Used Vertical Carousel for sale (7,473)

Condition: used, Year of construction: 2013, Technical details: turning diameter: 250 mm swing diameter: 250 mm turning height: 200 mm total power requirement: 37,7 kW chuck diameter: 315 mm spindle speed max.: 5500 1/min travel -x axis: 625 mm travel -y axis: +100/-80 mm travel -z axis: 250 mm worktool system: VDI 30+40 weight of the machine ca.: 8 t The synchronous spindle is powered with 37.7 kW of power, a torque of 300 Nm and a maximum speed of 5,500 rpm. Typical components are ball cages, ball hubs, gear wheels, sliding sleeves, pump wheels, flanges, synchronizer rings, bearing rings and pivot pins. The machine bed is made of Hydropol, a mixture of special concrete and steel, which ensures the greatest smoothness and precision even with larger components and powerful machining. * Njdovxuc Eepfx Aanedf

Condition: ready for operation (used), Year of construction: 2002, operating hours: 55,730 h, General Data Machine weight 24500 kg Control Unit Brand SIEMENS Model Sinumerik Main Drive Spindle speed range 12000 Spindle motor power 35 kW Number of axis 3 Movement X-Axis Rapid Traverse 100 m/min Y-Axis Rapid Traverse 60 m/min Z-Axis Rapid Traverse 60 m/min Table Table load 3100 kg Turret Ndsdpfsx Nr Tuox Aanof Number of tool slots 9 Tools Max weight 6 kg (SK40/HSK63) or 12 kg (SK50/HSK100) Type of tool holder HSK-63 Additional Equipment Safety Equipment: Monitored and locked work area door; Key switch for normal and set-up mode; Limited functions when the door is open This 3-axis DECKEL MAHO DMF 250 linear was manufactured in 2002. It features a robust vertical machining center with a high-speed main drive up to 40 kW and rapid traverse rates of 100 m/min on the X-axis and 60 m/min on Y- and Z-axes. The work table measures 3,100 × 900 mm with a load capacity of 3,100 kg. If you are looking to get high-quality milling capabilities consider the DECKEL MAHO DMF 250 linear machine we have for sale. Contact us for more information. Application Types Milling

Condition: used, Year of construction: 2021, turning diameter 400 mm turning height 300 mm swing diameter 520 mm workpiece weight 60 kg x-axis 995 mm y-axis +/-30 mm z-axis 580 mm Nsdpfx Aex H Aiboanodf chucking diameter max. 500 mm Tool drive speed max. 6.000 1/min Main spindle drive power 37 KW tool turret with 12 work positions BMT75 total power requirement 55 kW weight of the machine ca. 13,5 t Circulating workpiece transport system, O-design Drag frame system for 10 workpieces Coolant supply: 15 bar Coolant pump with a flow rate of approx. 80 l/min at 15 bar. Cooling unit (6.5 kW, water-air) A cooling unit (with dual-circuit technology) regulates the machine's thermal balance. The spindle drive, control cabinet, and turret are maintained at ambient temperature (10°C - 40°C). Dual coolant filter, manually switchable Filter mesh 100 µm, with electrical and mechanical contamination indicator Chip conveyor Hinged belt design: to the rear Chip discharge height 1,100 mm. (with integrated coolant reservoir, capacity approx. 500 l) Emulsion mist extraction: Extraction capacity approx. 800 m3/h Flushing gun Workpiece measurement with measuring probe Blow-off measuring probe Tool life monitoring (sister tool management) Tool breakage monitoring TOOLINSPECT MCU-EUROPA Axial drilling and milling head - BMT75 CC 5x 90° angle drilling and milling heads - BMT75 CC (i=1:1) Tool set for OP10 + OP20 Hydraulic full clamping cylinder size 150 - with 1 media feed-through Max. tensile force 10,850 daN at 70 bar Coolant through the spindle Programmable clamping pressure adjustment 3-jaw power chuck KNCS-N 500-155 quick-change Max. = 2,200 rpm (standard speed according to DIN 6386) Set of hard base jaws Set of soft top jaws Attachments for KNCS-N 500-155 Flushing nozzle in chuck bore Additional tool holders with tools: 1x 8.BMT25VL8IKX50 External finishing cutter 1x 8.BMT25VL8IKX50 External roughing cutter 1x 60.7516VL8IKDI15 Engraving tool 1x 60.7516VL8IKDI15 Tapping chuck 1x 40.75V5KRVL8IKD 50mm cutter head 3x 80.75V5VL8IKD boring bar holder 2x 27.V520HYDL26 drill bits, 20mm diameter 1x 42.V522L08Ik drill bits, 22mm diameter 1x 27.V514WNL31 Drill Bit Diameter 14mm Software Package Operating Instructions / Maintenance Manual

Condition: like new (used), functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC530, spindle speed (max.): 36,000 rpm, operating hours of spindle: 4,651 h, spindle nose: HSK 50, number of spindles: 15, Equipment: CE marking, documentation/manual, VERTICAL MACHINING CENTER MIKRON MODEL HSM 800 X-AXIS TRAVEL 800 mm Y-AXIS TRAVEL 600 mm Z-AXIS TRAVEL 500 mm SPINDLE HSK E 50 SPINDLE SPEED 36,000 RPM Ndedew U T Szopfx Aanof WORKPIECE PROBE LASER MEASUREMENT SYSTEM OPERATION AND MAINTENANCE MANUALS CE CERTIFICATION CNC HEIDENHAIN iTNC 530 REMOTE HANDWHEEL SIEMENS MOTORS AND DRIVES HEIDENHAIN LINEAR GLASS SCALE MEASURING SYSTEM TOTAL OPERATING HOURS: 6447 SPINDLE HOURS: 4651

Condition: used, Year of construction: 2002, Technical details: max. wheel diameter: 130 mm gear width: 170 mm max. module: 3 min. module: 0,5 total power requirement: 48 kVA weight of the machine ca.: 9 t Ndodpowdyx Uofx Aanof dimensions of the machine ca.: 7,64 x 3,14 x 3,25 m For technical data, see PDF-File enclosed *

Condition: ready for operation (used), Year of construction: 2012, Main Drive Spindle speed range 12000 Tool taper HSK-A 50 Number of axis 3 Max payload Up to 5 kg Movement Nsdpfx Aaox Nr I Eenjdf X-Axis Movement 550 mm X-Axis Rapid Traverse 40 m/min Y-Axis Movement 320 mm Y-Axis Rapid Traverse 40 m/min Z-Axis Movement 360 mm Z-Axis Rapid Traverse 60 m/min Table Table load 500 kg Tools Max weight 5 kg The system consists of: 2 x CHIRON FZ 12 KW (2012) + 2 x Fanuc LR Mate 200iC (2011) + 2 x Fanuc M - 20iA (2011) + Waschstraße. It features a high-speed spindle with a maximum speed of 12,000 rpm and a rapid traverse speed of up to 60 m/min on the Z-axis. Each machine includes a 24-slot automatic tool changer and can handle a table load of up to 500 kg. Ideal for precision machining tasks. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2000, VERTICAL MACHINING CENTER GUALDONI GV 95 TRAVELS: X AXIS 1250 mm Y AXIS 620 mm Z AXIS 650 mm SPINDLE TAPER ISO 40 SPINDLE SPEED 10,000 RPM TOOL CHANGER WITH 32 POSITIONS CNC SELCA 3045 CHIP CONVEYOR HIGH PRESSURE THROUGH SPINDLE Nodpfx Aaexpd Egenodf

Condition: used, Year of construction: 2015, Technical details: turning diameter: 200 mm swing diameter: 260 mm turning height: 60 mm Ndsdsq Sc Huspfx Aansf

Condition: ready for operation (used), Year of construction: 2012, operating hours: 35,385 h, Control Unit Brand SIEMENS General Data Machine weight 5500 kg Main Drive Spindle speed range 7500 Number of axis 3 Movement X-Axis Movement 400 mm Z-Axis Movement 200 mm Turret Number of turrets 1 Tools Number of station 12 Type of tool holder VDI 40 Media Internal cooling Yes Additional Equipment Tool Storage: Conveyor belt for max. 27 workpieces Ndsdox Nr Skspfx Aanof Workpiece Feed: Vibratory spiral conveyor, vibrating plate, single workpiece feed Handling Robot: 8-axis Protective Enclosure: Robot cell Scraper Belt Conveyor Oil Mist Extraction Cooling System: Cooling capacity 3 kW Chip Container: 700x700x600 mm It's System of 2 EMAG VL03 vertical turning machines that were manufactured in 2012 and 2010. It features a Fanuc control system, Series 32i-Model A, with a travel range of 400x200mm and a spindle speed of up to 7,500 rpm. The system machine includes a 12-station tool turret with VDI 40 tool holders and a tool drive of 6,000 rpm. Consider the opportunity to buy this vertical turning machine system with robot included. Contact us for more information about this system. Application Types Turning

Condition: excellent (used), travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 600 mm, controller manufacturer: Heidenhain, controller model: iTNC530, spindle speed (max.): 1,80,000 rpm, spindle nose: hsk 63, number of spindles: 30, Equipment: chip conveyor, documentation/manual, FPT vertical machining center model RAID Nedpfsx H Iylsx Aanedf Travels 1500X1100X600 mm 30-position tool changer HSK 63 spindle, 18,000 RPM (overhauled in 2025) CNC HEIDENHAIN iTNC 530 Remote electronic handwheel Chip conveyor

Condition: used, Year of construction: 2000, Technical details: pulling force - max.: 2,5 t Ndedjw Dugaspfx Aanof max. ram stroke: 1000 mm max. workpiece diameter: 40 mm Broaching speed: 60 m/min. return speed: 20 m/min. total power requirement: 24 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 1,7 x 2,4 x 4,77 m clamping plate: 320 mm

Condition: ready for operation (used), Year of construction: 2007, General Data Machine weight 8300 kg Control Unit Brand HEIDENHAIN Model iTNC 530 Main Drive Spindle speed range 36000 Number of axis 3 Movement X-Axis Movement 800 mm X-Axis Rapid Traverse 80 m/min Y-Axis Movement 600 mm Y-Axis Rapid Traverse 80 m/min Z-Axis Movement 500 mm Z-Axis Rapid Traverse 80 m/min Tools Max weight 1.5 kg Max tool diameter 25 mm Nodpsx Nr Ifofx Aanjdf Max tool length 150 mm Type of tool holder HSK-E50 This 3-axis +GF+ AgieCharmilles Mikron XSM 800 was manufactured in 2007. A vertical machining centre, it offers advanced capabilities for detailed and complex machining tasks. Consider the opportunity to buy this +GF+ AgieCharmilles Mikron XSM 800 vertical machining centre. Contact us for more information. Application Types Milling

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 635 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, spindle speed (max.): 10,000 rpm, spindle nose: ISO 40, number of slots in tool magazine: 30, Equipment: CE marking, chip conveyor, documentation/manual, VERTICAL MACHINING CENTER DMG MODEL DMC 635V TRAVELS: 635x510x460 mm TOOL CHANGER RANOM 30 POSITIONS SPINDLE 10,000 RPM HIGH PRESSURE THROUGH SPINDLE CHIP CONVEYOR REMOTE HANDWHEEL HEIDENHAIN HR410 Njdpsxq E Dajfx Aanjdf

Condition: used, Year of construction: 2002, Technical details: max. wheel diameter: 200 mm gear width: 250 mm max. module: 3 min. module: 0,5 Ndjdpfxjx Iumns Aansf total power requirement: 45 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 4,4 x 2,4 x 2,7 m Machine out of prototype production Without automation *

Condition: ready for operation (used), Year of construction: 2014, General Data Machine weight 6800 kg Measurements height 2808 mm Dimensions Machine Length 2929 mm Table Table load 1200 kg Main Drive Nodpfx Aox E Edxeanodf Number of axis 3 Spindle Speed 12000 RPM Spindle motor power 18.5 kW Movement X-Axis Movement 1050 mm Z-Axis Movement 510 mm Y-Axis Movement 530 mm Tools Max weight 8 kg This 3-axis Mazak VCS 530C vertical machining centre was manufactured in 2014. It features a table size of 1300x550 mm, X/Y/Z travels of 1050/530/510 mm, and a maximum spindle speed of 12000 min⁻¹. The machine supports a table load up to 1200 kg and includes a 30-tool magazine with a rapid tool change time of 2.8 seconds. Consider the opportunity to buy this Mazak VCS 530C vertical machining centre. Contact us for more information about this machine. Application Types Milling

Condition: used, Technical details: honing diameter: 4-31 mm stroke: 350 mm Nsdpfxswx Shko Aansdf throat: 250 mm

Condition: ready for operation (used), Year of construction: 2001, General Data Measurements width 2349 mm Measurements depth 1640 mm Measurements height 2600 mm Machine weight 2300 kg Ndsdpfx Aaox D Nfbonof Movement X-Axis Movement 500 Y-Axis Movement 300 Z-Axis Movement 300 This 3-axis Hyundai SPT-V30TD was manufactured in 2001. It features a spindle speed of 8,000 rpm, table dimensions of 600 x 380 mm, and a maximum table load of 200 kg. Ideal for milling applications, it offers X, Y, and Z travels of 500 mm, 300 mm, and 300 mm respectively. Consider the opportunity to buy this Hyundai SPT-V30TD vertical machining centre. Contact us for more information about this machine. Application Types Milling

Condition: used, Year of construction: 2013, Technical details: faceplate diameter: 800 mm power requirement: 110 kW weight of the machine ca.: 37.000 / total 52.000 t transport measurements machine: 5,07 x 2,98 x 3,90 m clamping diameter: 800 mm : Ø 800 x 720 mm Nsdpfxeuyp Eno Aanodf Tool bore: Capto C6 tools in tool magazin: 2 x 80 With C-Axis *

Condition: ready for operation (used), Year of construction: 2018, Movement X-Axis Movement 1500 mm Ndedpfx Asx D Sg Ujanef Y-Axis Movement 660 mm Z-Axis Movement 660 mm This 3-axis Okuma MB-66VB was manufactured in 2018 and features a robust vertical machining center design. It offers a large working area of 660 × 1530 mm, with X, Y, and Z travels of 1500 mm, 660 mm, and 660 mm respectively. The machine supports a load capacity of 1500 kg and achieves rapid traverse feed rates up to 40 m/min. Consider the opportunity to buy this Okuma MB-66VB vertical machining center. Contact us for more information about this machine. Application Types Milling

Condition: used, Year of construction: 2003, Technical details: Ndedpfxswwluns Aanof max. wheel diameter: 80 mm max. module: 3 total power requirement: 25-35 kW weight of the machine ca.: 10 t workpiece weight: 15 kg workpiece length - max.: -50....+450 mm table diameter: 145 mm diameter of hob: 90 mm cutter length max.: 220 mm hob turning speeds: 1.000 U/min

Condition: used, Year of construction: 2016, Technical details: total power requirement: 55 kW weight of the machine ca.: 13 t We offer you 21 x EMAG complete € 50.000 free loaded new EMAG is around € 500.000 * Ndedsxy I Exepfx Aanef

Condition: used, Year of construction: 2002, Technical details: x-travel: 2200/3400 mm y-travel: 550 mm z-travel: 510 mm total power requirement: 36,8 kW table length: 3050 mm Njdsldk Uqspfx Aanedf Traverse path can be used as a whole or divided into two areas for pendulum machining. 3 axis HSK 100 *

Condition: used, Year of construction: 2005, Technical details: x-travel: 750 mm y-travel: 406 mm z-travel: 508 mm Nsdpfx Aasx Iwr Tsnjdf weight of the machine ca.: 4 t bore spindle turning speed range: 12.000 U/min HAAS VF-2 is a 3-axis machining center designed for precision, high accuracy and reliability. *

Condition: used, Year of construction: 2002, Technical details: turning diameter: 200 mm turning height: 120 mm weight of the machine ca.: 18 t Ndedpfsr Dwpmsx Aanof Available from 01.08.2024 *

Condition: used, Year of construction: 2003, Technical details: Nodpfx Aaeuqq Uqjnsdf x-travel: 800 mm y-travel: 400 mm z-travel: 350 mm total power requirement: 44 kW weight of the machine ca.: 8,8 t dimensions of the machine ca.: 6,1 x 4,1 x 3,3 m tool taper: HSK63 number of spindle speeds: 36-12.000 Number of tools: 2 x 21 St. rotary table diameter: 1340 mm
