are offering this used CHIRON FZ 08 S vertical machining center, manufactured in the year 2000. The machine was used for single-shift operation. As it is our only Fanuc machine, we are now selling it. The machine has a memory expansion and was refurbished by Chiron in 2013. Unfortunately, no documents about this are available anymore after more than 10 years. Pedpfx Aezqfynobpjra If you have any questions or require further information, please feel free to send us a message or call us.

Condition: used, Year of construction: 2015, CNC machining center Manufacturer: Chiron Type: FZ 12 W Magnum Year of manufacture: 2015 CNC control: Siemens 840D solution line Travel distances: X/Y/Z = 550 x 400 x 360 mm Spindle: 15,000 rpm Predpfxozfppcj Abpea Tool interface: HSK63 Internal coolant supply Rotary table Integrated workpiece changer 32-position tool changer Glass scales Chip conveyor Laser control for breakage monitoring 3826

Condition: ready for operation (used), Year of construction: 2003, Make: CHIRON Type of machine: MILL 800 Year of manufacture: 2003 Control system: Siemens SINUMERIK 840D Tool holder: SK 40 x-travel: 800 mm y-travel: 500 mm z-travel: 550 mm Speed range: 12.000 U/min Table dimensions: 1.400 × 550 mm Prsdjzvyv Ijpfx Abpja Number of tools in the magazine: 24 Plätze Internal coolant supply: 40 Bar

Condition: new, Chiron 1122242 / 562 006 HSK-A63 clamping gripper SN: 9F08 with 5721028100 / 95281 tool arm 1088539/00 CW49/15, unused, 100% functional, scope of delivery as per photos. Pedpfx Abezpcv Rjpora

Condition: used, Year of construction: 2002, functionality: fully functional, machine/vehicle number: 213-65, Verfahrweg X-Achse: 300 mm Verfahrweg Y-Achse: 250 mm Verfahrweg Z-Achse: 250 mm Werkstückgewicht (max.):1 kg Anzahl der Werkzeugplätze：12 Pos Steuerungshersteller:Fanuc Predjywmziepfx Abpsa Steuerungsmodell: 21m 3x / 2x 21iM Kühlmittelzufuhr:1 bar Anzahl der Spindeln:1 Eilgang Z-Achse: 60 m/min Eilgang X-Achse: 40 m/min Eilgang Y-Achse: 40 m/min Drehzahl (max.): 10.000 U/min Werkstückdurchmesser (max.): 63 mm 4.Achse Peiseler AWU P100 die Maschinen wurden 2016 durch Chiron CMS überholt Ausstattung: Dokumentation/Handbuch, Drehzahl stufenlos einstellbar Die Maschine befindet sich unserer Einschätzung nach in einem guten gebrauchten Zustand und kann nach Terminvereinbarung unter Strom besichtigt werden.

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: 281-06, Technical Specifications: # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis Description: 3 linear axes (X, Y, Z) + 1 rotary axis (rotary table A) and 2 rotary axes (B, indexer head) with direct angular measuring system, maximum 50 rpm, accuracy +/- 5 seconds # A axis swivel: +/-110˚ # Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg # Rapid traverse rate: X/Y/Z 40/40/40 m/min Prsdpfsxxivcjx Abpja # Distance between divider heads B1/B2: 250 mm # Spindle speed: 1–10,000 rpm # Spindle taper: DIN69893-HSK-A63 (with internal coolant) # Automatic tool changer: 1x48 tools / chip-to-chip time approx. 2.5 sec # Max tool diameter: Ø82 mm / max. length 250 mm / 5 kg Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 45 kVA / 80A Dimensions: # Installation area: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment includes: # CNC control: Siemens 840D Powerline # Chip conveyor: Spring Knoll # Oil cooling system # High-pressure oil filtration system, max. 80 bar: Knoll HL 450/1200 # Shaft, guideways, and electrical cabinet cooling system # 2 oil lubrication systems # Oil mist extraction/recovery: LTA AC3002 # Fire protection: Kraft & Bauer # Presence detection: with low pressure air sensors (part present) # In-process control: Marposs T25 # Tool breakage monitoring: Blum Novotech # Tool presence detection system in spindle # Documentation: incomplete Machine condition: NOT OPERATIONAL # Cover for tool magazine # Tool magazine presence sensor (BERU)

Condition: used, Year of construction: 2021, functionality: fully functional, travel distance X-axis: 270 mm, travel distance Y-axis: 310 mm, travel distance Z-axis: 450 mm, controller manufacturer: Siemens, controller model: 840DSL, spindle speed (max.): 36,000 rpm, Spindle Speed: 36,000 rpm Power: 2.3 kW Tool interface: HSK-E Tool changer: 24 stations Working area Travel in X: 270 mm Travel in Y: 310 mm Travel in Z: 450 mm Rapid traverse (X/Y/Z): 75 m/min C-axis Type: NC rotary table Diameter of rotary table: 245 mm Robot Type: Variocell UNO Equipment 5-axis milling package Lasercontrol 40NT Measuring probe Automatic loading and unloading system Variocell UNO Prodszgckispfx Abpea

Condition: ready for operation (used), Year of construction: 2012, travel distance X-axis: 550 mm, travel distance Y-axis: 320 mm, travel distance Z-axis: 360 mm, table load: 500 kg, spindle speed (max.): 12,000 rpm, tool weight: 5,000 g, number of axes: 3, This 3-axis CHIRON FZ 12 KW vertical machining center was manufactured in 2012. It features a high-speed spindle with a maximum speed of 12,000 rpm and a rapid traverse speed of up to 60 m/min on the Z-axis. The machine includes a 24-slot automatic tool changer and can handle a table load of up to 500 kg. Ideal for precision machining tasks. Contact us for more information about this machine. Two Chiron units in combination with two x Fanuc M - 20iA (2011) Machine Benefits Pjdpfxszvyaae Abpjra Technical Machine Benefits • Controlled axes: 6 axes • Reach: 704 mm • Acceleration/deceleration: 0 to 12000 min-1 in 0. 6 seconds • Clamping surface: 820 x 440 mm² • Drilling capacity in st 60: Ø 16 mm • Tapping: m 16 • Milling capacity in st 60: 80 cm³/min • Acceleration: x & y axis 0. 7 g, z axis 1. 0 g Extra Information Movement Axis Movement Range and Speed: J1: 340°/360° (option) at 350°/s J2: 200° at 350°/s J3: 388° at 400°/s J4: 380° at 450°/s J5: 240° at 450°/s J6: 720° at 720°/s Allowable Load Moment: J4 & J5: 11.9 Nm J6: 6.7 Nm Repeatability: +/- 0.02 mm Maximum Speed J1: 195°/s J2: 175°/s J3: 180°/s J4 & J5: 400°/s J6: 600°/s Allowable Load Moment J4 & J5: 7.7 Nm J6: 9.8 Nm Tools Automatic Tool Changer: Tool Pockets: 24 Tool Change Time: approx. 0.9 s Chip-to-Chip Time: approx. 2.4 s The workpieces are supplied via an automated feeding system and sequentially loaded into the Chiron machining centres by two Fanuc industrial robots. Depending on the process specifications, these are either palletised automatically or further processed in a downstream step, for example by riveting. The entire system operates fully automatically.

Condition: repair required (used), Year of construction: 1991, operating hours: 40,000 h, functionality: limited functionality, machine/vehicle number: 109-43, travel distance X-axis: 550 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 425 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, feed rate X-axis: 4,000 m/min, feed rate Y-axis: 4,000 m/min, feed rate Z-axis: 4,000 m/min, nominal power (apparent): 13 kVA, torque: 35 Nm, controller manufacturer: Fanuc OMB, controller model: 9030556, workpiece length (max.): 220 mm, workpiece diameter (max.): 65 mm, total height: 2,600 mm, total length: 2,800 mm, total width: 1,800 mm, table width: 370 mm, table height: 900 mm, table length: 950 mm, table load: 500 kg, overall weight: 2,500 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 6,000 rpm, distance table center to spindle nose: 615 mm, number of slots in tool magazine: 12, input voltage: 380 V, Equipment: chip conveyor, rotational speed infinitely variable, Chiron Fz 12 S, year of manufacture 1991. Additional indexing device. Currently with a measurement system error on the B-axis. The machine can be inspected at any time during regular opening hours. Podpey R Dqhefx Abpsra

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, workpiece weight (max.): 1 kg, number of slots in tool magazine: 12, controller manufacturer: Fanuc, controller model: FANUC 21-iM, coolant supply: 1 bar, number of spindles: 1, rapid traverse Z-axis: 60 m/min, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rotational speed (max.): 10,000 rpm, workpiece diameter (max.): 63 mm, Equipment: documentation/manual, rotational speed infinitely variable, 4 units of CHIRON FZ08S with 4th axis Peiseler AWU P100 1 unit of CHIRON FZ08S 3-axis 3 machines were overhauled by Chiron CMS in 2016, and 4 machines in 2018. Unit price approximately €30,000. Prodpfevx Ugwex Abpoa

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 191-88, Technical specifications: # Working area: X 550 mm; Y 400 mm; Z 360 mm # Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis A and 2 rotary axes B with indexing head, direct angular measuring system, max. speed 50 rpm, accuracy +/- 5" # A-axis swivel: +/-110˚ # Max. clamping/part size: Ø247 x 830 mm; max. weight 360 kg # Rapid traverse rate: X/Y/Z 40/40/40 m/min # Distance between dividing heads B1/B2: 250 mm # Spindle speed: 1-10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 1x48 tools, tool-to-tool average 2.5 sec # Max. tool diameter: Ø82 mm / max. tool length: 250 mm / max. tool weight: 5 kg Electrical system: # Voltage: 3x400V/50Hz # Installed power: approx. 45 kVA / 80A Dimensions: # Installation footprint: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Pjdpfx Abexw Uplopsra Equipment includes: # CNC control: Siemens 840D Power Line # Chip conveyor: Spring Knoll # Oil cooling unit # Oil filtration system up to 80 bar: Knoll HL 450/1200 # Shaft, linear guide and electrical cabinet cooling system # 2 oil lubrication systems # Oil mist extraction/recovery unit: LTA AC3002 # Fire suppression: Kraft & Bauer # Part presence check with low-pressure air sensors # In-process control: Marposs T25 # Tool support monitoring system at spindle # Documentation: incomplete Machine condition: NOT OPERATIONAL # Operator protection screen damaged – operator panel functional # Tool magazine chain # Ballbar X # Ballbar Y # Pullbar spindle # Axis drive power supply X # Axis drive power supply Y # Main drive power supply # Complete hydraulic unit defective
