Used Gantry Type Milling Machine for sale (85,698)

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,300 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 6,000 rpm, spindle speed (min.): 36 rpm, table length: 4,000 mm, table width: 1,500 mm, tank capacity: 500 l, SHW PowerSpeed 5 Travel Ranges • X-axis (bed): 4,000 mm • Y-axis (vertical): 2,100 mm • Z-axis (spindle horizontal): 1,300 mm Control System • CNC control: Heidenhain iTNC 530 Feed Speed • X, Y, and Z axes: 2 - 30,000 mm/min • Acceleration: 3.5 m/s² Universal Milling Head in Orthogonal Design • Milling head swivel range (mounting): 360 x 1 degree • Milling head swivel range: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 36 – 4,000 rpm o Short-term: 36 – 6,000 rpm Automatic Tool Changer • Tool magazine for 48 tools Clamping Plate • Clamping surface: 4,000 x 1,500 mm Chip Conveyor • Fork length: 4,000 mm Coolant System • Tank capacity: 500 l Splash and Chip Protection • One-sided, with 2 manually sliding doors About the Company MBM MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is on tool milling machines. Our services include, among others, spare parts delivery, on-site customer service, machine overhauls, and control system modernization. Bcedsw I Rz Hjpfx Afhsu Services: - Used machines - Spare parts - Customer service - Machine servicing - Machine overhauls - CNC control modernization ----- _____ Used machine – used milling machine – used traveling column milling machine – orthogonal milling head – metalworking – tool milling machine – milling head – SHW machine – SHW spare parts – used milling machine – used cnc milling machine – used boring and milling machine – used metal milling machine – used metal mill – used metal machining center – used cnc mill – cnc milling machines – milling machinery – large part machining – cnc large part machining – milling – shw – PS5 – PS 5 – Powerspeed – SHW PSZ 5 – SHW Powerspeed – SHW Powerspeed 5 – PSZ 5 – Heidenhain – MBM milling machine – MBM machine – column-type milling machine

Condition: new, Year of construction: 2025, machine/vehicle number: 2021, 3D AC SERVO SkyCNC WK Series machine - 1250 mm x 1250 mm x 220 mm High precision - milling and drilling with extremely high speed and quality. As CNC Milling machines manufacturer whistler-technology with SkyCNC CNC milling and engraving your partner. Our PFEIFER technology SkyCNC WK series milling machines with high-precision ball screw drive on all axes provide highest precision, accuracy and speed - with a pleasant value for money.   By building a high solid steel base frame ca. 2,2 t high static rigidity of the machine is achieved, so that the processing of solid woods and various metals will be trouble. The sophisticated location and distribution of 35mm linear rails and guides and the associated massive portal with its vibration damping characteristics distinguish our CNC milling machines made especially. The superior programmable CNC control allows flexible intervention via touchscreen in all production conditions and is standard in our PFEIFER technology SkyCNC WK series milling machines. This CNC control, you can create your milling data or CAD / CAM import data and then can be processed independently of a computer.   The tool changer (up to 16 tools), the vacuum table made of solid aluminum, various tool / workpiece cooling solutions, the automatic lubricating device for all axes and other refined details, complete this milling system.   With the PFEIFER technology SkyCNC WK series you get a reliable and efficient bulk - Portal - milling system for your applications.   - Drive system: high-precision ballscrew on X and Y axis and Z axis of high-precision manufacturing - Operating speed: 15 m / min - Xyz Workspace / traverse: 1250 x 1250 x 220 mm - Table size (vacuum table with milled vacuum tracks): 1220 x 1220 x 30 mm - Xyz Repeatability: 0.03mm - Xyz accuracy: 0.01 mm - Compatible with DIN ISO CAM etc. - Format: ISO standard G-code, FANUC compatible - Additional: Spindle motor / tool changer / Vacuum table according to customer requirements Bodj Sd U Djpfx Afhocu - Warranty: 2 years - Spindle Power: from 5.5kW (other spindle power optional) - Spindle speed: 6000-24000 U / min (depending on requirements) - Spindle taper: BT 30 4ea ER20 (other recordings optional) - Drive: AC SERVO motors on all axes - Tool changer: 6 magazine slots - Power supply: AC400 V ± 10% 50Hz - Power 10-15 kW (depending on equipment) - Dimensions: 2670 (L) X 1735 (W) x 1790 (H) mm - Weight: 2700 kg

Condition: new, Year of construction: 2025, machine/vehicle number: 2021, 3D AC SERVO SkyCNC WK Series Milling Machine - 2050mm x 3050mm x 220mm High precision - milling and drilling with extremely high speed and quality. As a CNC milling machine manufacturer, pfeifer-technology is your partner with skycnc CNC milling machines and engraving machines. Our PFEIFER technology skycnc WK series milling machines with high-precision ball-spindle drive on all axes offer you the highest precision, accuracy and speed - and all this with a pleasant price-performance ratio. Due to the structure with a high solid steel base frame approx. 4 t, a high static rigidity of the machine is achieved, so that the processing of solid wood and different metals is possible without any problems. The sophisticated position and distribution of the 35mm linear rails and guides and the associated massive portal with its vibration-damping properties characterize our CNC milling machines in particular. All machine components and the servo drive units used are the result of years of development and experience. The powerful servo motors are highly effective and backlash-free with the ball screw from German quality production and thus offer a feedback-free drive to meet even the highest demands. The superior, freely programmable CNC control enables flexible intervention by means of a touchscreen under all production conditions and is standard on our PFEIFER technology skycnc WK series milling machines. With this CNC control you can create your milling data or import CAD/CAM data and then process them independently of a computer. The tool changer (up to 16 tools), the all-aluminum vacuum table, various tool/workpiece cooling solutions, the automatic lubrication system for all axes and other ingenious details round off this milling system. With the PFEIFER technology skycnc WK series you get a reliable and powerful large portal milling system for your applications. On request, we can supply the corresponding CAD / CAM ARTCAM SKYCNC control software: 2.5 / 3D PFEIFER SKYCNC milling & engraving software in German for Windows® operating systems or ArtCAM Pro / ArtCAM Insignia software in German / Russian etc. on request. - Drive system: high-precision ball screw on X and Y axis and Z axis from high-precision German production - Working speed: 15 m/min - xyz working area/travel area: 2050 x 3050 x 220 mm - Table size (vacuum table with milled vacuum tracks): 2000 x 3000 x 30 mm - xyz repeat accuracy: 0.02mm - XYZ Accuracy: 0.01mm - Compatible with Software Type3, ARTCAM, MASTERCAM, FeatureCam, etc. - Formats: ISO standard G-code, FANUC compatible Bedpfxjbnpgxo Afhscu - Addition: Spindle motor / Tool changer / Vacuum table according to customer requirements - Warranty: 1 year - Spindle power: from 5.5kW (other spindle powers optional) - Spindle speed: 6000 - 24000 rpm (depending on requirements) - Spindle mount: BT30 / ER20 (other mounts optional) - Drive: AC SERVO motors on all axes - Tool changer: 4-8 magazine places - PDSP control RTU / MTU (Remote Terminal Unit) - Power input: AC400V±10% 50Hz - Power consumption 10-15 kW (depending on equipment) - Dimensions: 4500 (L) X 3100 (W) x 2500 (H) mm - Weight: 4000kg

Condition: new, functionality: fully functional, Year of construction: 2025, laser power: 30,000 W, travel distance X-axis: 3,050 mm, travel distance Y-axis: 13,050 mm, travel distance Z-axis: 450 mm, positioning accuracy: 0.03 mm, repeat accuracy: 0.02 mm, workpiece weight (max.): 20,000 kg, input frequency: 50 Hz, total length: 16,800 mm, total width: 2,200 mm, total height: 5,120 mm, warranty duration: 24 months, working range: 13,000 mm, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, GS-CL Series, Glorystar Single Table Gantry Type Metal Laser Cutting Machine Laser Power: 12000-80000W Fits in a standard 40HQ container The GS-L Series is a high-power metal laser cutting machine with a gantry-type segmented bed design. It can be freely customized to meet processing format requirements according to customer needs. Bedpsvmwn Hofx Afhjcu Key Features: ● Super Large Processing Format with a gantry-style segmented design. ● The GS-L Series has the largest Z-axis travel and height in its class in the industry. Supports extreme thickness cutting for plates over 20mm. Capable of cutting ultra-thick plates up to 70mm. ● High Negative Pressure Automatic Partition Dust Removal ● Equipped with a high-air-volume fan for effective dust removal. Technical parameters: Working area (mm): 13000mm*3000mm（bevel cut: 12500mm*2500mm） X axis travel distance (mm): 3050mm Y axis travel distance (mm): 13050mm Z axis travel distance (mm): 450mm X/Y axis positioning accuracy: ≤0.03mm/m X/Y axis repeat positioning accuracy: ≤±0.02mm Max. synthetic positioning speed: 110m/min Max. acceleration: 1.2G Min. setting unit: 0.001mm Floor size (mm): 18500mm*6500mm Main body dimension (mm): 16800mm*5120mm*2200mm Worktable max. weight capacity (T): 20 tons (even load bearing)

Condition: good (used), Year of construction: 1997, Manufacturer: Line Type: Seramill 240 Control: NUM 750 Travel X: 6000 mm Travel Y: 2500 mm Travel Z: 950 mm Column spacing: 2400 mm Table: 6000 x 2100 mm Automatic milling head: 2.5° Bcjdpfoyf A H Nex Afhou Spindle speed: 3200 rpm Feed rate: 10 m/min Machine weight: approx. 35 tons

Condition: excellent (used), Year of construction: 2000, travel distance X-axis: 5,500 mm, travel distance Y-axis: 2,900 mm, travel distance Z-axis: 1,000 mm, table length: 5,000 mm, table width: 2,000 mm, CNC Gantry Milling Machine Forest Line Seramill 240T – Robust & Precise For sale: Forest Line Seramill 240T CNC gantry milling machine, year 2000 – used, in excellent condition. Perfect for machining large workpieces with high precision. Key Features: Robust gantry design for maximum stability Accurate Siemens 840D control Large working area: 5,000 × 2,000 mm Travel: X 5,500 mm | Y 2,900 mm | Z 1,000 mm | A ±135° | C ±180° ISO 50 spindle, max. 6,000 rpm Ideal for series production and individual parts Perfect for carpenters, furniture manufacturers, and production workshops that want to machine large parts precisely. Bcodpfxjyfpkbo Afhju Available immediately! Contact us for details, photos, or a viewing.

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: 9101, travel distance Y-axis: 4,600 mm, travel distance Z-axis: 1,600 mm, rotational speed (max.): 6,000 rpm, Equipment: rotational speed infinitely variable, Machine configuration: • PowerPortal4000 • 45° diagonal milling head (C 0.01° / A 0.01°) • Camera system integrated in SHW diagonal milling head • 4-point Hirth-type milling head interface Bsdpfsygtnasx Afhocu • Heidenhain TNC 7 • HR 550 FS handwheel • Heidenhain optimization for 5-axis machining • X = freely selectable, Y = 4,600 mm, Z = 1,600 mm • ToolCenter with 90 tools • Coolant system 2,500 l • Coolant pump 70 bar / 30 l/min • Coolant/air switching • Wash gun in the working area • Main drive 75 kW up to 6,000 rpm • Tool holder SK 50 BIG-PLUS • Panelling and grating • Double chip conveyor • SHW-UniScan • Sealing air • Operating mode 3 • Hexagon wireless probe • LED workspace lighting • Second camera in the working area

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 5220511, travel distance X-axis: 2,600 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 4,000 rpm, workpiece weight (max.): 8,000 kg, TECHNICAL DETAILS Travel X-axis: 2,600 mm Travel Y-axis: 1,000 mm Travel Z-axis: 1,000 mm Max. workpiece weight: 8,000 kg Table size: 3,600 x 900 mm Number of T-slots: 6 Bcsdpfx Afoygxgzshju T-slot width: 22 mm T-slot spacing: 125 mm Spindle taper: ISO 50 DIN 69871 Spindle speed: 4,000 rpm (2 ranges: 0 - 1,000 rpm) Feed rate: 10 - 5,000 mm/min Rapid traverse: 10,000 / 10,000 / 10,000 mm/min MACHINE DETAILS Control: HEIDENHAIN TNC 426 Dimensions & Weight Space requirement: approx. 9.82 x 5.1 x 3.16 m Machine weight: approx. 21.5 t Motor Spindle drive motor: 29 kW Feed drive motor (Y-axis): 20 Nm Feed drive motor (X and Z-axis): 27 Nm Hydraulic motor: 2.2 kW Coolant pump motor: 0.50 kW Lubrication pump motor: 0.09 kW EQUIPMENT Tool changer Both head joints have 2.5°

Condition: used, Year of construction: 2020, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, RepairFIT by Dornhöfer The Difference. Including installation & commissioning! TECHNICAL MAIN DATA Bodpfx Afjygiwqehscu Year of manufacture: 2020 Capacities / Travel distances: Longitudinal (X): 3,000 mm Vertical (Y): 1,500 mm Transverse (Z): 1,500 mm Clamping area NC rotary table: Indexing plate: 2,400 x 1,900 mm Max. load capacity (with centrical load): 10,000 kg Positioning accuracy arc/sec ±2.5” Max. swing diameter: approx. 2,900 mm Paintwork: RAL 7024 graphite grey RAL 7038 agate grey Tool holder: DIN 69871 AD (ISO50) Big Plus Pull stud: DIN 69872 Type A Main spindle drive: Motor / manufacturer main spindle drive Heidenhain Max. drive power: 32 kW from 376 rpm Max. torque: 1,085 Nm (constant up to 376 rpm) Speed control/gearbox: 3-stage (oil-cooled), automatic gear shifting Spindle speeds: 6,000 rpm: low range rpm 0–738 medium range rpm 739–1,842 high range rpm 1,843–6,000 Axis drive / axis feed: Axis motors: Manufacturer Heidenhain (digital drives) Rapid traverse max.: X, Y, and Z axis 25,000 mm/min Max. working feed: X, Y, and Z axis 15,000 mm/min Max. mean acceleration: 2 m/s² Max. feed force: X, Y, and Z axis 26,000 N Axis drive systems: X-axis (longitudinal) preloaded ball screw Ø 63 x 40 Z-axis (vertical) preloaded ball screw Ø 63 x 20 Y-axis (transverse) preloaded ball screw Ø 50 x 20 Guideway systems: X-axis (longitudinal) 6 pcs Type: INA RUE 55 EL Z-axis (vertical) 4 pcs Type: INA RUE 65 EL Y-axis (transverse) 8 pcs Type: INE RUE 55 E-HL plus additional damping unit Clamping table / Table surface: T-slot size 10x: 22 H12 mm Reference slot, center 1x: 22 H8 mm T-slot spacing: 150 mm (pitch of outer slots 1,800 mm) Weight: Weight RT3000 approx. 32,000 kg Connected load: approx. 53 KVA Heidenhain TNC 640HSCI Automatic tool changer with 80 stations Automatic oil-cooled milling head 2.5° x 1° 2 chip conveyors Coolant system with increased pressure to 37 bar ICS Special operating mode 4 RepairFIT is our proven package for a profitable entry into our product lines. Machines available in this line are sourced through a strict selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, any found defects and faults are professionally repaired by our expert service team.

Condition: used, Year of construction: 2014, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 20 rpm, RepairFIT by Dornhöfer The Difference. Installation & Commissioning Included! TECHNICAL MAIN DATA Year of manufacture: 2014 Travel/Capacity: Longitudinal (X): mm 3,000 Transverse (Y): mm 1,200 Vertical (Z): mm 1,500 Clamping table/Clamping surface: Length: mm 3,200 Width: mm 1,000 Number of T-slots on table surface: pcs. 7 T-slot size: mm 22H12 Reference slot: mm 22H7 Distance between slots: mm 140 Maximum transport load: kg 11,000 Paint: graphite grey RAL 7024 and agate grey RAL 7038 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Maximum drive power, from 198 rpm: kW 30 Spindle speed range: Spindle speed: rpm 20-6,000 Maximum torque: Nm 935 Speed control: 3-stage (oil-cooled) with automatic changeover Feed rates: X, Y and Z axes mm/min: 2 – 15,000 Maximum rapid traverse speed: X, Y and Z axes mm/min: 25,000 Maximum feed force: X, Y and Z axes: N 22,000 Bcedpfx Ajygipaofhsu Space requirements: Length approx. BT3200: mm 8,100 (without cross conveyor +1,280 mm) Height approx. (at Z = 1,500 mm): mm 3,800 Width approx. (at Y = 1,200 mm): mm 5,000 (with spacer 4,500 mm) Weight: approx. kg 20,200 Connected load: approx. KVA 52 HEIDENHAIN iTNC 530 HSCI Automatic MTE universal milling head Diagonal 2.5° x 2.5° Automatic tool changer with 40 positions 2 chip conveyors + cross conveyor Coolant system with 20 bar & through-spindle coolant RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are sourced through a strict selection process and undergo thorough inspection (Deep-Dive Check). After intensive cleaning, any identified obvious defects and faults are professionally repaired by our qualified service team.

Condition: good (used), Year of construction: 2009, functionality: fully functional, Technical details x-travel 4000 mm y-travel 1350 mm z-travel (Vert.) 1600 mm Control Heidenhain iTNC 530 table surface area 4200 x 1150 mm table load 13 t tool taper ISO 50 spindle turning speed - stepless 0 - 3000 U/min transmission ratio 2 spindle motor 28/38 kW feed range 5000 mm/min rapid traverse (X/Y) 12 m/min rapid traverse (Z) 10 m/min Bcedpfxoyf Evto Afhsu weight of the machine ca. 37 t dimensions of the machine ca. 12,9 x 6,53 x 3,79 m

Condition: good (used), Year of construction: 2001, CNC bed type milling machine Fabr.IBERIMEX-MVR Type: UH-1250 BJ. 2001 Bjdpfsd Eransx Afhscu Control HEIDENHAIN TNC124 Procedures: X1250mm Y500mm 460 mm Clamping table: 360mmX1800mm Spindle retainer: ISO50 Machine with full enclosure. Machine card see more data. Machine in good condition.

Year of construction: 2013, condition: ready for operation (used), This Okuma MCR-A5C30x65 gantry milling machine was manufactured in 2013. It features a robust 100 mm spindle, capable of speeds up to 4000 min⁻¹, and accommodates a maximum workpiece size of 2540 mm by 5540 mm. The machine supports a hefty 30,000 kg on its 2500 × 6300 mm table. Ideal for heavy-duty milling with a rapid feed rate of 20,000 mm/min. Contact us for more information about this machine. Bedpfx Afex D S Ekehecu Application Types Milling

Condition: used, Year of construction: 1999, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,360 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 20 m/min, feed rate Z-axis: 20 m/min, spindle speed (max.): 15,000 rpm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, type of input current: three-phase, torque: 57 Nm, overall weight: 15,000 kg, Equipment: rotational speed infinitely variable, Initial commissioning: 1999 Control: Heidenhain TNC430 PA with portable hand control unit Working ranges X-axis approx. 3,000 mm Y-axis approx. 2,360 mm Bodpex Ifdkofx Afhjcu Z-axis approx. 1,000 mm A-axis ±110° C-axis ±300° Clamping table Length x Width x Height: approx. 4,500 x 2,000 x 400 mm Longitudinal T-slots 18H12 T-slot spacing 250 mm (Shown zero-point clamping plates and additional clamping devices are not included in the scope of delivery!) Milling head Spindle power: 18 kW Spindle speed: max. 15,000 rpm Torque: 57 Nm Tool holder: HSK 63 F Tool clamping: hydraulic Linear axis drives Feed rate X, Y, Z axes: approx. 20 m/min Connection data Power requirement: approx. 20 kW Frequency: 50 Hz Voltage: 400 V Main fuse: approx. 63 A Dimensions, weights Machine footprint without control cabinet: approx. 6,000 x 3,500 mm Required height: approx. 4,050 mm Total weight: approx. 15,000 kg Additional equipment - 12-position tool changer - External minimum quantity lubrication - TT140 touch probe Condition of the machine Fully operational, machine is supplied without enclosure and must be enclosed by the purchaser in accordance with CE regulations.

Condition: used, Year of construction: 1997, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,360 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 20 m/min, feed rate Z-axis: 20 m/min, spindle speed (max.): 15,000 rpm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, type of input current: three-phase, rotational speed (min.): 1,500 rpm, rotational speed (max.): 9,000 rpm, overall weight: 15,000 kg, Equipment: rotational speed infinitely variable, Initial commissioning: 1997 Control system: Heidenhain Working ranges X-axis approx. 3,000 mm Y-axis approx. 2,360 mm Z-axis approx. 1,000 mm A-axis ±90° Clamping table Length x width x height approx. 4,500 x 2,000 x 400 mm T-slots longitudinal 18H12 T-slot spacing 250 mm (The zero-point clamping plates shown and additional clamping devices are not included in the scope of delivery!) Milling head Spindle power: 12 kW Spindle speed: max. 9,000 rpm Tool holder: SK40 / ISO40 Linear axes drives Feed speed X, Y, Z axes: approx. 20 m/min Connection data Bodpfsx Iugujx Afhocu Power requirement: approx. 20 kW Frequency: 50 Hz Voltage: 400 V Main fuse: approx. 63 A Dimensions, weights Space required by machine (without control cabinet): approx. 5,600 x 3,500 mm Required height: approx. 4,050 mm Total weight: approx. 14,000 kg Condition of the machine Fully functional, the machine is delivered without enclosure and must be enclosed in a CE-compliant manner by the buyer. Note: The tool changer, vacuum table including pump, and extraction unit can be purchased at an additional cost. However, they are NOT included as standard equipment with the machine!

Condition: used, Year of construction: 2009, Year of manufacture: 08/2009 Commissioning: 03/2010 Bcodpjya U Uuefx Afhsu Control: Heidenhain iTNC 530 Technical Data: Tool holder: SK 50 Tool changer: 30 stations Spindle speed vertical, stepless: 4400 rpm Spindle speed horizontal, stepless: 3500 rpm Cutting capacity: 440 cm³/min Positioning accuracy: +/- 0.005/300 mm Repeatability of the automatic swivel head: +/- 3' Machine table (LxW): 4000 x 2000 mm Travel paths X/Y/Z: 4230 x 2150 x 775 mm Max. workpiece weight: 11,000 kg Rapid traverse X/Y/Z: 12 / 15 / 12 m/min Motor power: 22 kW Dimensions (LxWxH): 10,130 x 4,510 x 4,250 mm Machine weight: 27,000 kg Scope of delivery: - Chip conveyor - Tool cabinet - Approx. 80 tool holders including tools

Condition: used, Year of construction: 2009, x-travel 3.500 mm y-travel 1.200 mm Bcjdpfxjxwzf Ho Afhsu z-travel 1.250 mm Control HEIDENHAIN TNC-530 table-size 1.250 x 1.250 mm table weight 4.000 Kg feeds 12.000 mm/min Number of revolutions 4.000 rpm power capacity 24 kW taper ISO 50 DIN 69871 AD spindle head Automatisch 2,5 x 2,5 Grad handwheel Heidenhain HR-410 internal coolant system feed 20 bar total power requirement 46 kW weight of the machine ca. 18.000 kg dimensions of the machine ca. 7.800 x 4.850 x 3.530 mm -Integralverkleidung -Doppelter Längsspäneabsauger -Querspanabsaugung -500-l-Tank mit Magnetabscheider-Papierfilter

Condition: used, Year of construction: 2007, travel distance X-axis: 8,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,300 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 36 rpm, table width: 5,500 mm, table length: 2,600 mm, total height: 4,900 mm, total width: 16,200 mm, total length: 9,000 mm, overall weight: 55,100 kg, CNC Floor Type Bed Milling Machine CNC Control Heidenhain iTNC 530 Controlled NC Table 1600 x 1600 mm Table dimensions 5500 x 2600 mm Movement X-axis 8000 mm Movement Y-axis 2100 mm Movement Z-axis 1300 mm Movement W-axis 1000 mm C-axis-swivel of milling head body 360 ° A-axis-swivel of milling head 180° Spindle speed 36 - 6.000 R/min Bcedpfoyddk Tex Afhju Spindle motor 42 / 30 kW Spindle taper DIN 69871-SK 50 Tools in tool magazine 48 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2003, x-travel 4.000 mm y-travel 1.000 mm z-travel 1.500 mm control Heidenhain iTNC 530 spindle tunring speed 5.000 U/min tool taper SK 50 number of tool places 40 Pos. Number of working hours ca. 15.829 h In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: - Automatic swivel head with B-axis, infinitely variable - Internal coolant supply 20 bar - Air blower through spindle Bcsdpsxylqrefx Afhsu - Chip conveyor - Chip flushing Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice. Prior sale reserved.

Condition: used, Radial drilling machine with plate field WEBO type HRH 100 / 3000 Machine. No. 10009555/7 -- 1110185 -- 6046 Year of manufacture 1979 Drilling capacity Ø 100 mm in ST 60 at feed rate 0.5 mm/rev. Nominal throat depth 3000 mm Bcedpsfbt Hujfx Afhou Max. throat depth max. 3100 mm Spindle holder MK 6 Spindle speed 22.4 - 1600 rpm 36 steps Feed rate 0.05 - 2.5 mm/rev 18 steps Spindle - base plate distance 970 - 2335 mm Pinol stroke 325 mm Swivel range of the arm 360 movable on bed, bed length 7500 mm Clamping area panel field 8000 x 2100 mm - Electrical central clamping - Drilling unit can be moved lengthwise on the machine bed by electric motor - Panel field consisting of 2 clamping plates with 7x T-slot, (length 4000 x width 2100 x panel thickness 360 mm) Space requirement L x W x H 8000 x 4550 x 4300 mm Maximum height 4300 mm Transport height (bed with drilling machine) approx. 3150 mm Transport weight (bed with drilling machine) approx. 20 tons Transport dimensions of panel section L x W x H 4000 x 2100 x 900 mm (2 panels stacked on top of each other) Transport weight panel field approx. 14 ton. good condition

Condition: new, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, position of the milling head: Universal-Diagonal-Fräskopf, spindle speed (max.): 6,000 rpm, table width: 1,200 mm, table load: 6,000 kg, table length: 1,600 mm, workpiece weight (max.): 6,000 kg, torque: 1,178 Nm, power: 31 kW (42.15 HP), Equipment: rotational speed infinitely variable, BRAND NEW BED TYPE MILLING MACHINE WITH ROTARY TABLE Control and Motors: HEIDENHAIN TNC 640 digital path control HEIDENHAIN 19" TFT display HEIDENHAIN package (motors, measuring systems, and handwheel) ICS: Internal coolant supply, 36 bar Rotary Table: 1600 x 1200 mm – double motor drive system Additional Equipment: Chain-type tool changer with double gripper, 40 positions Bjdpfxjhy At Aj Afhscu Double hinged belt chip conveyor (longitudinal), one at the front and one at the rear Perimeter enclosure Accuracies: Positioning accuracy: 0.015 mm Repeatability: 0.008 mm Only inquiries from Germany will be answered.

Condition: used, Year of construction: 1999, x-travel 2000 mm y-travel 800 mm z-travel 850 mm control HEIDENHAIN TNC 360 total power requirement / kW weight of the machine ca. / t Bcedov H Ertjpfx Afheu required space / m

Condition: ready for operation (used), controller manufacturer: Heidenhain iTNC530, empty load weight: 1,70,000 kg, Zware portaalfreesmachine Type: FPM-50/200 - tussen kolommen: 3480 mm - met automatische indexeerfreeskop (elke 0,1° in beide vlakken) 27 kW / max. 6000 tpm / 660 Nm hogedrukkoeling via de spindel (17 bar) - 2 Heidenhain-operatorstations - gereedschapswisselaar met 120 posities - 2 spanentransportbanden - met koel- en filtereenheid en zelfreinigend systeem Bcodpfx Asycmnrsfheu Als u de linker- en rechterkant van een werkstuk wilt bewerken, is de maximale breedte 3200 mm. In de huidige configuratie staat de tafel op de grond. Maar als je de tafel lager zet, kun je er ook hogere werkstukken op kwijt. Passage beween uprights: 3480 mm Longitudinal travel X-axe: 20 000 mm Cross travel Y-axe: 3800 mm Travel (height) Z-axe: 1350 mm Dimensions Clamping space - table: 20 000 x 2500 mm Max height of workpiece: 1750 mm (adjustable - according to table position) Power on spindle: 27 kW - 660 Nm Admission in millingheadspindle (ISO): ISO 50 Max speedrange: 10 > 6000 rpm Cooling system: yes Toolchanger: yes Number of tools: 120 positions

Condition: used, x-axis / mm y-axis / mm z-axis / mm The boring mill is sold without clamping plates – the price refers exclusively to the boring mill. Technical data Horizontal milling and drilling machine with support sleeve Working range Vertical adjustment of the headstock from the clamping surface: 0 - 3000 mm Horizontal adjustment of the column: 7000 mm Maximum drilling depth with drill spindle alone: 1200 mm Maximum drilling depth with drill spindle and support sleeve together: 1300 mm Drill spindle diameter: 150 mm Milling spindle diameter: 240 mm Support sleeve diameter: 390 mm Support sleeve extension: 700 mm Drill spindle tool holder: ISO 50 Maximum workpiece weight: 70,000 kg When placed in 4 prisms: 95,000 kg Main drive Total speed range, adjustable from 2 - 795 rpm Series 1 2 - 50.4 rpm Series 2 50.4 - 126 rpm Series 3 126 - 314 rpm Series 4 314 - 795 rpm Maximum drive power at rated speed 17.5 80 kW Bodpfxjxdnraj Afhocu Quick adjustment speed of spindle box and column 1800 mm/min Rapid adjustment speed of drill spindle and support sleeve 1400 mm/min Fine adjustment speed of spindle box and column medium 75 mm/min Fine 3 mm/min Fine adjustment speed of drill spindle and support sleeve Medium 57.7 mm/min Fine 2.5 mm/min Feed of headstock and column for milling Row 1 3 - 75 mm/min Row 2 72 - 1800 mm/min Feed of drill spindle for drilling Row 1 0.19 - 4.7 mm/min Row 2 2.2 - 56 mm/min Row 3 56 - 1400 mm/min Special equipment Numerical length measuring device in horizontal and vertical directions Accuracy 0.01 mm Rotatable and movable clamping table, Collet & Engelhard, Offenbach Model Tdvmf 1.6 (for technical data, see ‘Clamping table’) Rotatable and movable clamping table from Scharmann, Rheydt Model DAV 1600 Rotatable and movable clamping table from Froriep, Rheydt Swivel crane for tool change, maximum load capacity 500 kg Special tools Carbide core drill bits for extracting core samples Universal facing and boring head from Wohlhaupter, Frickenhausen Model UPA7, with the following specifications: 1 division of the fine adjustment 0.01 mm in diameter 1 revolution of the fine adjustment 0.5 mm in diameter Facing and boring range 0 - 1250 mm Maximum slide adjustment 210 mm Automatic slide feed in mm/rev during facing 0.05 - 0.10 - 0.15 - 0.20 - 0.25 - 0.30 - 0.35 - 0.40 - 0.45 - 0.50 - 0.55 - Quick adjustment per revolution of the quick adjustment spindle 6 mm in diameter Largest diameter of the slide at zero position corresponds to the smallest drilling diameter of 323 mm Head height without shaft 260 mm

Condition: good (used), Year of construction: 1999, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,150 mm, total length: 6,000 mm, total width: 5,200 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 10 m/min, Control: Siemens 840 D Powerline Tool holder: HSK-A63 Max. rpm: 16,000 X-travel: 3,000 mm Y-travel: 2,500 mm Z-travel: 1,150 mm A-axis: +/- 100 mm C-axis: +/- 181.5 mm Table size: 3,000 mm x 2,500 mm Bcedpfx Afsyfm Ukjheu Option: External blowing air Kinematics: Fork head
