Used Vertical Milling Center for sale (25,421)

Condition: used, Year of construction: 1989, x-travel 650 mm y-travel 410 mm z-travel 450 mm travel x vor 1000 mm control mc4va Ibodpfx Aijx U A Rnjyeb

Condition: new, Year of construction: 2026, functionality: fully functional, turning height: 2,300 mm, workpiece weight (max.): 12,000 kg, turning diameter over cross slide: 2,650 mm, turning diameter: 2,700 mm, faceplate diameter: 2,000 mm, total height: 7,100 mm, total width: 5,500 mm, total length: 8,500 mm, rotary table diameter: 2,000 mm, rotational speed (max.): 250 rpm, rotational speed (min.): 1 rpm, spindle speed (min.): 5 rpm, spindle speed (max.): 2,500 rpm, table load: 12,000 kg, table diameter: 2,000 mm, warranty duration: 24 months, overall weight: 63,000 kg, faceplate torque: 43,000 Nm, repeat accuracy: 0.015 mm, REM SCR 27 1SF — CNC Vertical Turning & Milling/Drilling Center 🔴 MACHINE CURRENTLY UNDER ASSEMBLY — DELIVERY MAX 3 MONTHS 🔴 24-MONTH WARRANTY — LONGEST IN ITS CLASS 🔴 UNBEATABLE PRICE FOR EUROPEAN CNC QUALITY Iodpezb Ufvofx Aiysbb ━━━━━ MACHINE HIGHLIGHTS ━━━━━ ✓ Complete turning + milling + drilling in ONE setup ✓ 12-Station ATC — bi-directional, 30 sec tool change ✓ Live spindle ISO 50 — 5 to 2,500 RPM | 37 kW ✓ C-Axis for full contour milling ✓ FANUC 0i-TF PLUS CNC — global support ✓ Heidenhain absolute measuring system (X: LC 195F) ✓ CE certified, full enclosure 3,300mm height ✓ Heavy-duty Meehanite cast iron structure ━━━━━ TECHNICAL SPECIFICATIONS ━━━━━ • Max Machining Diameter: 2,650 mm | Swing: 2,700 mm • Max Machining Height: 2,300 mm • Table Diameter: 2,000 mm (8 T-slots + 4 clamping jaws) • Max Workpiece Weight: 12,000 kg • Table Speed (turning): 1–250 RPM • Main Motor: 100 kW FANUC servo | Torque: 43,000 Nm • Ram Cross Section: 250×250 mm • X/Z Rapid Feed: 10,000 mm/min | Feed: 0.02–6,000 mm/min • X/Z Thrust Force: 35,000 N • ATC: 12-station disc | Max tool Ø 300mm | L 400mm • Coolant: 2,000 L tank | External 10 bar | Through-spindle 40 bar • Chip Conveyor: SARIGÖL hinged, 500mm wide • Accuracy: ±0.020 mm/m | Repeatability: ±0.015 mm • Electrical: 400V/50Hz | 140 KVA | Fanuc 0i-TF PLUS • Weight: 63,000 kg | 8,500×5,500×7,100 mm ━━━━━ IDEAL APPLICATIONS ━━━━━ Large gear blanks | Ring gears | Wind energy hubs & rings Heavy castings & forgings | Oil & gas flanges Mining equipment components | Aerospace large parts ━━━━━ COMMERCIAL TERMS ━━━━━ Delivery: MAX 3 MONTHS from order Warranty: 24 MONTHS parts + labor Incoterms: EXW Bacău, Romania Payment: 50% advance + 50% before shipment Installation & commissioning: included Manufacturer: REM Bacău, Romania

Condition: used, Year of construction: 1995, x-travel 650 mm y-travel 410 mm z-travel 410 mm Control Mitsubishi Meldas 50 M max. turning speeds 6.000 min/-1 tool taper SK 40 Used, untested Additional information – Machine weight: approx. 4,200 kg Dimensions (L x W x H): approx. 2,400 x 2,400 x 2,500 mm Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to changes and errors in technical data and specifications, Ibedpfx Aozz S R Ueiyeb as well as prior sale!

Condition: good (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 550 mm, CNC control Sinumerik 828D 24-fold automatic tool changer chip conveyor coolant through spindle device measuring feeler Technische Daten / technical details: Verfahrweg X / X-Travel 1020 mm Verfahrweg Y / Y-Travel 520 mm Verfahrweg Z / Z-Travel 550 mm Tischgröße / table size 1100x500 mm Ibedpewu Tpnsfx Aiyob Drehzahlbereich / spindle speed 10000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 24 fach Antriebsleistung Spindel / drive capacity spindle 9/22 kW Gewicht der Maschine ca. / weight 5500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, CNC Vertical Machining Center FEHLMANN Type PICOMAX 60 CNC Control System: HEIDENHAIN TNC 426 Serial No.: 14599641 Year of manufacture: 1999 Travel paths X: 500 mm, Y: 350 mm, Z: 610 mm Feed rate: 1 - 20,000 mm/min Rapid traverse: 20 m/min Feed force: 12,000 N Table clamping surface: 920 x 380 mm T-slots: 7 pcs, 12-H8 mm Table load capacity: max. 250 kg Table height: 1004 mm Distance spindle nose - table: 94 - 704 mm Overhang spindle - column: 405 mm Spindle speed: 50 - 18,000 rpm, stepless Spindle drive: 10.2 kW (60% duty cycle) Max. torque: 70 Nm (up to 1240 rpm) Spindle taper: SK 30 / DIN 69871A Pull stud: DIN 69872 Drilling capacity in steel: 25 mm Milling capacity in steel / aluminium: 100 / 700 cm³/min Thread cutting in steel / aluminium: M20 / M24 Tool changer: 24 positions Tool change time: approx. 6 sec. Chip-to-chip time: approx. 8 sec. Control: Heidenhain TNC 426 Power supply: 400 Volt, 50 Hz Connected load: 20 kW - Electronic handwheel Heidenhain HR410 - 3D probe Renishaw MP12 - Tool measurement system - TFT display - Direct path measuring system - Coolant system (200 liters, lateral) - Spindle cooling unit (lateral) - Central lubrication Vogel - Air supply: 6 bar, 40 - 200 l/min - Oil mist extraction - Operating hours: Iedpfxsy N Du Ds Aiysbb - Control on: 97,000 h - Machine on: 80,000 h - Program run: 42,000 h Required space (L x W x H): 2,000 x 1,700 x 3,000 mm Weight: approx. 3.2 t Good condition

Condition: used, Year of construction: 2022, travel -x axis 550 mm travel -y axis 400 mm travel -z axis 400 mm a-axis +/- 120 ° C-axis 360 ° control HEIDENHAIN - TNC 640 number of spindle speeds 24.000 numbers of positions in the tool changer 48 tool taper HSK-A50 5-axis machining center | CHIRON - FZ12-S equipped with ITC (70 bar), NC swivel rotary table, 48-way tool changer & chip conveyor. The machine has only 3.606 H spindle hours. Isdjz Dbyhjpfx Aiyebb Additional equipment: - BLUM LaserControl NT - BLUM TC52 Touch Probe - Scraper Belt Chip Conveyor - KF150/500 Cooling System The machine is in very well-maintained, like-new condition and can be inspected under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: FZ12S| FZ 12-S | FZ 12 S

Condition: used, Year of construction: 2013, travel distance X-axis: 508 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, spindle speed (max.): 15,000 rpm, Equipment: chip conveyor, TECHNICAL DETAILS Travel range, X-axis: 508 mm Travel range, Y-axis: 406 mm Travel range, Z-axis: 508 mm Distance from spindle nose to machine table: max. 610 mm Distance from spindle nose to machine table: min. 102 mm Rated power: max. 22.4 kW Torque: max. 122.0 N·m at 2,000 rpm Torque with optional gearbox: max. 339 N·m at 450 rpm Spindle design: metric Spindle taper: SK40 Spindle speed: 15,000 rpm Table length: 660 mm Table width: 356 mm Width of T-slots: 15.90 to 16.00 mm Center distance of T-slots: 125 mm Number of T-slots in standard configuration: 3 Load capacity of the table with uniform distribution: max. 1,361 kg Feed rate during machining: max. 16.5 m/min Rapid traverse, X-axis: 25.4 m/min Rapid traverse, Y-axis: 25.4 m/min Rapid traverse, Z-axis: 25.4 m/min Tool diameter (overall): max. 89 mm Tool weight: max. 5.4 kg Tool-to-tool change time (average): 4.20 s Isdpfxozxhmtj Aiyobb Chip-to-chip change time (average): 4.50 s MACHINE DETAILS Coolant tank capacity: 208 l Input voltage AC, three-phase, low: 220 V AC Full-load current, three-phase, low: 70 A Input voltage AC, three-phase, high: 440 V AC Full-load current, three-phase, high: 35 A Weight: 3539 kg The seller estimates the operating hours to be approximately 9,000 hours. EQUIPMENT 20-position tool changer Chip conveyor Internal cooling, 21 bar Coolant mist extraction system Additional coolant filter

Condition: good (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, CNC control Heidenhain 4. axis electronical hand wheel 20-fold automatic tool changer chip tank Technische Daten / technical details: Ijdpfx Aijx U Sd Royebb Verfahrweg X / X-Travel 1020 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 510 mm Tischgröße / table size 1200x450 mm Werkzeugschaft / spindle taper BT40 Drehzahlbereich / spindle speed 8000 UpM /rpm Anzahl der Werkzeugplätze / tool places in ATC 20 Gewicht der Maschine ca. / weight ca. 5000 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 1981, Table work surface: 500 x 1400 mm Permitted workpiece weight: 1000 kg Strokes: X1050 Y510 Z560 Ibjdpfszvni Aex Aiysb Rapid feed X/Y: 12000 mm/min Rapid feed Z: 10000 mm/min Main spindle motor: 11 kW Video of machine in operation available

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller manufacturer: Siemens, TECHNICAL DETAILS Travel range, X-axis: 800 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 500 mm Ibodsz Apdhjpfx Aiyjb MACHINE DETAILS Control system manufacturer: Siemens

Condition: used, Year of construction: 2014, x-travel 1740 mm y-travel 760 mm z-travel 660 mm Control PC-Fusion-640M spindle taper SK 40 spindle turning speed range 40 - 12.000 U/min spindle motor 30 kW distance spindle centre table top edge 180 - 840 mm table load 1400 Kg distance spindle center to column 830 mm rapid travel x/y/z 36 m/min table width 760 mm table length 2000 mm 5-T-slots - width x distance 18 x 125 mm table height over floor 825 mm tool change unit 30 tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 110 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 140 l/min electrics - voltage/frequency 400 / 50 V/Hz coolant tank 360 l high-performance coolant system 15 bar total power requirement 22 kW weight of the machine ca. 11 t dimensions of the machine ca. 4,5 x 3,5 x 3,1 m Standard Equipment / Included Accessories - Through-Spindle High-Pressure Coolant System (15 bar) - Manual Pulse Generator (MPG) - Hinged Belt Chip Conveyor, Right-Hand Side Discharge - Torque-Controlled Chip Breaking Drilling Cycle - Performance Software Package Performance Software Package Includes - 600 User Variables - MAZAK Tornado Boring & Tapping Cycle (EIA/ISO) - Synchronous Tapping - EIA/ISO Program Input - Extended EIA/ISO Functions - G93 Inverse Time Feed - G37 Automatic Tool Length Measurement - Sequence Number Comparison Stop Function - G0 Inclination Constant - Additional Work Coordinate Systems (G54.1) - Thread Cutting Function General Machine Features Adaptive Feed Control (AFC) The Adaptive Feed Control system continuously monitors spindle motor load and feed axis servo load. If a significant deviation from the programmed load is detected, the feed rate is automatically adjusted to maintain optimum cutting conditions, improve productivity and protect the cutting tool. - MAZAK Standard Machine Colour Safety Equipment - Operator Safety Door with Interlock Switch - Fully Enclosed Splash Guard - Integrated Work Area Lighting - CE Conforming Machine Coolant System Through-Spindle Coolant (TSC) - Through-spindle coolant system - Pump pressure: 5 bar Complete coolant system including pumps, valves, piping and coolant nozzles for efficient machining and reliable chip evacuation. Measuring System Ibjdpfszz Afiox Aiyeb Automatic Tool Length Measurement Automatic measurement of small-diameter tools without operator intervention. Chip Disposal Machine prepared for side-mounted chip conveyor CNC Control - MAZATROL PC Fusion CNC 640M - 10.4" Colour LCD Display - Relocation Detector MAZAK Tornado Boring & Tapping Cycle (MAZATROL) Helical interpolation allows boring and tapping operations over a wide range of diameters using a single tool, significantly reducing programming time and machining time while increasing flexibility. Background Tool Path Verification Tool paths can be verified in the background while another NC program is being executed in automatic mode. Machining Navigation – Prediction Prior to machining, the control predicts machining time, spindle load and other operating parameters, allowing programs to be optimized for maximum productivity. Machining Navigation – Monitoring Real-time display of machining conditions and machine loads with continuous feedback for process optimisation. Machining Navig...

Condition: used, Year of construction: 2013, x-travel 1020 mm y-travel 610 mm z-travel 610 mm control Heidenhain iTNC530 Isdpjzzfb Hjfx Aiyebb

Condition: used, Year of construction: 2015, x-travel 1020 mm y-travel 610 mm z-travel 610 mm control Heidenhain iTNC530 Iedpfszzfbmox Aiyobb weight of the machine ca. 7390 kg

Condition: used, Year of construction: 2012, travel -x axis 1.630 mm travel -y axis 762 mm travel -z axis 650 mm control FANUC - 0I-MD Spindle speed 12.000 min -1 weight of the machine ca. 13 t Milling machining centers - vertical | DOOSAN - DNM 750 equipped with 30-way tool changer, ITC (20 bar) and chip conveyor. The machine only has 13.686 spindle hours. The machine video from the production plant will be shared on request. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Ibjdpfx Ajzw N E Ieiyeb #Tags: DNM750 | DNM-750

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 675002, travel distance X-axis: 650 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 500 mm, empty load weight: 13,000 kg, TECHNICAL DETAILS Travel range, X-axis: 650 mm Travel range, Y-axis: 1,100 mm Travel range, Z-axis: 500 mm C-axis rotation: 360° Tool magazine slots: 32 pcs. MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,500 x 1,800 x 2,800 mm Iodpfx Ajzxckmoiysbb Dry weight: 13,000 kg Transport packages: 3 pcs. EQUIPMENT Documentation CE marking

Condition: used, Machine has a defect in the main spindle CNC vertical machining center CHIRON type FZ 22 L high speed Machining center with CNC control FANUC Series 21-M serial no. 179-98 year of construction 1999 Travel X: 2000 mm, Y: 520 mm, Z: 630 mm Table size 2700 x 570 mm Ibedpfx Ajquhbgoiyjb Table load 525 kg (per meter) Tool holder SK 40 (DIN 69871) Drilling capacity 35 mm Tapping capacity M27 Tool diameter 75 mm Diameter with free secondary positions 105 mm Tool change speed tool - tool 2.0 sec. Tool change speed from chip to chip 4.8 sec. Distance spindle nose - table 190 to 820 mm Spindle speed max. 10,500 rpm Main spindle drive max. 18.5 kW Mains connection 400 Volt, 50 Hz, 32 kVA - Pendulum machining over 2 work areas (partition wall missing) - CNC control FANUC Series 21-M - Tool changer 40-fold - IKZ = internal coolant supply through the spindle - Spray protection cabin with sliding door - Indirect measuring system - Coolant device with chip conveyor opposite - Electronic handwheel Transport dimensions of the basic machine L x W x H 4600 x 2470 x 2950 mm Weight of the machine approx. 7.5 tons. Transport space requirement on the truck L x W x H 12000 x 2470 x 2950 mm Transport Weight on the truck approx. 10 ton. Weight 7.2 tons. good condition - machine has a defect on the main spindle

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 610 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 610 mm, - ULTIMAX 4 control - toolchanger for 24 tools - coolant through spindle - chip screw - electronical hand wheel - measuring feeler Renishaw Technische Daten / technical details: Verfahrweg X / X-Travel 610 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 610 mm Tischgröße / table size 760x510 mm Werkzeugschaft / spindle taper SK40 Drehzahlbereich / spindle speed 10-10000 UpM /rpm Anzahl der Werkzeugplätze / tool places in ATC 24 fach Eilgang / rapid feed 30 m/min Gewicht der Maschine ca. / weight 4700 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Iedpfox D A Ddox Aiyobb Technical data, accessories and description of the machine are not binding.

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain iTNC 620, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! Note: The machine is located on the first floor. The main difference between the MTRent MTcut v60 and the MTRent MTcut v60D lies in the inclusion of an additional rotary axis ("D" stands for rotary table or integrated 4th axis for extended machining capabilities). TECHNICAL DETAILS Travel in X-axis: 600 mm Travel in Y-axis: 420 mm Travel in Z-axis: 450 mm Distance from spindle nose to table: 120–570 mm Spindle speed range: 60 – 12,000 rpm Torque: 70 Nm (S6, 40 %) Spindle power: 11 kW (40 %) Spindle cooling: Oil/Air Tool interface: SK40 Pull stud: DIN 69871/72 Table dimensions: 750 × 420 mm Number of T-slots: 5 T-slot width: 14 mm H8 T-slot spacing: 65 mm Rapid traverse X/Y/Z: 32 Feed rate: 1 – 12,000 mm/min Positioning accuracy: ±0.005 mm Ibjdpfx Aszzlhaeiysb Repeatability: ±0.003 mm Tool positions: 30 Tool change time: 1.5 s Maximum tool weight: 6 kg Maximum tool diameter: 76 mm Maximum tool length: 250 mm MACHINE DETAILS Control system: Heidenhain iTNC 620 Central lubrication: R68 (ISO 68) Hydraulic oil: R32 (ISO 32) Compressed air connection: 3/8" Compressed air: 6–8 bar Power supply: 400 V Fuse rating: 63 A Connected power: 25 kVA Coolant tank: 160 l Linear guides X/Y/Z: 30/35/35 mm Machine bed: Meehanite casting Machine weight: 4,000 kg EQUIPMENT Rotary table or integrated 4th axis Heidenhain iTNC 620 CNC control Digital Heidenhain drive technology Ceramic-bearing precision spindle Separate spindle cooling for constant temperature Integrated chip conveyor Maintenance-free Siemens spindle motor THK linear guides in all three axes 30-position tool changer with dual gripper Central lubrication Large access door to the work area Loading option from above using an overhead crane Two waterproof work area lights CE certification • The height and weight of the asset must be considered when selecting the transport vehicle. • A forklift is available for loading. • If the item is not collected on time, a storage fee of €20.00 per lot and for each day started will be charged. The fee must be paid before collection. • The sale is made without any warranty or guarantee. • The information on the technical specifications comes from the original offer. • No liability is accepted for typing or measurement errors. If in doubt, please compare the information with the provided photos or inspect the item on site before the end of the auction.

Condition: used, Year of construction: 2019, chuck diameter 500 mm swing diameter over bed slide 700 mm control SIEMENS travel -x axis 630 mm travel -z axis 500 mm CNC turning and milling center vertical | EMAG - VMC 450 MT The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VMC450MT | VMC 450MT | VMC-450 | VMC-450MT Ibsdpfx Ajx Szlreiyob

Condition: used, CNC Vertical Machining Center HURCO Type BMC 25/M Serial No: ZB9-001-052 Year of manufacture: approx. 1995 Travel distances X: 610 mm, Y: 410 mm, Z: 560 mm Table size (clamping surface) 845 x 400 mm Table size (with coolant groove) 1050 x 500 mm Spindle taper SK 40 Distance spindle nose - table 155 - 710 mm Table load capacity max. 500 kg Overhang 420 mm Ibsdpfx Aow Nklhoiysb Spindle speed max. 10,000 rpm Feed rate 3 to 5080 mm/min Rapid traverse 10 m/min Spindle drive approx. 5.5 kW Power supply 400 Volt, 50 Hz - CNC path control Ultimax 3 with two TFT monitors - Electronic handwheel - Indirect measuring system with rotary encoders on the ballscrew - Tool changer with 20 tool stations - Full enclosure with sliding door - Swiveling control panel - Yaskawa (Japan) spindle drives - Pneumatic-mechanical tool clamp - Without coolant system – pump included – coolant tray missing Machine width 2400 mm Space requirement for transport L x W x H = 3000 x 2400 x 2650 mm Weight 4200 kg Good condition

Condition: excellent (used), Year of construction: 2013, operating hours: 11,000 h, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 435 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, nominal power (apparent): 54 kVA, torque: 117 Nm, controller manufacturer: Fanuc, controller model: i Series, workpiece height (max.): 200 mm, workpiece diameter (max.): 300 mm, total height: 300 mm, total length: 2,465 mm, total width: 2,835 mm, table width: 200 mm, table load: 60 kg, rotary table diameter: 200 mm, overall weight: 5,500 kg, spindle speed (min.): 120 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 11,000 h, coolant supply: 20 bar, spindle nose: DIN40, number of spindles: 1, number of slots in tool magazine: 30, tool length: 300 mm, tool diameter: 125 mm, tool weight: 8 g, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 2013 Doosan DNM 200/5AX 5 Axis CNC Machining Centre Used 2013 Doosan DNM 200/5AX (4+1) 5-axis CNC machining centre with Fanuc i Series control, probe, tool holders, spindle chiller, transformer, swarf conveyor and only 11,000 run time hours. Manufacturer: Doosan Model: DNM200/5AX Machine Type: 5 Axis (4+1) Machining Centre Year: 2013 Control: Fanuc Series i Control Hours: 11,000 Run Time Hours Machine Description 2013 Doosan DNM 200/5AX CNC Machining Centre, a compact, high-performance 4+1 - 5-axis vertical machining centre ideal for precision engineering, toolmaking, aerospace, medical, motorsport, mould and die, and complex component machining. This machine is fitted with a Fanuc i Series CNC control and has only 11,000 run time hours, making it an excellent opportunity for manufacturers looking for a reliable used 5-axis machining centre with strong capability, premium features and valuable accessories included. The Doosan DNM 200/5AX is well known for combining compact footprint, rigid construction and 5-axis positioning. It is ideal for reducing setups, machining complex parts and increasing productivity compared with conventional 3-axis machining. Key Features 2013 Doosan DNM 200/5AX 4+1 5 Axis CNC Machining Centre Fanuc i Series Control Only 11,000 Run Time Hours Includes Renishaw OMP60 probe Includes tool holders Includes spindle chiller Includes transformer Includes swarf conveyor Compact 5-axis machining solution Ideal for complex component machining Technical Specifications X Axis Travel: 400 mm Y Axis Travel: 435 mm Z Axis Travel: 500 mm Ibedpfx Aey St Sdeiyob A Axis Travel: 150 Deg (+30 to -120Deg) C Axis Travel: 360 Deg Table Diameter: 200 mm Max Load on Table: 60 kg Max Workpiece: 300mm Dia x 200mm High Spindle Speed: 12,000 rpm Spindle Taper: DIN40 Pullstud: Nikken PS-806 Tool Capacity: 30 Station ATC Rapid traverse (X, Y): 36000mm/min Rapid traverse (Z): 30000mm/min Rapid traverse: (A - tilt axis) 20 rpm Rapid traverse: (C – rotary axis) 30 rpm Maximum feedrate: (X, Y, Z) 15000mm/min Maximum feedrate: (A, C) 7200 deg/min Feedback system: Absolute encoder Max Tool Diameter: 125mm Max Tool Length: 300mm Max Tool Weight: 8kg Spindle motor AC: 11/18.5kW Axis motor (XYZ): AC 4.0kW Axis motor (A axis): AC 3.0kW Axis motor (C axis): AC 1.6kW Power Requirements: 54.0 kVA Air Pressure: 6kgf/cm2 Machine Dimensions: 2465 x 2835 x 3091mm Approx. Machine Weight: 5,500 kg Run Time Hours: Approx. 11,000 hours Included With This Machine Renishaw OMP60 Probe Tool holders Spindle chiller Transformer Swarf conveyor Fanuc i Series CNC control Why Buy This Doosan DNM 200/5AX? This machine is a strong choice for companies searching for a used 5 axis CNC machining centre, used Doosan machining centre, Doosan DNM 200/5AX for sale, or compact 5-axis vertical machining centre. The 4+1 machining capability allows users to machine multiple faces of a component in fewer setups, helping to reduce handling time and increase production efficiency. With a compact table, high spindle speed and Fanuc control, this machine is particularly suited to small to medium batch production and complex prismatic parts. Applications This Doosan DNM 200/5AX is suitable for: Aerospace components Medical components Motorsport parts Toolroom machining Mould and die work General subcontract machining Complex 4+1 machining Notes: *Specifications are given in good faith but not guaranteed*

Condition: good (used), Year of construction: 1997, functionality: fully functional, travel distance X-axis: 510 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, CNC control MSC 803 25-fold automatic tool changer coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 510 mm Ibedpfx Aiewhkcxoyob Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 510 mm Tischgröße / table size 750x550 mm Drehzahlbereich / spindle speed 8000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 25 fach Spindelaufnahme / spindle taper BT40 Gewicht der Maschine ca. / weight 4500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain iTNC 620, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! Note: The machine is located on the first floor. TECHNICAL DETAILS Travel range X-axis: 600 mm Travel range Y-axis: 420 mm Iodpfx Aiozzlh Heyebb Travel range Z-axis: 450 mm Distance spindle nose – table: 120–570 mm Speed range: 60 – 12,000 rpm Torque: 70 Nm (S6, 40 %) Spindle power: 11 kW (40 %) Spindle cooling: Oil/air Tool holder: SK40 Pull stud: DIN 69871/72 Table dimensions: 750 × 420 mm Number of T-slots: 5 T-slot width: 14 mm H8 T-slot spacing: 65 mm Rapid traverse X/Y/Z: 32 Feed rate: 1 – 12,000 mm/min Positioning accuracy: ±0.005 mm Repeatability: ±0.003 mm Tool positions: 30 Tool change time: 1.5 s Maximum tool weight: 6 kg Maximum tool diameter: 76 mm Maximum tool length: 250 mm MACHINE DETAILS Control system: Heidenhain iTNC 620 Central lubrication: R68 (ISO 68) Hydraulic oil: R32 (ISO 32) Compressed air connection: 3/8" Compressed air: 6–8 bar Power supply: 400 V Fuse rating: 63 A Connected power: 25 kVA Coolant tank: 160 l Linear guides X/Y/Z: 30/35/35 mm Machine bed: Meehanite casting Machine weight: 4,000 kg EQUIPMENT Heidenhain iTNC 620 CNC control system Digital Heidenhain drive technology Ceramic-bearing precision spindle Separate spindle cooling for constant temperature Integrated chip conveyor Maintenance-free Siemens spindle motor THK linear guides in all three axes 30-position tool changer with double gripper Central lubrication Large access door to the work area Loading possible from above using an overhead crane Two waterproof work area lights CE certification The height and weight of the asset must be taken into account when selecting the transport vehicle. A forklift is available for loading. If the item is not collected on time, a storage fee of €20.00 per lot and day started will be charged. The fee must be paid before collection. The sale is made with the exclusion of any warranty or guarantee. The information on the technical data comes from the original offer. No liability is assumed for printing and measurement errors. In case of doubt, please compare the information with the provided photos or inspect the goods on site before the end of the auction.

Condition: used, Year of construction: 2024, x-travel 400 mm y-travel 400 mm z-travel 375 mm control Siemens 840D sl Linear Ibedezvhm Iopfx Aiyob

Condition: used, CNC Vertical Machining Center HURCO Type BMC 30/M Serial No: B3M92202056AB : 9650234 Year of construction 1996 CNC path control Ultimax 3 Travel X: 760 mm, Y: 460 mm, Z: 610 mm Table size (clamping surface) 1010 x 400 mm Table size (with water groove) 1120 x 500 mm Spindle holder SK 40 Distance spindle nose - table 150 - 760 mm Projection 450 mm Spindle speed 80 to 8000 rpm infinitely variable Ijdpfstrhq Hex Aiyobb Feed rate 3 to 16,000 mm/min. Rapid traverse 24 m/min. Spindle drive 7.5 kW at 30 min / 5.5 kW at 100% Mains connection 400 Volt, 50 Hz - CNC path control Ultimax 3 (with hardware update e.g. TFT monitors) - Electronic handwheel - Indirect measuring system with rotary encoders on the ball screw spindle - Tool changer with 24 tool positions - Fully protected cabin with sliding door - Rotating control panel - spindle drives Yaskawa (Japan) - pneum. mechanical tool clamp - Coolant unit adjacent, pushed under from behind - trough rinsing Machine width 2400 mm Space required for transportation L x W x H 3400 x 2400 x 2550 mm Weight approx. 4800 kg good condition
